SNOWJOE Sunjoe SJEDGE7-RM Manuale utente

A Division of Snow Joe®, LLC Model SJEDGE7-RM Form No. SJ-SJEDGE7-RM-880E-M-V1

OPERATOR’S MANUAL

ELECTRIC EDGER + TRENCHER

12-AMP | 2-TOOLS-IN-1

A Division of Snow Joe®, LLC Model SJEDGE7-RM Form No. SJ-SJEDGE7-RM-880E-M-V1

OPERATOR’S MANUAL

ELECTRIC EDGER + TRENCHER

12-AMP | 2-TOOLS-IN-1

IMPORTANT!

Safety Instructions

All Operators Must Read These

Instructions Before Use

Always follow these safety guidelines. Failure to do so may

result in serious bodily injury or death.

General Safety

mWARNING! When using the electric edger + trencher,

basic safety precautions should always be followed to reduce

the risk of re, electric shock, and personal injury. These

include:

Work Area Safety

1. Keep work area clean and well-lit – Cluttered, dark

areas invite accidents.

2. Keep children, bystanders, and pets away – All

spectators, including pets, should be kept a safe distance

away from the work area.

3. Do not operate the electric edger + trencher in

explosive atmospheres – Such as in the presence of

ammable liquids, gases, or dust. Power tools create

sparks which may ignite the dust or fumes.

4. Avoid dangerous environments – Do not use appliances

in damp or wet locations. Do not use in rain.

Personal Safety

1. Stay alert – Watch what you are doing. Use common

sense. Do not operate the edger + trencher when you are

tired, or under the inuence of alcohol or drugs.

2. Dress properly – Do not wear loose clothing or jewelry.

They can be caught in moving parts. Rubber gloves,

long pants and substantial, non-skid footwear are

recommended when working outdoors. Do not go

barefoot or wear sandals. Wear protective hair covering to

contain long hair.

3. Avoid unintentional starting – Do not carry plugged-in

tool with nger on the trigger. Make sure the switch is o

before plugging in the tool.

4. Do not overreach – Keep proper footing and balance at

all times.

5. Use personal protective equipment – Always wear eye

protection. Protective equipment such as dusk mask, non-

skid safety shoes, hard hat, or hearing protection used for

appropriate conditions will reduce personal injuries.

Tool Use and Care

mWARNING! Don’t grasp the exposed cutting blades or

cutting edges when picking up or holding the appliance.

1. Do not force the tool – It will perform better with less

likelihood of personal or mechanical injury if it is used at

the rate for which it was designed.

2. Keep children and bystanders away – Children and

other spectators, including pets, should be kept at least

50 feet (15 meters) away from the work area.

3. Use safety glasses and other safety equipment –

Use safety goggles or safety glasses with side shields,

complying with applicable safety standards and, when

needed, a face shield. Also use face or dust mask if

operation is dusty. This applies to all persons in the work

area. Also use a hard hat, hearing protection, gloves,

safety shoes and dust collection systems when specied

or required.

4. Use the right tools – Do not use tools for any job except

that for which they are intended.

5. Store idle tools indoors – When not in use, tools should

be stored indoors in a dry and high or locked-up place out

of the reach of children.

6. Do not abuse the cord – Never carry the tool by the cord

or yank the cord to disconnect it from the receptacle.

Keep cord away from heat, oil, and sharp edges.

7. Do not force the tool – It will do the job better and with

less likelihood of injury if it is used at the rate for which it

was designed.

8. Disconnect the tool – Disconnect the appliance from the

power supply when not in use, before servicing, and when

changing accessories such as blades and the like.

9. Maintain tools with care – Keep cutting edge clean for

best performance and to reduce the risk of injury. Follow

instructions for lubricating and changing accessories.

Inspect appliance cord periodically and if damaged, have

it repaired by authorized service facility. Inspect extension

cords periodically and replace if damaged. Keep handles

dry, clean, and free from oil and grease.

