SoftBank 002SH Manuale utente

7-1

Getting Started

Camera

Capture still images or record video.

Getting Started

Detect Personal & Pet

Locks focus on the face of a person or pet.

information appears in Viewfinder upon

face detection.

Select Camera

Continuous AF

Focus continuously adjusts as the

framed subject's position changes.

Album

Sort saved images into up to 500 albums;

create original albums as needed.

002SH is loaded with preset camera

modes tailored for various purposes/

occasions; select a camera mode to

suit subject/shooting conditions.

Important Mobile Camera Usage Notes

.Clean dust/smudges from lens cover with

soft dry cloth before use.

.Mobile camera is a precision instrument,

however, some pixels may appear

brighter or darker.

.Shooting/saving images while handset is

hot may affect the image quality.

Exposing lens to direct sunlight may

damage color filter and affect image color.

Auto Shut-off

.Before image capture/recording, mobile

camera shuts down after a period of

inactivity and handset returns to Standby.

Shutter Click

Shutter click and Self-timer tone sound at

fixed volume regardless of handset settings.

Getting Started

7-2

Focus modes and sizes shown beloware defaults; those with *are fixed.

Photo Camera & Video Camera Overview

Select one according to subject/shooting conditions

Normal(Face)*14M

Capture sepia images Normal(Face)*14M

Capture images in low light (fireworks, night

scenes, etc.) Normal(Face)*14M

Capture black and white images Normal(Face)*14M

Scene Cameras

Sepia Camera

LongExposure Camera

Monochrome Camera

Improve text readability in captured memos,

tables, etc. Center Auto Focus*5M

Show mock Clock/Calendar in Viewfinder to

capture image and set it as Wallpaper Normal(Face) Wallpaper*

Capture and send images via mail easily Normal(Face)*VGA

Capture and post images to blogs easily Normal(Face) VGA

Use guide to capture multiple images for

posting on auction sites Center Auto FocusVGA

Shot Memo Camera

Wallpaper Camera

MessagingCamera

BlogCamera

Auction Camera

Standard

Shooting

Subject

Conditions

Specific

Objectives

Description Focus Mode Size

Easy Auto Camera Capture nearby subjects easily (settings

partially changeable)

Quick Camera Capture distant scenery quickly

Pro Auto Camera Capture nearby subjects easily (settings mostly

changeable)

Normal(Face)*

Manual Focus*

Normal(Face)

14M

7-3

Getting Started

Consecutive

Shooting

Full HD

Best Select Photo

Select best image from a series of rapid shot images

including moments immediately before shutter releases

Center Auto Focus QVGA

14M

Fun

Cameras

Fish-eye Camera Capture images with enhanced barrel distortion

as if shot with full-frame horizontal fisheye lens Center Auto Focus*3M

Miniaturize Camera Capture images of scenery, etc. that resemble

miniature models as if shot with a tilt-shift lens Center Auto Focus*5M

Drawable Camera Drag on captured image to scribble or sketch Normal(Face)*Wallpaper

Auto Shutter

Release

Look Back Camera

Self Timer Camera

Smile Camera

Description Focus Mode Size

Play sound and release shutter automatically

when subject turns face to camera 14M

Release shutter automatically after selected

time elapses Normal(Face)*14M

Release shutter automatically when subject

smiles Normal(Face)*14M

Normal(Face)*

Rapid ShootingCamera Capture up to 100 images rapidly

Three-Shot Camera Capture three consecutive images of up to 14M

size automatically

Normal(Face)

Getting Started

7-4

Camera-in-Use Light

LED beside the lens flashes red while mobile camera

is active. LED illuminates red while recording video.

Pro Auto Video Camera

Description Focus Mode Size

Golf SwingVideo Camera

Record and check golf swing ーWide*

Video Camera for Mail

Record small video easily to send it via mail Normal(Portrait) QCIF

Additional

Cameras

Pretty Arrange Camera To uch up faces in captured images Normal(Face)*5M

Face Register Camera Register name and note for faces Normal(Face)*VGA*

Self Portrait Camera Use guide to capture self portraits Normal(Face)*5M

HD Video Camera Record long high quality video Normal(Portrait) HD*

Pro Auto Video Camera Record video with more customizable options Normal(Portrait) HD

Video Camera

Camera-in-Use Light

7-5

Photo Camera

(Landscape Display Touch Panel Operations)

Followthese steps to capture someone's

image via Pro Auto Camera:

2Rotate Display to Viewer

position

3Tap SSwipe to select

Pro Auto Cam

4Tap Pro Auto Camera

.Pro Auto Camera activates.

5Frame subject on Display

Photo Viewfinder

(face detected)

.Focus is locked on the face of a

detected person or pet automatically

for Pro Auto Camera, Easy Auto

Camera, etc. (Face auto focus)

,When multiple faces are detected,

frame appears on each face; tap

one on which to lock focus.

,Detection may fail depending on

face angle, distance from subject or

environment.

