Smeg DF345CQSX Manuale utente

DF345CQSX

EN Dishwasher User Manual

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following data

available: Model, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

VISIT OUR WEBSITE:

To get usage advice, brochures, trouble shooter, service and repair information:

www.smeg.com/services/customer-service

CONTENTS

1. SAFETY INFORMATION...................................................................................2

2. SAFETY INSTRUCTIONS.................................................................................4

3. PRODUCT DESCRIPTION............................................................................... 6

4. CONTROL PANEL............................................................................................ 7

5. PROGRAMMES................................................................................................ 8

6. OPTIONS.........................................................................................................10

7. SETTINGS.......................................................................................................11

8. BEFORE FIRST USE...................................................................................... 14

9. DAILY USE......................................................................................................15

10. HINTS AND TIPS.......................................................................................... 16

11. CARE AND CLEANING.................................................................................18

12. TROUBLESHOOTING...................................................................................22

13. TECHNICAL INFORMATION........................................................................ 25

14. ENVIRONMENTAL CONCERNS.................................................................. 26

Subject to change without notice.

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully read

the supplied instructions. The manufacturer is not responsible

for any injuries or damage that are the result of incorrect

installation or usage. Always keep the instructions in a safe

and accessible location for future reference.

2 ENGLISH

1.1 Children and vulnerable people safety

•This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

the use of the appliance in a safe way and understand the

hazards involved.

•Children between 3 and 8 years of age and persons with

very extensive and complex disabilities shall be kept away

from the appliance unless continuously supervised.

•Children of less than 3 years of age should be kept away

from the appliance unless continuously supervised.

•Children should be supervised to ensure that they do not

play with the appliance.

•Keep detergents away from children.

•Keep children and pets away from the appliance when the

door is open.

•Children shall not carry out cleaning and user maintenance

of the appliance without supervision.

1.2 General Safety

•This appliance is for cleaning household-type dishes and

tableware only.

•This appliance is designed for single household domestic

use in an indoor environment.

•This appliance may be used in offices, hotel guest rooms,

bed & breakfast guest rooms, farm guest houses and other

similar accommodation where such use does not exceed

(average) domestic usage levels.

•Do not change the specification of this appliance.

•The operating water pressure (minimum and maximum)

must be between 0.05 (0.5) / 1 (10) MPa (bar).

•Follow the maximum number of 14 place settings.

•The appliance door should not be left in an open position to

avoid the tripping hazard.

ENGLISH 3

•If the supply cord is damaged, it must be replaced by the

manufacturer, its Authorised Service Centre or similarly

qualified persons in order to avoid a hazard.

•WARNING: Knives and other utensils with sharp points

must be loaded in the basket with their points down or

placed in a horizontal position.

•Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the socket.

•Do not use high pressure water sprays and/or steam to

clean the appliance.

•If the appliance has ventilation openings in the base, they

must not be covered e.g. by a carpet.

•The appliance is to be connected to the water mains using

the new supplied hose-sets. Old hose sets must not be

reused.

2. SAFETY INSTRUCTIONS

2.1 Installation

WARNING!

Only a qualified person must install this

appliance.

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Follow the installation instructions supplied

with the appliance.

• Always take care when moving the

appliance as it is heavy. Always use safety

gloves and enclosed footwear.

• Do not install or use the appliance where

the temperature is less than 0 °C.

• Install the appliance in a safe and suitable

place that meets installation requirements.

2.2 Electrical connection

WARNING!

Risk of fire and electric shock.

• Warning: this appliance is designed to be

installed / connected to a grounding

connection in the building.

• Make sure that the parameters on the

rating plate are compatible with the

electrical ratings of the mains power

supply.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to the

mains plug and to the mains cable. Should

the mains cable need to be replaced, this

must be carried out by our Authorised

Service Centre.

• Connect the mains plug to the mains

socket only at the end of the installation.

Make sure that there is access to the

mains plug after the installation.

• Do not pull the mains cable to disconnect

the appliance. Always pull the mains plug.

• This appliance is fitted with a 13 A mains

plug. If it is necessary to change the mains

plug fuse, use only a 13 A ASTA (BS

1362) fuse (UK and Ireland only).

2.3 Water connection

• Do not cause damage to the water hoses.

• Before connection to new pipes, pipes not

used for a long time, where repair work

4 ENGLISH

has been carried out or new devices fitted

(water meters, etc.), let the water flow until

it is clean and clear.

• Ensure that there are no visible water

leaks during and after the first use of the

appliance.

• To protect drinking water, the enclosed

non-return valve must be installed

between the water tap and the water

supply hose.

