INSTRUCTION MANUAL

Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Smeg LVS375SX o

cerca il tuo prodotto tra le migliori offerte di Lavastoviglie

Contents

Description of the controls ________________________________2

Operating instructions___________________________________ 16

Cleaning and maintenance_______________________________31

Troubleshooting _______________________________________ 35

Thank you for choosing one of our products.

You are advised to read this manual carefully; it contains all the

information you need use your dishwasher safely, correctly and in the

most satisfactory manner.

Following the cleaning instructions provided here will keep your

dishwasher's performance at peak levels in the long term.

USER INSTRUCTIONS: these consist of recommendations for using the

appliance, a description of its controls and of the correct cleaning and

maintenance procedures.

User instructions

1. Description of the controls

1.1 Front panel

The ON/OFF is on the top edge of the panel, and all the dishwasher’s

other controls and monitoring devices are on the central display.

Programming and option selection are only possible with the door

closed.

NOTA:

The displays illustrated in the instruction manual are purely guideline;

symbols, programs and options may vary depending on the model

purchased.

The 4-figure

INFORMATION DISPLAY (9)

informs

the user about the program delay, time remaining

(washing cycle duration) and alarms.

User instructions

1 ON/OFF BUTTON

2 SELECTION PROGRAMS BUTTON

3 START/PAUSE BUTTON

4 PROGRAMS LIGHTS

5 PHASES/PROGRAM LIGHTS

WATER HARDNESS ADJUSTMENT ON INDICATOR LIGHT

The light flashes to indicate that the appliance is in “water

hardness adjustment” mode.

SALT WARNIN LIGHT

Illumination of this light denotes a regenerating salt warning level.

7 NO RINSE AID LIGHT

8 OPTIONS

9 INFORMATION DISPLAY

PROGRAMS TABLE

The manual contains the programs table for several models. To find the

table for your dishwasher, compare the program symbols at the top of the

table with those on your control panel.

User instructions

<<OPTIONS (8)>>

Depending on the model, this zone may contain one or more of the

following options, identified by the relative symbols and described in

more detail in the relevant sections of the manual.

It is not possible to select any options when the soak program is being

used. All options except "Flexi Tabs" are disabled at the end of the

wash cycle. To disable the “Flexi Tabs” option, press the relative

button (the light goes out).

Flexi Tabs

Option recommended for the use of multi-function tablet

detergent.

HYCLEAN

Increases the temperature of the final hot rinse to 70°C to

ensure a further reduction in the bacteria level.

Spread HALF LOAD WASH

Allows washing of just a few dishes placed in both baskets.

PROGRAM DELAY

Allows the program to be set to start with a delay of up to 9, 12

or 24 hours, depending on the model.

QUICK TIME

Select this option together with any washing program (except

the soak program) to SHORTEN the cycle.

ENERSAVE

Indicated option for save energy.

WARNING!

Some models are fitted with a static system to optimise water consumption. When

a programme is started or changed, the dishwasher performs a pump-out followed by

a standby phase (about 10 min.) during which it will make absolutely no noise; the

actual washing process starts after this time.

User instructions

PROGRAMM

NUMBER &

SYMBOL

LOAD CROCKERY AND

CUTLERY

PROGRAM

PROGRESS

DURATION

CONSUMPTION

MINUTES

(1)

WATER

LITRES

POWER

KWh (1)

SOAK

Pans and dishes awaiting

completion of the load. Cold prewash

15 3,5 0,02

GLASS

Delicate dishes with light dirt.

Wash at 45°C

Cold rinse

Rinse at 70°C

Dry

9,5 1,10

DELICATE

Delicate dishes with normal dirt.

Cold prewash

Wash at 45°C

Cold rinse

Rinse at 70°C

Dry

12,5 1,1

ECO (*)

EN 50242

Dishes with normal dirt, even

with dried-on residues.

Wash at 45°C

Cold rinse

Rinse at 55°C

Dry

** **

AUTO

40-50

Pans and dishes with normal

dirt, washed immediately after

use.

When the "

AUTO

" program is selected, the dishwasher

recognises the type of dirt and automatically adjusts the

washing parameters as appropriate.

AUTO

60-70

IEC/DIN***

Pans and dishes with normal

dirt, even with dried-on residues.

When the "

AUTO

" program is selected, the dishwasher

recognises the type of dirt and automatically adjusts the

washing parameters as appropriate.

SUPER

****

Very dirty pans and dishes,

even with dried-on residues.

Hot prewash

Wash at 70°C

Cold rinse (2)

Rinse at 70°C

Dry

155

15,5 1,60

IMPORTANT: see “NOTES AND REFERENCES” table on the following pages.

If the dishwasher door is open or not properly closed, the washing cycle

will not start.