10. Check for damaged parts – Before further use of the

appliance, a guard or other part that is damaged should

be carefully checked to determine that it will operate

properly and perform its intended function. Check for

alignment of moving parts, binding of moving parts,

breakage of parts, mounting, and any other conditions

that may aect its operation. A guard or other part that

is damaged should be properly repaired or replaced by

an authorized service center unless otherwise indicated

elsewhere in this manual.

11. Use of accessories and attachments – The use of any

accessory or attachment not recommended for use with

this appliance could be hazardous. Note: Refer to the

accessory section of this manual for further details.

Additional Warnings for Edger + Trencher

1. Keep guard in place.

2. Keep blade area clean.

mDANGER! Risk of injury. Keep hands and feet away

from blade and cutting area.

Important Warning:

When using the edger + trencher, stones, pieces of metal

and other objects can be thrown out at high speed by the

blade. The tool and guard are designed to reduce the danger.

However, the following special precautions should be taken:

1. Wear safety glasses or other eye protection, gloves, long

pants and substantial footwear.

2. Make sure that other persons and pets are at least 100 ft.

(30.5 m) away.

3. Always stand to left side of main handle.

4. Before Landscaping or Trenching, check for buried

electrical cables.

5. To reduce the risk of rebound (ricochet) injury, work going

away from any nearby solid object such as a wall, steps,

large stone, tree, etc. Use great care when working close

to solid objects or into the wind, and, where necessary, do

edging or trimming by hand.

Electrical Safety

1. Ground fault circuit interrupter (GFCI) protection should

be provided on the circuit(s) or outlet(s) to be used for

this electric edger + trencher. Receptacles are available

having built-in GFCI protection and may be used for this

measure of safety.

2. To reduce the risk of electric shock, this appliance has a

polarized plug (i.e. one blade is wider than the other). Use

this appliance only with a polarized UL-, CSA-, or ETL-

listed extension cord recommended for outdoor,

all-weather use, such as the Snow Joe®+ Sun Joe®

SJTW-A 14-gauge 50-foot extension cord with lighted

end (Model PJEXT50-B). Visit sunjoe.com to purchase

this extension cord online or, to order by phone, call

1-866-SNOWJOE (1-866-766-9563).

The appliance plug will t into a polarized extension

cord only one way. If the appliance plug does not t

fully into the extension cord, reverse the plug. If the plug

still does not t, obtain a correct polarized extension

cord. A polarized extension cord will require the use of a

polarized wall outlet. The extension cord plug will t into

the polarized wall outlet only one way. If the plug does

not t fully into the wall outlet, reverse the plug. If the plug

still does not t, contact a qualied electrician to install

the proper wall outlet. Do not modify the appliance plug,

extension cord receptacle, or extension cord plug in any

way.

3. To prevent electric shock, use only with an extension cord

suitable for outdoor use, such as SW-A, SOW-A, STW-A,

STOW-A, SJW-A, SJOW-A, SJTW-A, or SJTOW-A.

Before use, check that the extension cord is in good

condition. When using an extension cord, make sure to

use one heavy enough to carry the current your product

will draw. An undersized cord will cause a drop in line

voltage resulting in loss of power and overheating.

Extension Cord

Length

Wire Gauge (A.W.G.):

Up to 50 ft

(15 m)

+50 ft - 100 ft

(+15 m - 30 m)

14 12

mWARNING m

Electric shock may cause SEVERE INJURY or

DEATH. Heed these warnings:

• Do not allow any part of the electric edger + trencher

to make contact with water while it is in operation. If

the appliance becomes wet while turned o, wipe dry

before starting.

• Use only a UL-, CSA-, or ETL-rated extension cord

for outdoor, all-weather use, such as the Snow Joe®+

Sun Joe® SJTW-A 14-gauge 50-foot extension cord

with lighted end (Model PJEXT50-B).