.To use Detect Personal, first register

a face with a name, etc. If camera

detects registered face, saved name,

etc. appears in Viewfinder; handset

automatically sorts saved images to

designated folder (Portrait & Pet).

,Camera cannot detect registered

faces and pets at the same time.

Captured Image Window

Shutter clicks; captured image appears.

7Tap

.Image is saved. (Viewfinder returns.)

.Open saved images via Album or

Data Folder.

8Tap END SCamera shuts

down

Capturing Still Images

Viewer Position

Mobile Light

.Mobile Light may illuminate automatically

depending on ambient light level or

camera mode. Followthese steps to turn

setting off:

[Photo Viewfinder] Tap STap

twice

,May require access via MENU

depending on camera mode.

Photo Camera

7-6

Indicators appear on Display. Tap one to

adjust the corresponding setting or

execute the assigned command.

Indicators vary by camera mode.

[Additional Operations

Ta p MENU for more functions/settings.

(Portrait Display Handset Key Operations)

Followthese steps to capture distant

scenery via Quick Camera:

.Photo Viewfinder appears.

2ASQuick Cam S%

3Frame subject on Display

.Faces are not detected automatically

for Quick Camera. For close-up

portrait shots, press !and use e

to adjust focus, then press %.

(Manual Focus)

.Shutter clicks; captured image is

saved. (Viewfinder returns.)

.Open saved images via Album or

Data Folder.

5"SCamera shuts down

Pre-Image Capture Operations

(Touch Panel)

1Self-timer 6Switch cameras

2Mobile Light 7MENU

3To g g l e

indicator view8Exit

4Scene 9Release shutter

5Picture Size

Toggling Indicator View

[Photo Viewfinder] Tap

Zoom In/Out Drag up or down across


Adjust

Brightness

Drag left or right across


Focus Lock Tap image

Opening Help

[Photo Viewfinder] Tap MENU STap

Help twice

Clamshell Open

Mobile Light

.Mobile Light may illuminate automatically

depending on ambient light level or

camera mode. Followthese steps to turn

setting off:

[Photo Viewfinder] BSMobile

Light S%SOff S%

7-7

Photo Camera

Press Bto open Options menu for more

functions/settings.

Lock focus on subject; camera continuously

focuses on the subject even if it moves.

Chase Focus tracks the subject's movement,

and Continuous AF adjusts focus as the

distance to the subject changes.

.May be unavailable depending on camera

mode.

1In Photo Viewfinder, frame

subject in center of Display

Half press and hold

tap subject

.Focus Lock is set.

.To cancel, release Ior tap subject

again.

.Captured image appears.

.Tap or OK to return to Viewfinder.

002SH Picture Size & Corresponding Usage:

Pre-Image Capture Operations

(Handset Keys)

Zoom In/Out a/b

Adjust Brightness c/d

Toggle Mobile Light Mode #

Toggle Indicator View )

Open Help 0

Focus Lock

Using Handset Keys

[Photo Viewfinder] Frame subject in

center of Display S!S%

,To cancel Focus Lock, press !again

before pressing %.

Chase Focus

.Camera distinguishes the subject by

color; light-colored subjects or subjects

having the same color as the background

may not be tracked correctly.

Image Size & Usage

14M A3 prints

10M B4 prints

5M B5 prints

3M L to 2L prints

Full HD Full HD display wallpaper

Wallpaper 002SH Wallpaper

VGA Blog posts, etc.

QVGA Mail attachments, etc.

Smart Resize Zoom

.At 14M(Smart Resize), Picture Size

changes with zoom scale (print quality

may be affected); check the size on

indicator before image capture.

Photo Camera

7-8

(Landscape Display Touch Panel Operations)

1In Photo Viewfinder, tap

camera selection indicator

(,etc.)

2Swipe to select camera

3Tap camera

.Selected camera activates.

.For subsequent operations, see

"Using Selected Camera."

(Landscape Display Touch Panel Operations)

[Rapid Shooting Camera

1Tap

2Tap mode twice

3Frame subject on Display

.After image capture, thumbnails

appear.

4Tap

5Tap Save

.Save process may take some time

depending on the number of

captured images. If a confirmation

appears, tap Yes, then tap OK.

.Saved images appear in Data Folder

(Pictures > Shooted Pics).

Selecting Camera by Use

Switching Cameras Using Selected Camera Shooting Manually

After 3, press Ifor each frame S

From 4

Saving Selected Images

After 3, tap image ( ) STap Save

Using Photo Recommender

.Followthese steps to save an image from

recommended images (automatically

selected in terms of Face, Move,

Sharpness and Macro, one for each).

After 3, tap STap image ( ) S

Tap Save

Creating Strobe Photo (Composite Image)

After 3, tap STap Yes STap OK

,Tap to save.

,May be unavailable depending on rapid

shooting mode.

7-9

Photo Camera

[Look Back Camera

1Frame subject on Display S

Tap , or

.Sound plays.

2Face detection activates

and shutter releases;

image appears

3Tap OK

.Viewfinder returns.