User instructions

QUICK TIME PROGRAMS

(see relevant section for explanation of functioning modes)

PROGRAMME

NUMBER E

SYMBOL

LOAD CROCKERY AND

CUTLERY

PROGRAM

PROGRESS

DURATION

CONSUMPTION

MINUTI

(1)

WATER

LITRES

POWER

KWh (1)

RAPID 27’

Dishes with light dirt,

washed immediately after

use

Wash at 38°C

Rinse at 50°C

6,5 0,70

DELICATE

QUICK

Dishes with normal dirt,

even with dried-on residues

Cold prewash

Wash at 50°C

Cold rinse

Rinse at 70°C

12,5 1,15

ECO

QUICK

Dishes with normal dirt,

washed immediately after

use.

Cold prewash

Wash at 60°C

Cold rinse

Rinse at 70°C

12,5 1,40

DAILY QUICK

Dishes with normal dirt,

washed immediately after

use.

Wash at 70°C

Cold rinse

Rinse at 70°C

9,5 1,40

NORMAL

QUICK

Dishes with normal dirt,

even with dried-on residues

Cold prewash

Wash at 70°C

Cold rinse

Rinse at 70°C

13 1,40

STRONG and

FAST

Mixed dishes with normal dirt

without dried-on residues.

Wash at 65°C

Cold rinse

Rinse at 70°C

9,5 1,35

IMPORTANT: see “NOTES AND REFERENCES” table on the following pages.

The washing cycle will not take place if the dishwasher door is left open

or not properly closed.

User instructions

PROGRAMME,

NUMBER &

SYMBOL

LOAD CROCKERY AND

CUTLERY

PROGRAM

PROGRESS

DURATION

CONSUMPTION

MINUTES

(1)

WATER

LITRES

POWER

KWh (1)

SOAK

Pans and dishes awaiting

completion of the load. Cold prewash

15 3,5 0,02

GLASS

Delicate dishes with light dirt.

Wash at 45°C

Cold rinse

Rinse at 70°C

Dry

9,5 1,10

DELICATE

Delicate dishes with normal

dirt.

Cold prewash

Wash at 45°C

Cold rinse

Rinse at 70°C

Dry

12,5 1,1

ECO (*)

EN 50242

Dishes with normal dirt, even

with dried-on residues.

Wash at 45°C

Cold rinse

Rinse at 55°C

Dry

** **

AUTO

45-65

Pans and dishes with normal

dirt, washed immediately after

use.

When the "

AUTO

" program is selected, the dishwasher

recognises the type of dirt and automatically adjusts the

washing parameters as appropriate.

6 NORMAL

IEC/DIN***

Dishes with normal dirt, even

with dried-on residues

Cold prewash

Wash at 65°C

Cold rinse

Rinse at 70°C

Dry

105

13,5 1,35

SUPER

****

Very dirty pans anddishes,

even with dried-on residues.

Hot prewash

Wash at 70°C

Cold rinse (2)

Rinse at 70°C

Dry

155

15,5 1,60

IMPORTANT: see “NOTES AND REFERENCES” table on the following pages.

If the dishwasher door is open or not properly closed, the washing cycle

will not start.

User instructions

QUICK TIME PROGRAMS

(see relevant section for explanation of functioning modes)

PROGRAMME

NUMBER E

SYMBOL

LOAD CROCKERY AND

CUTLERY

PROGRAM

PROGRESS

DURATION

CONSUMPTION

MINUTI

(1)

WATER

LITRES

POWER

KWh (1)

RAPID 27’

Dishes with light dirt,

washed immediately after

use

Wash at 38°C

Rinse at 50°C

6,5 0,70

DELICATE

QUICK

Dishes with normal dirt,

even with dried-on residues

Cold prewash

Wash at 50°C

Cold rinse

Rinse at 70°C

12,5 1,15

ECO

QUICK

Dishes with normal dirt,

washed immediately after

use.

Cold prewash

Wash at 60°C

Cold rinse

Rinse at 70°C

12,5 1,40

DAILY QUICK

Dishes with normal dirt,

washed immediately after

use.

Wash at 70°C

Cold rinse

Rinse at 70°C

9,5 1,40

NORMAL

QUICK

Dishes with normal dirt,

even with dried-on residues

Cold prewash

Wash at 70°C

Cold rinse

Rinse at 70°C

13 1,40

STRONG and

FAST

Mixed dishes with normal dirt

without dried-on residues.

Wash at 65°C

Cold rinse

Rinse at 70°C

9,5 1,35

IMPORTANT: see “NOTES AND REFERENCES” table on the following pages.

The washing cycle will not take place if the dishwasher door is left open

or not properly closed.