Visit sunjoe.com to purchase this extension cord

online or, to order by phone, call 1-866-SNOWJOE

(1-866-766-9563).

• Do not use an extension cord over 100 ft (30 m).

• Do not touch the appliance or its plug with wet hands

or while standing in water. Wearing rubber boots

oers some protection.

EXTENSION CORD CHART

4. To prevent the appliance cord from disconnecting from

the extension cord during operation, use the onboard

extension cord restraint hook and/or make a knot with the

two cords as shown in Table 1.

5. Do not abuse the cord. Never pull the edger + trencher

by the cord or yank the cord to disconnect it from the

receptacle. Keep the cord away from heat, oil, and sharp

edges.

Double-Insulated Appliances

In a double-insulated appliance, two systems of insulation

are provided instead of grounding. No grounding means is

provided on a double-insulated appliance, nor should a means

for grounding be added to the appliance. Servicing a double-

insulated appliance requires extreme care and knowledge

of the system, and should be performed only by qualied

service personnel at an authorized Snow Joe®+ Sun Joe®

dealer. Replacement parts for a double-insulated appliance

must be identical to the parts they replace. A double-insulated

appliance is marked with the words “Double Insulation” or

“Double Insulated.” The symbol (square within a square)

may also be marked on the appliance.

DOUBLE-INSULATED: GROUNDING NOT

REQUIRED. WHEN SERVICING, USE ONLY

IDENTICAL REPLACEMENT PARTS.

This electric edger + trencher is double-insulated, eliminating

the need for a separate grounding system. Use only identical

replacement parts. Read the instructions before servicing

double-insulated appliances. Use this electric edger + trencher

only as described in this manual.

Service

1. If your electric edger + trencher requires service,

contact an authorized Snow Joe®+ Sun Joe®dealer or

call the Snow Joe®+ Sun Joe®customer service center

at 1-866-SNOWJOE (1-866-766-9563). Only identical

replacement parts should be utilized for repairs. This will

ensure that the safety of the power tool is maintained.

(B) Connect plug and receptacle

Cord set Appliance cord

(A) Tie cord as shown

Table 1. Method of Securing Extension Cord

Safety Symbols

The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all

instructions on the machine before attempting to assemble and operate.

READ THE OPERATOR'S

MANUAL(S) – Read,

understand, and follow

all instructions in the user

manual(s) before attempting to

assemble and operate.

SAFETY ALERT – Indicates

a precaution, a warning, or

a danger.

Immediately remove the plug

from the mains if the power

cable is damaged, frayed, or

entangled. Always keep the

power cable away from heat,

oil and sharp edges.

DANGER! Beware of thrown

objects to bystanders. Keep

bystanders at least 100 ft (30.5 m)

away from the machine.

DOUBLE INSULATION –

When servicing, use only

identical replacement parts.

WARNING! Do not expose the

unit to rain or wet conditions.

WEAR EYE AND HEARING

PROTECTION – For protection

against injury, wear ear

defenders and safety goggles.

Keep bystanders and children

a safe distance away.

Symbols SymbolsDescriptions Descriptions

Wear safety gloves during

use to protect hands.

Wear non-slip footwear that will

protect your feet and improve

your footing on slippery surfaces.

Beware of ying objects

and debris.

WARNING! Turn the machine

OFF and disconnect it from the

power supply before inspecting,

cleaning, changing accessories,

or conducting any other

maintenance task.

1. Handle

2. Trigger switch

3. Extension cord restraint hook

4. Auxiliary handle knob

5. Auxiliary handle

6. Telescopic shaft

7. Appliance cord

8. Telescopic shaft adjustment knob

9. Back wheel (2)

10. Blade cut cover

11. Steel blade

12. Motor housing

13. Height adjustment knob

14. Front guide wheel

Know Your Electric Edger + Trencher

Read the owner’s manual and safety instructions carefully before operating the electric edger + trencher. Compare the illustration

below to the electric edger + trencher in order to familiarize yourself with the location of the various controls and adjustments.

