Wireless SMCWIPCAM-G
EZ Connect™g Wireless IP Camera with Pan/Tilt and MPEG4 support
www.smc.com
The SMCWIPCAM-G is an MPEG-4 (Wireless) Pan/Tilt Internet Camera, a
standalone system that can be connected directly to an Ethernet or Fast
Ethernet, and also supported by the wireless transmission based on the
IEEE 802.11g standard. With support for latest MPEG-4 technology, you
can record streaming video that utilizes high quality MPEG-4 images to
your hard drive, enable motion detection and setup automated email
alerts for security. The built-in microphone provides you with the audio
function, allowing you to “watch” and “listen” from the camera.
Compared to the conventional PC Camera, the camera features a built-in
CPU and web-based solutions that can provide a cost-effective solution
to transmit the real-time high-quality video images and sounds
synchronously for monitoring.
The camera can be managed remotely, so that you can use a web
browser to access and control it from any notebook/desktop PC over
the Intranet or Internet. The simple installation procedures and web-
based interface allow you to integrate it into your network easily. With
comprehensive applications supported, the Internet camera is your best
solution for remote monitor, high quality, and high performance video
images. The SMCWIPCAM-G has a built-in CPU, no special hardware (such
as a PC frame capture card) or software required. The camera supports
DirectX 9.0; therefore, the only requirement you need is the web browser
software such as Internet Explorer 5.0 or above. Once you have a valid IP
Address, just connect it and you can view the picture and receive sound
from your camera. In addition, the camera’s stand allows you to adjust
the camera for optimal viewing angle. You can tilt the camera right or left
(up to 170/ 170 degrees), forward or backward (up to 45/90 degrees).
The camera supports TCP/IP networking, SMTP e-mail, HTTP and other
Internet related protocols. It can be utilized in a mixed operating system
environment, including Windows 98SE/ME/ 2000/XP. Moreover, it can be
integrated easily into other www/ Intranet applications.
Applying a standard web browser, the administrator can configure and
manage the camera directly from its own web page via the Intranet or
Internet. Up to 64 users name and password are permitted with privilege
setting controlled by the administrator.
The powerful IPView Pro application assigns the administrator with a
pre-defined user ID and password, allowing the administrator to modify
the camera settings from the remote site via Intranet or Internet. When
new firmware is available, you can also upgrade remotely over the
network for added convenience. Users are also allowed to monitor the
image, and take snapshots.
FEATURES BENEFITS
OVERVIEW
Easy to Install and Use Installation in 5 minutes using the EZ
Installation Wizard from the CD-ROM
Support for Variety of Platforms The camera works with all major operating
systems. ActiveX and DirectX are supported.
The camera can be embedded into Internet/
Intranet pages as well.
Web Configuration / Additional Software Web-based management, IP View Pro software
for professional usage included
Wall Mounting Kit No need for additional purchase of bracket kits.
Remote Access You can easily access the camera from anywhere
having an Internet access.