• If the water inlet hose is damaged,

immediately close the water tap and

disconnect the mains plug from the mains

socket. Contact the Authorised Service

Centre to replace the water inlet hose.

• Without electrical power, the water

protection system is not active. In this

case there is a risk of flooding.

• The water inlet hose has a safety valve

and a sheath with an inner mains cable.

WARNING!

Dangerous voltage.

2.4 Use

• Do not put flammable products or items

that are wet with flammable products in,

near or on the appliance.

• Dishwasher detergents are dangerous.

Follow the safety instructions on the

detergent packaging.

• Do not drink and play with the water in the

appliance.

• Do not remove the dishes from the

appliance until the programme is

complete. Some detergent may remain on

the dishes.

• Do not store items or apply pressure on

the open door of the appliance.

• The appliance can release hot steam if

you open the door while a programme

operates.

2.5 Service

• To repair the appliance contact the

Authorised Service Centre. Use original

spare parts only.

• Please note that self-repair or non-

professional repair can have safety

consequences and might void the

guarantee.

• The following spare parts will be available

for 7 years after the model has been

discontinued: motor, circulation and drain

pump, heaters and heating elements,

including heat pumps, piping and related

equipment including hoses, valves, filters

and aquastops, structural and interior

parts related to door assemblies, printed

circuit boards, electronic displays,

pressure switches, thermostats and

sensors, software and firmware including

reset software. Please note that some of

these spare parts are only available to

professional repairers, and that not all

spare parts are relevant for all models.

• The following spare parts will be available

for 10 years after the model has been

discontinued: door hinge and seals, other

seals, spray arms, drain filters, interior

racks and plastic peripherals such as

baskets and lids.

• Concerning the lamp(s) inside this product

and spare part lamps sold separately:

These lamps are intended to withstand

extreme physical conditions in household

appliances, such as temperature,

vibration, humidity, or are intended to

signal information about the operational

status of the appliance. They are not

intended to be used in other applications

and are not suitable for household room

illumination.

2.6 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the mains

supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent children

and pets to get closed in the appliance.

ENGLISH 5

3. PRODUCT DESCRIPTION

67 5

11 10 8

1Worktop

2Ceiling spray arm

3Upper spray arm

4Lower spray arm

5Filters

6Rating plate

7Salt container

8Air vent

9Rinse aid dispenser

10 Detergent dispenser

11 Lower basket

12 Upper basket

13 Cutlery drawer

6 ENGLISH

4. CONTROL PANEL

2 4 5

1On/off button

2Program touch button

3Programme indicators

4Display

5Delay touch button

6Option touch button

7Indicators

8Start touch button

4.1 Indicators

Indicator Description

Salt indicator. It is on when the salt container needs refilling. It is always off while the pro‐

gramme operates.

Rinse aid indicator. It is on when the rinse aid dispenser needs refilling. It is always off

while the programme operates.

Washing phase indicator. It is on when the washing phase operates.

Rinsing phase indicator. It is on when the rinsing phase operates.

Drying phase indicator. It is on when you select a programme with the drying phase. It

flashes when the drying phase operates.

Delay indicator. It is on when you set the delay start.

Crystal indicator.

ENGLISH 7

Indicator Description

Extreme indicator.

Sterilise indicator.

5. PROGRAMMES

The order of the programmes in the table may not reflect their sequence on the control panel.

Programme Dishwash‐

er load

Degree of

soil

Programme phases Options

Eco

Crockery, cut‐

lery, pots,

pans

Normal,

lightly dried-

• Prewash

• Dishwashing 50 °C

• Intermediate rinse

• Final rinse 55 °C

• Drying

• Dry Assist 2)

• Extreme

• Crystal

• Sterilise

Intense 60°

Crockery, cut‐

lery, pots,

pans

Normal to

heavy,

dried-on

• Prewash

• Dishwashing 60 °C

• Intermediate rinse

• Final rinse 60 °C

• Drying

• Dry Assist 2)

• Extreme

• Crystal

• Sterilise

Mix 60°

Crockery, cut‐

lery, pots,

pans

Normal,

lightly dried-

• Dishwashing 60 °C

• Intermediate rinse

• Final rinse 55 °C

• Drying

• Dry Assist 2)

• Extreme

• Crystal

• Sterilise

Full Express 60'

Crockery, cut‐

lery

Fresh, light‐

ly dried-on

• Dishwashing 60 °C

• Intermediate rinse

• Final rinse 50 °C

• Dry Assist 2)

• Extreme

• Crystal

• Sterilise

Express 50°

Crockery, cut‐

lery

Fresh • Dishwashing 50 °C

• Intermediate rinse

• Final rinse 45 °C

• Dry Assist 2)