Save this manual for future reference.

Technical Data

Rated Voltage ....................................................... 120 V ~ 60 Hz

Power ....................................................................................12A

No Load Speed ............................................................4500 rpm

Blade Diameter.................................................. 7.3 in. (18.5 cm)

Adjustable Cutting Depth ..................... 0.43 in. | 0.75 in. | 1.2 in.

(11 mm | 19 mm | 30 mm)

Cutting Width ..................................................... 0.1 in. (2.5 mm)

Telescopic Shaft .................................................... 2.5 ft to 2.9 ft

(76.5 cm to 88.5 cm)

Wheel Size........................................Back wheel: 6.3 in. (16 cm)

Front guide wheel: 2.9 in. (7.4 cm)

Weight .............................................................. 14.8 lbs (6.7 kg)

Unpacking

Carton Contents

• Edger + trencher motor housing

with lower shaft bolt and nut

• Telescopic shaft adjustment knob and bolt

• Auxiliary handle

• Auxiliary handle knob + bolt

• Wrench

• Spanner

• Manual with registration card

1. Carefully remove the electric edger + trencher and check

to see that all of the above items are supplied.

2. Inspect the product carefully to make sure no breakage or

damage occurred during shipping. If you nd damaged or

missing parts, DO NOT return the unit to the store. Please

call the Snow Joe®+ Sun Joe®customer service center at

1-866-SNOWJOE (1-866-766-9563).

NOTE: Do not discard the shipping carton and packaging

material until you are ready to use the electric edger +

trencher. The packaging is made of recyclable materials.

Properly dispose of these materials in accordance with

local regulations or save the packaging for long-term

product storage.

IMPORTANT! The equipment and packaging material are not

toys. Do not let children play with plastic bags, foils, or small

parts. These items can be swallowed and pose a suocation

risk!

Assembly

Assembling the Handle

1. Slide the lower shaft down into the motor housing and

align the screw holes (Fig.1).

2. Secure the telescoping shaft with the bolt and nut (Fig. 2).

NOTE: When you rst insert the bolt it may be necessary

to wiggle it carefully to get it past the jacketed wire inside

the tube.

mCAUTION! NEVER use a sharp object to move jacketed

wires out of the way.

Adjusting the Telescopic Shaft

The telescopic shaft can be set at three dierent heights.

1. To set the height for your comfort, slide the telescopic

shaft up to the level required using one of the three holes

provided.

2. Insert the bolt through the hole and tighten the knob fully

locking the two shafts in place (Fig. 3).

NOTE: When rst assembling the shaft to the trencher

+ edger, the shafts should be pulled fully up to allow the

cord to sit correctly in the tubes and motor housing.

Assembling Auxiliary Handle

1. Assemble the auxiliary handle onto the main handle by

inserting the bolt into the auxiliary handle and tightening

the handle with the auxiliary handle knob provided (Fig. 4).

Fig. 1 Lower shaft

Motor housing

Fig. 2

Bolt Nut

Telescoping shaft

Fig. 3

Telescopic shaft

adjustment knob

Bolt

Upper

shaft

Lower

shaft

Fig. 4

Auxiliary handle knob

Handle

Bolt

Auxiliary

handle

Operation

Cutting Depth Adjustment

The front guide wheel can be adjusted to allow a deeper or

shallower cut, and to increase the life of the blade. The edger

can be adjusted to edge at three dierent depths.

mDANGER! Risk of personal injury. Never attempt to

adjust the depth while the edger is running. Always unplug

edger before making any adjustments.

1. To adjust the depth of the cut, loosen the height

adjustment knob on the front of the edger + trencher

(Fig. 5).

2. Push front guide wheel to the left, then raise or lower the

arm to the desired depth setting (Fig.6).

