Tabletop Gas Grill

VT280SS1

Tools needed for assembly:

Phillips screwdriver, Pliers or Adjust-

able Wrench

If you smell gas:

1. Shut off gas to the appliance.

2. Extinguish any open flames.

3. Open lid.

4. If odor continues, keep away from

the appliance and immediately call

your fire department.

Failure to follow these instructions could

result in fire or explosion which could

cause property damage, personal injury

or death.

DANGER

1. Never operate this appliance unat-

tended.

2. Never operate this appliance within

10 ft (3.0 m) of any structure, com-

bustible material or other gas cylin-

der.

3. Never operate this appliance within

25 ft (7.5 m) of any flammable liquid.

4. Do not fill cooking vessel beyond

maximum fill-line.

5. Never allow oil or grease to get hot-

ter than 400°F or 200°C. If the tem-

perature exceeds 400°F (200°C) or

if oil begins to smoke, immediately

turn the burner or gas supply OFF.

6. Heated liquids remain at scalding

temperatures long after the cooking

process. Never touch cooking appli-

ance until liquids have cooled to

115°F (45°C) or less.

7. If a fire should occur, keep away

from the appliance and immediately

call your fire department. Do not at-

tempt to extinguish an oil or grease

fire with water.

Failure to follow these instructions could

result in fire or explosion which could

cause property damage, personal injury

or death.

DANGER

Conforms to ANSI Std Z21.89-2013

Outdoor cooking specialty gas appliance

WARNING

For Outdoor Use Only

(outside of any type of enclosure)

WARNING

If you smell gas –

● Turn off the gas supply to the appli-

ance

● Extinguish any and all open flames

● Open the Lid of the Grill

● If the odor remains, stay away from

the grill and notify your gas supplier

and/or the Fire Department.

WARNING

● Do not use or store gasoline, kero-

sene, alcohol, or other flammable

liquids or vapors in the vicinity of

this appliance or any other appli-

ance.

● Any LP Gas Cylinder NOT con-

nected for use with the appliance,

shall not be stored in the same vi-

cinity of this or any other appliance.

● A LP Propane Gas Cylinder is

needed for operating the gas side of

this grill.

● The LP Gas Cylinder is NOT in-

cluded.

● This gas grill is only intended for

Domestic use, not to be used for

any commercial purpose.

WARNING

● Never use the gas or charcoal grill

for INDOOR cooking or heating

● Never use the grill on or in a boat or

recreational vehicle

The combustion fumes from either

the gas or charcoal grill are toxic and

can cause severe illness and possibly

death.

DANGER

The combustion of Propane gas can

yield the formation of chemical com-

pounds known in the state of Califor-

nia，U.S.A., to cause birth defects，

cancer，and other serious health mat-

ters.

WARNING

Read this installation manual before as-

sembling or servicing this appliance.

Failure to follow these instructions may

result in an faulty installation, which

could cause damage to property, dam-

age personal injury or death.

Save these instructions after reading

them in case you need to refer to them

in the future.

IMPORTANT

CALIFORNIA PROPOSITION 65

1. Combustion by-products produced

when using this product contain

chemicals known to the State of

California to cause cancer, birth de-

fects, and other reproductive harm.

2. This product contains chemicals,

including lead and lead compounds,

known to the State of California to

case cancer, birth defects, and

other reproductive harm.

Wash your hands after handling this

product.

WARNING

Read all safeguards and assembly instruc-

tions before assembling and operating

your grill.

Before assembling your new grill, unpack

all the parts from the box. Carefully re-

move all packing material and lay out all

the parts for easy access and identifica-

tion. Do not discard the carton or packag-

ing until your grill is fully assembled and

operating to your satisfaction.

In order to properly assemble your grill,

you will only need two tools:

● Phillips head screwdriver

● Pliers or adjustable wrench

(tools not included)

The grill is heavy and must be moved

around during assembly and before use.

Be sure to have a friend help.

Outdoor Leisure Products, Inc.

5400 Doniphan Drive

Neosho, MO 64850

Toll Free: 866-475-5180

Website: www.olp-inc.com

8:30am to 4:30pm, Central Time

Monday through Friday

SAFETY WARNINGS

1. The installation of this grill must conform to local codes, or in the absence of local codes, with either

the National Fuel Gas Code, ANSI Z223.1 / NFPA 54, Natural Gas and Propane Installation Code,

CSA B149.1, or Propane Storage and Handling Code, B 149.2, or The Standard for recreational

Vehicles, ANSI 119.2 / NFPA, and CSA Z240 RV Series, Recreational Vehicle Code, as Acceptable.