[Smile Camera

1Frame subject on Display

2Smile detection activates

and shutter releases;

image appears

3Tap OK

.Viewfinder returns.

[Self Timer Camera

1Frame subject on Display

.Countdown starts.

2Shutter releases after

approximately ten seconds;

image appears

3Tap OK

.Viewfinder returns.

[Wallpaper Camera

1Frame subject on Display

.Wallpaper previewappears.

2Tap Setting

.Image is set as Wallpaper.

(Viewfinder returns.)

[Auction Camera

1Frame subject on Display

.First previewimage appears.

2Tap

Repeat

to capture two more

images following onscreen instructions.

3Tap Yes

[Messaging Camera

1Frame subject on Display

2Tap

.Mail Composition windowopens.

Complete and send message.

[Shot Memo Camera

1Frame subject on Display

2Tap SCorrection starts

SSwipe to select preview

image STap Apply

3Tap

.Viewfinder returns.

Photo Camera

7-10

[Pretty Arrange Camera

1Frame subject on Display

2Tap

.Face is touched up.

.To cancel, tap .

3Tap Apply STap

.Viewfinder returns.

[Self Portrait Camera

Activate Self Portrait Camera with handset

open and followthese steps:

Turn handset upside down

Rotate Display

180 degrees

Tap OK

3Frame your face on

Display and look into

the lens

4Face detection activates,

tones sound, and shutter

releases; image appears

5Tap OK

.Viewfinder returns.

[Additional Cameras

Adjusting Each Effect Separately

After 2, tap corresponding indicator

( , etc.)

,Tap the same indicator repeatedly for

further adjustment.

When Multiple Faces are Detected

.After 2, tap to touch up all faces. To

touch up select faces, followthese steps:

Tap frame ( ) STap S3

Three-Shot

Camera

Frame subject on Display

SISTap image S

Tap Save

To save all images or use

Photo Recommender,

see

P. 7 - 8

"Rapid

Shooting Camera."

Best Select


Scene

Cameras

Frame subject on Display

Monochrome

Camera

Sepia Camera

Miniaturize

Camera

Fish-eye

Camera

Long Exposure

Camera

Frame subject on Display

Shutter is left open for

approximately 30 seconds

before image capture.

Blog Camera

Frame subject on Display

SISTap S

Proceed with blogging

Drawable

Camera

Frame subject on Display

SISTap SDrag

on image STa p Assign

STap Save as New or

Overwrite

.For Save as New, follow

onscreen instructions.

Altri manuali per 002SH

Indice

Altri manuali SoftBank Telefono cellulare

SoftBank

SoftBank 101K Manuale utente

SoftBank

SoftBank 301P Manuale utente

SoftBank

SoftBank 815SH Manuale utente

SoftBank

SoftBank 003Z Guida utente

SoftBank

SoftBank SoftBank 106SH Manuale utente

SoftBank

SoftBank 708SC Manuale utente

SoftBank

SoftBank 912T Manuale utente

SoftBank

SoftBank 940SH Manuale utente

SoftBank

SoftBank 812SH s II Istruzioni e ricette

SoftBank

SoftBank 812SH s II Manuale utente

SoftBank

SoftBank 931sc Manuale utente

SoftBank

SoftBank 830T Manuale utente

SoftBank

SoftBank 943SH Manuale utente

SoftBank

SoftBank X02HT Manuale operativo e di manutenzione

SoftBank

SoftBank 831SH Manuale utente

SoftBank

SoftBank 002P Manuale utente

SoftBank

SoftBank 931sc Manuale utente

SoftBank

SoftBank 911T Manuale utente

SoftBank

SoftBank 932SH Manuale utente

SoftBank

SoftBank 009Z Manuale utente

SoftBank

SoftBank 002P Manuale utente

SoftBank

SoftBank 005SH Istruzioni per il montaggio

SoftBank

SoftBank 910SH Manuale utente

SoftBank

SoftBank 840N Manuale utente

Manuali Telefono cellulare popolari di altre marche

Zte

Zte BLADE A520 Manuale utente

Nokia

Nokia Lumia 620 Manuale utente

Blackbe;rry

Blackbe;rry KEYone Manuale utente

Bea-fon

Bea-fon X5 Premium Manuale utente

Blackbe;rry

Blackbe;rry 8707 Series Manuale utente

Blackbe;rry

Blackbe;rry Storm Istruzioni operative

LG LM-X420QN Manuale utente

LifeWatch

LifeWatch V Manuale utente

Bea-fon

Bea-fon SILVER LINE SL860 Manuale utente

IKI Mobile

IKI Mobile KF4.5i Manuale utente

Hitech

Hitech HT-850 Manuale utente

Yezz

Yezz Fashion F10 Manuale utente

Point Mobile

Point Mobile PM60 Manuale utente

Blackbe;rry

Blackbe;rry Q10 Manuale utente

Blackbe;rry

Blackbe;rry Bold 9900 Manuale utente

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuale utente

LG LM-K420EMW Manuale utente

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale utente