3. Push in the front guide wheel arm, check to ensure the

front guide wheel arm has located into any of the pre-

allocated positions. Ensure the head of the bolt securing

the front guide wheel arm is resting at on the surface of

the wheel arm (Fig. 7).

4. Retighten the height adjustment knob securely (Fig. 7).

Operation

Securing the Extension Cord

1. Make a loop with the extension cord (Fig. 8).

2. Insert the loop through the opening in the back of the

handle (Fig. 8).

Fig. 5

Height

adjustment

knob

Fig. 6

Push to the left

then adjust up

or down

Front guide

wheel arm

Fig. 7

Height

adjustment

knob

Fig. 8

Extension cord

Handle

3. Secure the loop onto the extension cord restraint hook

then connect the extension cord to the appliance cord

(Fig. 9).

mCAUTION! Always wear eye protection.

Cord Routing

• Always keep the extension cord away from the area being

edged. Make sure the extension cord is behind the edger.

• If you cut or damage the cord, unplug it immediately. After

cord is unplugged, inspect it for damage and replace cord if

necessary.

Starting + Stopping

The electric edger + trencher is tted with a safety lock button

and a trigger switch to prevent accidental operation of the tool.

mCAUTION! The edger + trencher blade coasts after the

unit is turned o. Keep hands away from blade.

1. Before you start the unit, tilt the edger + trencher on back

wheel to ensure blade is not in contact with the work

surface.

2. Hold the edger + trencher rmly with both hands before

turning on.

3. To turn the edger + trencher ON, press and hold the safety

lock button with your thumb, then squeeze the ON/OFF

trigger switch with your ngers. Once the machine powers

on, you can release the safety button and proceed with

operation (Fig. 10).

4. To switch OFF, release the ON/OFF trigger switch (Fig. 10).

mCAUTION! Do not force the trigger switch without rst

pressing the safety lock button.

mCAUTION! Do not tie or jam the trigger switch in the ON

position. The trigger switch is designed to be held in the ON

position by your hand only.

mWARNING! Take care when you turn the edger +

trencher ON that the cutter is in a safe position to operate.

NOTE: When a switch is released, a short spark may appear

from the engine. This is normal, and not a cause for concern.

The spark is caused by the braking system that is built into the

product.

mCAUTION! If the edger + trencher becomes jammed or

stalled on a branch, sticks, or other foreign object, release the

trigger immediately. Failure to stop the unit when the unit jams

may cause excessive damage to the unit’s motor. Always wear

eye protection when using the unit.

Edging Techniques

NOTE: The edger + trencher is a major appliance and should

not be operated simultaneously with other major appliances on

the same household circuit.

mCAUTION! Make sure that other persons and pets are

at least 100 ft (30.5 m) away.

mWARNING! Do not use the edger + trencher on wet

growth or in the rain.

mCAUTION! To prevent injury, keep hands away from

trigger when clearing jams. To prevent injury, do not use the

edger + trencher with any damaged parts.

1. Set cutting depth. Refer to Cut Depth Adjustment

instructions on v 7.

2. To avoid kickback of the edger, tilt the handle down so the

blade is above the ground.

3. Turn switch on and allow blade to spin without moving the

tool.

4. Slowly lift the handle to lower the blade. Then, begin to

move tool forward slowly, being careful not to strike the

edge of the paved surface.

For the rst edging each season, it is best to move forward

slowly because grass is thickest then. Subsequent edging will

be completed more rapidly.

If the tool slows down, back it up slightly until the blade

returns to normal speed. During edging some sparks may be

generated from hitting stones, this is normal. Do not attempt

to edge when the grass or soil is wet or moist - for electrical

safety and to prevent clogging of the blade chamber.