2. The Gas Grill is for use with LP (Propane) Gas ONLY! LP Gas Cylinder is NOT included with the Grill.

3. Never use lighter fluid, gasoline, kerosene, or alcohol for lighting the gas grill.

4. The LP Gas supply Cylinder used must be constructed and marked in accordance with the Specifica-

tions of the U.S. Department of Transportation (D.O.T.) or The Standard for

Cylinders, Spheres and

Tubes for Transportation of Dangerous Goods; and Commission, CAN/CSA-B339, as applicable. It

MUST be provided with a Listed Overfilling Device. Only use 20 pound cylinders that have a type 1 cyl-

inder connection device compatible with the Connection for Outdoor Cooking Appliances.

5. The LP gas cylinder must be arranged for vapor withdrawal, purging and have an overfilling prevention

device.

6. LP Gas Cylinders must be stored outdoors, out of the reach of children, and must not be stored in a

building, garage or any other enclosed area.

7. The Pressure regulator and Hose Assembly supplied with the Grill, must be used. Any replacement

regulator and hose assemblies must be those specified by the outdoor cooking gas appliance manu-

facturer.

8. The LP Gas Cylinder must include a collar to protect the cylinder valve.

9. Do not store a spare LP Gas Cylinder under or near this grill.

10. Never fill the LP Gas Cylinder beyond 80% full. For vapor withdrawal /purging, the cylinder should be

in the upright position.

11. This outdoor cooking gas appliance must only be used outdoors, and must not be used in a building,

garage or any enclosed area.

12. The following distances for proper clearance must be maintained :

● Minimum distance from back and sides of the outdoor cooking gas appliance to walls is 36" ( 1 me-

ter )

● Do not use under any overhead combustible constructions

● For outdoor use only

● Remove LP Gas Cylinder from grill if storing grill indoors

13. This outdoor cooking gas appliance is not intended to be installed in or on boats.

14. Inspect the Gas Hose before each use. If the Hose has any leak, cut or wear, it must be replaced BE-

FORE using the grill.

15. Do not try to move the grill while the gas chamber is lit.

16. Wait one hour minimum before touching any metal parts, until they are cool.

17. NEVER leave the grill unattended when in use.

18. Keep children and pets away from the grill when in use.

19. Note: Grease Cup should be emptied and cleaned after each use to prevent flare – ups and /or

grease fires.

IF THESE INSTRUCTIONS ARE NOT FOLLOWED EXACTLY, A FIRE CAUSING

DEATH OR SERIOUS INJURIES MAY OCCUR!

READ ALL SAFEGUARDS AND INSTRUCTIONS THOROUGHLY!

YOUR SAFETY IS VERY IMPORTANT – FAILURE TO FOLLOW PROPER PROCEDURES AND

SAFEGUARDS MAY RESULT IN PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.

DANGER DANGER

● The GRILL is for outdoor use only!

● Do NOT use this grill for other than its intended

purpose.

● Do not leave grill unattended when in use.

● Do not use gasoline, kerosene or alcohol for light-

ing charcoal, use of any of these or similar prod-

ucts may cause an explosion possibly leading to

severe bodily harm.

● Never operate this grill under any overhead roof

covering, awning or overhang. Never use inside

an enclosed area such as screen patios, garages,

buildings or tents.

● Keep the area clear of all flammable liquids, com-

bustible material including but not limited to wood,

dry plants including grass, brush, paper, and can-

vas.

● Grill is HOT while in use and after use – Avoid

touching hot surfaces. Always wear protective

gloves or mitts when operating the smoker.

● Keep children and pets away from the grill at all

times.

● Do not allow anyone to conduct activities around

the grill during or following its use until the unit

has cooled. The grill is hot during operation and

remains hot for a period of time following its use.

● Always wear shoes and protective clothing during

operation of this grill.

● Never use glassware, plastic, or ceramic cook-

ware in this grill.

● The cooking chamber lid will be extremely hot.

● Do not use water to extinguish grease fires.

● Do not move the unit while it is being used.

● Do not use in windy conditions.

● Use caution when opening the lid, as hot stream

or a flame flare-up could cause burns.

● Before each use, make sure the unit is in good

working condition.

● Use caution after the fire has been extinguished,

the surface will remain hot for some time.

● Store the grill out of reach of children and in a dry

location when not in use.

● When opening the lids, keep hands, face and

body a safe distance from hot steam and flame

flare-ups.

● Close lids and all dampers to suffocate flame.

● Never leave coals and ashes in grill unattended.

● Use caution when lifting or moving grill to prevent

strains and back injuries.

● Properly dispose of all packaging material.