• Extreme

• Crystal

• Sterilise

8 ENGLISH

Programme Dishwash‐

er load

Degree of

soil

Programme phases Options

Auto

Crockery, cut‐

lery, pots,

pans

All • Prewash

• Dishwashing 50 - 60 °C

• Intermediate rinse

• Final rinse 60 °C

• Drying

• Dry Assist 2)

Self Clean

None Cleaning

the appli‐

ance interior

• Cleaning 70 °C

• Intermediate rinse

• Final rinse

• Dry Assist 2)

Soak

All All • Prewash

1) This programme offers the most efficient use of water and energy consumption for crockery and cutlery with

normal soil. This is the standard programme for test institutes. This programme is used to assess compliance with

the Ecodesign Comission Regulation (EU) 2019/2022. This programme is used to assess compliance with the UK

Ecodesign for Energy-Related Products and Energy Information Regulations.

2) Automatic door opening during the drying phase. Refer to "Settings".

3) The appliance senses the degree of soil and the quantity of items in the baskets. It automatically adjusts the

temperature and the quantity of water, the energy consumption and the programme duration.

4) This programme is designed to clean the inside of the appliance effectively and efficiently. It removes limescale

and grease buildup. The programme should be run at least once every 2 months with a descaler or a cleaning

product designed for dishwashers and without any load.

5) With this programme, you can quickly rinse off food remains from dishes and prevent odours forming in the ap‐

pliance. Do not use detergent with this programme.

5.1 Consumption values

Programme 1)2) Water (l) Energy (kWh) Duration (min)

11.0 0.746 240

11.9 1.210 160

11.9 1.110 90

11.8 0.970 60

11.0 0.620 30

12.1 1.220 170

10.6 0.710 60

ENGLISH 9

Programme 1)2) Water (l) Energy (kWh) Duration (min)

5.0 0.010 15

1) The pressure and the temperature of the water, the variations of the mains supply, the options, the quantity of

dishes and the degree of soil can change the values.

2) The values for programmes other than ECO are indicative only.

5.2 Information for test institutes

To receive the necessary information for conducting performance tests (e.g. according to:

EN60436 /BS EN60436 ), contact the manufacturer.

In your request, include the model from the rating plate.

6. OPTIONS

Desired options must be activated

every time before you start a programme.

It is not possible to activate or deactivate

options while a programme is running.

The option button toggles between

the available options and their possible

combinations.

Not all options are compatible with

each other. If you select non compatible

options, the appliance automatically

deactivates one or more of them. Only

the indicators of the still active options

are on.

If an option is not applicable to a

programme, the related indicator is off or

it flashes quickly for a few seconds and

then goes out.

Activating options can affect the

water and energy consumption as well as

the programme duration.

6.1 (Crystal)

This option protects a delicate load,

glassware in particular, from damaging. It

prevents rapid changes in the dishwashing

temperature of the selected programme and

reduces it to 45 °C.

How to activate

Press Option until the indicator is on.

The display shows the updated programme

duration.

6.2 (Extreme)

This option improves the dishwashing results

of the selected programme. It increases the

wash temperature and duration.

How to activate

Press Option until the indicator is on.

The display shows the updated programme

duration.

6.3 (Sterilise)

This option provides better cleaning results

by keeping the temperature between 65 and

70 °C for at least 10 minutes during the last

rinsing phase.

How to activate

Press Option until the indicator is on.

The display shows the updated programme

duration.

10 ENGLISH

Indice

Manuali Lavastoviglie popolari di altre marche

Electrolux

Electrolux ESI5211LOX Manuale utente

KitchenAid

KitchenAid KUDB230B Manuale utente

Brandt

Brandt BDJ424DB Manuale utente

Asko

Asko DSD767UXXL.AU Manuale utente

Beko

Beko DFN26210W Manuale utente

NEFF

NEFF S153ITX00E Scheda tecnica

Midea

Midea SV 4.45 wi Manuale utente

LG LDF7932 Manuale utente

Gorenje

Gorenje GV63214 Manuale utente

Hotpoint

Hotpoint HDA1100ZWH Manuale di servizio

Blomberg

Blomberg LDFN2240W Manuale utente

AEG

AEG FFB83836PM Manuale utente

Cylinda

Cylinda DM3220RFD Manuale utente

Atag

Atag DW8214MB Manuale utente

GE GLD8000 Series Manuale utente

Siemens

Siemens SN23HI02KE Scheda tecnica

Omega

Omega ODW717X Manuale utente

BORETTI

BORETTI BVW-683 Manuale utente