Fig. 9

Extension cord

restraint hook

Extension

cord

Appliance

cord

Fig. 10

Trigger switch

Safety lock button

mWARNING! If you must edge under conditions that

cause the blade chamber to become clogged, release trigger,

and wait for blade to come to complete stop! Unplug the

tool and remove clogged material with a stick. To continue to

operate the tool in a clogged condition will seriously overload

the motor.

mCAUTION! Do not attempt to unclog the blade chamber

by dropping or tapping the tool on the ground. This can

damage the unit. Keep hands clear of

and blade when cleaning as these wear to a very sharp point

during edging.

Landscaping + Trenching

Before landscaping or trenching, inspect and ensure there are

no exposed or buried cables or pipes or other objects that may

create a hazard or interfere with operating the edger.

Set depth to only that required for the job, do not overload, if

tool slows, pull back slightly and wait until the blade returns to

normal speed.

Application

Changing the Blade

mWARNING! Prior to attempting to perform any

maintenance which includes the changing of the blade, ensure

the power supply cord has been totally disconnected from the

main supply.

mWARNING! Wait for blade to come to complete stop!

Position the edger + trencher on its side with the blade

upwards. Ensure the surface you are working on is clean and

foreign particles (stones, etc.) cannot enter the air intake slots

of the motor housing.

1. Place the large ange spanner over the outer blade ange

(Fig. 11).

2. Fit the blade spanner over the blade lock nut and while

holding rmly the spanner on the blade ange, rotate the

locking nut in counterclockwise direction (Fig. 11).

3. Remove the lock nut counterclockwise along with the

outer ange and blade (Fig. 11).

4. There is no need to remove the inner ange, although on

reassembly the area of the inner ange must be free of

foreign particles (dirt, etc.).

5. To reassemble with a new blade t the inner ange on to

the spindle, t the replacement blade and secure the outer

ange on to the spindle and blade (Fig. 12).

6. Ensure the assembly is correct and the blade is correctly

orientated (Fig. 12).

7. With the spanner tted to the outer ange, t the locking

nut and tighten with the blade spanner in a clockwise

direction (Fig. 13).

8. After the blade is secure, rotate the blade by hand

to ensure the blade is not making contact with any

components of the edger.

9. Blade wear is expected whenever you use your edger.

10. The blade wears quite quickly when edging along concrete

paths. This does not aect the eciency of the edger and

is expected due to the aggressive abrasion of concrete on

steel.

NOTE: To increase blade life, keep initial cutting depth at

minimum and increase depth setting as blade wears.

Fig. 11

Outer blade

ange

Blade

Large

ange

spanner

Blade spanner

Lock nut

Fig. 12

Outer blade ange

Lock

nut

Inner blade ange

Blade

Fig. 13

Outer blade

ange

Blade

Large

ange

spanner

Blade spanner

Lock nut

Indice

Altri manuali SNOWJOE Bordatore

SNOWJOE

SNOWJOE Sunjoe SJEDGE7 Manuale utente

Manuali Bordatore popolari di altre marche

Ryobi

Ryobi EXPAND-IT RYEDG12VNM Manuale utente

VEVOR

VEVOR ASYTM02230 Manuale utente

CRL

CRL SM5C Manuale utente

Ryobi

Ryobi RED1220 Manuale utente

Kunzle & Tasin

Kunzle & Tasin SILVER BACK Manuale

Scotts

Scotts S20300 Manuale utente

Husqvarna

Husqvarna LE475 Manuale utente

Echo

Echo PE-230 Manuale utente

Mantis

Mantis Edger Manuale utente

Echo

Echo PE-225 Manuale utente

MTD

MTD 520 Series Manuale utente

RedMax

RedMax HEZ2602S Manuale utente

Craftsman

Craftsman 247.772461 Manuale utente

Ryobi

Ryobi RED1850Li40 Manuale utente

Clarke

Clarke Super E Manuale utente

MTD

MTD 244-595-000 Manuale utente

Husqvarna

Husqvarna 426EX Manuale utente

MTD

MTD 24596B Manuale utente