USE CAUTION AND COMMON SENSE WHEN OPERATING YOUR GRILL. READ ALL INSTRUCTIONS,

WARNINGS AND SAFEGUARDS PRIOR TO ASSEMBLING AND OPERATING YOUR GRILL.

SAVE THESE INSTRUCTIONS

Hardware Pack

Quantity Description

10 M6x12 Combo Truss Head Bolts, Black Nickel Plated

2M5x17 Shoulder Bolts, Black Nickel Plated

6 M5x10 Combo Truss Head Bolts, Black Nickel Plated

2 M5 Nuts

2M6x20 Combo Truss Head Bolts, Black Nickel Plated

6Spring Washers

VT280SS1 Parts List

Note: For assistance, including missing or damaged parts, call toll free - 866-475-5180

from 8:30 am - 4:30 pm Central Time, Monday - Friday

15 16 17 18

3 2

Item No. Quantity Description Part No.

1 1 Grill Lid and Firebox Assembly VT280SS1-01

2 1 Wood Chip Box Left Rail VT280RDS-19

3 1 Wood Chip Box Right Rail VT280RDS-20

4 1 Warming Rack VT280RDS-04

5 1 Heat Indicator VT280RDS-05

6 1 Lid Handle VT280RDS-06

7 1 Lid Decorative Plate VT280SS1-07

8 2 Cooking Grid VT280RDS-08

9 1 Wood Chip Box Tent VT280RDS-09

10 1 Wood Chip Box Lid VT280RDS-10

11 1 Wood Chip Box VT280RDS-11

12 1 Wood Chip Box Front Panel Assembly VT280RDS-12

13 1 Wood Chip Box Handle VT280RDS-13

14 2 Side Supporting Leg VT280RDS-14

15 2 Heat Tent VT280RDS-15

16 1 Grease Tray Handle VT280RDS-16

17 1 Grease Tray VT280RDS-17

18 1 Rear Supporting Leg VT280RDS-18

19 1 Wood Chip Box Lock VT280RDS-22

Assembly

Note: Carefully cut the tape holding the carton together. Cut the carton so that it can lay flat on

the ground to provide a clean surface for assembling your Grill. Remove the packing materials

and all the parts from inside the Cabinet. After unpacking all the parts, check to make sure you

HAVE all the parts. If anything is damaged or missing, contact our toll free number: 866-475-

5180. Discard all packing material in a safe and recyclable manner. Save this Assembly Manual

for future reference.

Tools Required: Phillips Head Screwdriver, Adjustable Wrench or Pliers

Step 2

Step 1 Step 1: Attach the Side Supporting Legs

Locate: Grill Lid and Firebox Assembly, (2) Side

Supporting Legs, (4) spring washers and (4) M6x12

bolts

Procedure: Attach (2) Side Supporting Legs to the

Grill Lid and Firebox Assembly using (4) spring

washers and (4) M6x12 bolts as shown in Fig. 1A

and Fig. 1B.

Fig. 1A

Fig. 1B

Step 2: Attach the Rear Supporting Leg

Locate: Rear Supporting Leg, (2) spring washers

and (2) M6x12 bolts

Procedure: Attach the Rear Supporting Leg to the

Grill Lid and Firebox Assembly using, (2) spring

washers and (2) M6x12 bolts as shown in Fig. 2.

Fig. 2

Assembly

Step 3

Step 5

Step 3: Attach the Heat Indicator

Locate: Heat Indicator

Procedure: Remove the nut from the Heat Indica-

tor first, then attach the Heat Indicator to the Grill

Lid using the nut as shown in Fig. 3.

Fig. 3

Fig. 5A

Step 5: Attach the Grease Tray

Locate: Grease Tray and Handle, (2) M6x12 bolts

Procedure:

Attach the Grease Tray Handle to the Grease

Tray using (2) M6x12 bolts as shown in Fig. 5A.

Slide the Grease Tray Assembly into the bottom

of the Firebox as shown in Fig. 5B.

Step 4: Attach the Lid Decorative Plate and

Lid Handle

Locate: Lid Decorative Plate, Lid Handle and (2)

M6x20 bolts

Procedure: Attach the Lid Decorative Plate and

Lid Handle to the Grill Lid using (2) M6x20 bolts

as shown in Fig. 4.

Fig. 5B

Step 4

Fig. 4

Assembly

Step 6: Attach the Wood Chip Box Rails

Locate: Wood Chip Box Left & Right Rails, (4)

M5x10 bolts

Procedure:

Push the Wood Chip Box Left Rail into the rectan-

gular hole in the Front Panel of the Firebox as

shown in Fig. 6A.

Attach the bracket of the Wood Chip Box Left Rail

to the left side of front panel using (1) M5x10 bolt

as shown in Fig. 6B.

Attach the Wood Chip Box Left Rail to the Rear

Panel of the Firebox using (1) M5x10 bolt as

shown in Fig. 6C.

Refer to Fig. 6A to Fig. 6C, attach the Wood Chip

Box Right Rail to the Firebox as shown in Fig. 6D.

Step 6

Fig. 6B

Fig. 6A

Fig. 6C

Fig. 6D

Assembly

Step 7 Step 7: Attach the Wood Chip Box Assembly

Locate: Wood Chip Box, Wood Chip Box Front

Panel Assembly, Wood Chip Box Lid, Wood Chip

Box Handle, Wood Chip Box Lock, Wood Chip

Box Tent, (2) M6x12 bolts, (2) M5x10 bolts and

(2) M5 nuts

Procedure:

Attach the Wood Chip Box Handle and Wood

Chip Box Lock to the Front Panel Assembly using

(2) M6x12 bolts as shown in Fig. 7A.

Attach the Wood Chip Box to the Front Panel As-

sembly using (2) M5x10 bolts and (2) M5 nuts as

shown in Fig. 7B.

Insert the Wood Chip Box Lid into the slots in the

Front Panel Assembly as shown in Fig. 7C.

Slide the Wood Chip Box Assembly into the Fire-

box as shown in Fig. 7D.

Position the Wood Chip Box Tent onto the Wood

Chip Box Assembly as shown in Fig 7E. Set onto

wood chip rails and push back into place.

Fig. 7A

Fig. 7C

Fig. 7D

Fig. 7B

Fig. 7E

Indice

Altri manuali Smoke hollow Griglia

Smoke hollow

Smoke hollow 30169G Istruzioni per l'installazione

Smoke hollow

Smoke hollow CG600S Manuale utente

Smoke hollow

Smoke hollow PT300B Guida

Smoke hollow

Smoke hollow LS2016-2B Manuale utente

Smoke hollow

Smoke hollow VT280B1 Manuale utente

Smoke hollow

Smoke hollow DG1100S Manuale utente

Smoke hollow

Smoke hollow 1800CGS Manuale utente

Smoke hollow

Smoke hollow SST18L Manuale utente

Smoke hollow

Smoke hollow SH9916 Manuale utente

Smoke hollow

Smoke hollow SH3020 Manuale utente

Smoke hollow

Smoke hollow SH2250K Manuale utente

Smoke hollow

Smoke hollow D4015SS Guida

Smoke hollow

Smoke hollow TC3718 Istruzioni per l'installazione

Smoke hollow

Smoke hollow 30160G Istruzioni per l'installazione

Smoke hollow

Smoke hollow 105 Manuale utente

Smoke hollow

Smoke hollow 2415PG Manuale utente

Smoke hollow

Smoke hollow 6500 Istruzioni per l'installazione

Smoke hollow

Smoke hollow SH7000 Supplemento

Smoke hollow

Smoke hollow DG850C Manuale utente

Smoke hollow

Smoke hollow PS9900 Istruzioni per l'installazione

Smoke hollow

Smoke hollow Deluxe Outdoor Grill & Smoker 8500 Manuale elenco delle parti

Smoke hollow

Smoke hollow WG800 Manuale utente

Smoke hollow

Smoke hollow 26142G Istruzioni per l'installazione

Smoke hollow

Smoke hollow 7000CGS Istruzioni per l'installazione

Manuali Griglia popolari di altre marche

Orbegozo

Orbegozo GR 2300 Manuale utente

bora

bora PT11 Manuale utente

Klarstein

Klarstein 10031664 Manuale utente

Garland

Garland MWE3W Manuale utente

Char-Broil

Char-Broil 463722714 Manuale utente

Nexgrill

Nexgrill 720-0830HK Manuale utente

Kenmore

Kenmore 415.16123800 Manuale utente

Camp Chef

Camp Chef PG24CLAU Manuale utente

Tucker Barbecues

Tucker Barbecues GTR Series Istruzioni per il montaggio

Monogram

Monogram ZGG540NCP1SS Manuale utente

Equipex

Equipex Sodir Savoy Manuale utente

Gaggenau

Gaggenau VR 414 610 Manuale utente

Miele

Miele KM 408-1 Manuale utente

George Foreman

George Foreman GGR50B Manuale utente

AOG

AOG T series Manuale utente

Gorenje

Gorenje TG2000CB Manuale di istruzioni

Weber

Weber Genesis Silver-B Permamount NG 051701 Manuale utente

Glen

Glen SA 3037 Manuale utente
