SOLAR VISION LX25 Manuale utente
installation ManUal
LX commerciaL soLar Lighting FiXtUre
Solar Vision inc. www.solar-vision.ca info@solar-vision.ca T. 1-819-729-0450
Revision 4.0
IMPORTANT NOTES:
• Alwaysinstallthelightingxtureonthepolebeforeinstallingthebattery.
• Thelightingxtureshouldneverbehandledwithbatteryinstalledinside.
• Thebatterycompartmentcontainsa“quickconnector”toconnectthebattery.
STEP 2, 3, 4, 5
STEP 6 STEP 7
Indicator lights
INSTALLATION
1. Usingthesuppliedboltsandhardware,fastenthebatterycom-
partmenttothesolarmoduleasindicatedontheimage#1.Orien-
tationofthebatteryboxiscritical.
2. Installthelightingxtureonapolewithanouterdiameterof:
• 102mm(4in)LX25&LX50(squareorroundsleeve);
• 127mm(5in)LX95(squaresleeveonlyontheLX95);
3. Usetheproperdrillingpattern(4inor5in)attheendofthisdocu-
ment.
4. Slidethelightingxtureontopofthepole;
5. Usethe1/4”-20bolttosecuretheluminairetothepole,thedrilling
patternisattheendofthisdocument;
6. Oncethelightisinplace,openthebatteryboxdoorandinsertthe
battery.
7. Makeaquickconnectionwiththequickconnectcable;
8. Agreenindicatorlightindicatesthattheluminaireisfunctionnal.
9. Closethebatteryboxdoor,theinstallationisnowcomplete.
LEARNING DELAY
Thelightrequiresa24-hourdelaytooperateproperlyaccordingtoit’s
program.
Image #1 (step #1)
P.1/5
installation ManUal
LX commerciaL soLar Lighting FiXtUre
Solar Vision inc. www.solar-vision.ca info@solar-vision.ca T. 1-819-729-0450
Revision 4.0
Solar Module
Orientation Period Autonomy
losses
South
(≈optimal)
Annual 0%
Summer 0%
Winter 0%
East / West
Annual -17%
Summer -9.8%
Winter -28%
North
Annual -35.8%
Summer -21.6%
Winter -54.8%
ORIENTATION AND AUTONOMY 1.1 INSTALLATION GUIDELINES
Toavoidalossofautonomyandamalfunction:
• Theluminairemustbeinstalledhorizontallyandmustneverbetilted;
• Theluminairemustbeinstalledattheendofthepost;
• The luminaire must be installed in an open space with no trees or
structuresnearby,thiscouldfavoursnowaccumulationandshading;
• Thesolarmodulemustbeideallyorientedtowardsthesouth,other-
wiseseetable“ORIENTATIONANDAUTONOMY”.
Failingtofollowtheserecommendationscanresultinlossofsystemper-
formance.
FACTORSAFFECTINGAUTONOMY:
Lackofsunshine,verylowambienttemperature,snowaccumulationdue
totreesorstructuresnearby,shadingduetonearbytreesorstructures,
solarmoduleorientation(seetable),toomanyunplannedoccupancyde-
tections(road,unusualactivitiesandevents),sunshinebelowthemonthly
averages,timedelaytoohighontheoccupancysensor.
P.2/5
installation ManUal
LX commerciaL soLar Lighting FiXtUre
Solar Vision inc. www.solar-vision.ca info@solar-vision.ca T. 1-819-729-0450
Revision 4.0
1.2 STORAGE AND HANDLING:
Ifyouwishtostoretheluminaire,thebatteryneedstoberechargedbeforestoringforaperiodof15daysormore
inordertopreventdamagetothebattery.Theluminairemustbestoredat20°Croomtemperature.
The luminaire should never be manipulated when the battery is inside. Use the quick access door to
remove the battery before handling.
1.3 DEEP DISCHARGE PROTECTION
Thisprotectionsignicantlyincreasesbatterylifespan.Thisprotectionalsopreventspermanentdamagetothe
batterycausedbyverydeepdischargesduringcoldweather.When the battery reaches a 50% state of charge,
the battery is automatically disconnected from the system until it’s state of charge reaches 85% i.e.about
1dayofsunshineinsummerandabout4daysofsunshineinwinter.
1.4 DAY-NIGHT TRANSITION
The xture uses the solar panel to detect day and night periods. The night transition requires a very low
brightnesslevelfor5continuousminutes.Thisconstraintpreventsfalsenighttransitions.Avoidexposingthe
luminairetoanarticiallightsourcethatmaycausesynchronizationerrorsbysimulatingtheday.Ifthexture
operateserratically,makesurethesolarmoduleisnotcoveredwithdebrisorheavysnow.Theluminaireau-
tomaticallycorrectssynchronizationerrorsafter24hours.Theoccupancysensorhasitsownphotocell,which
doesnotactivatewhentheambientbrightnessistoohigh.
P.3/5
4.13
.45 X4
2.00
NOTE:
The installation of
the solar system
must be made
using one bolt
which passes
through the post.
Follow this drilling
pattern for the
position of holes.
The hole should be
pointing in the
direction of the
desired lighting
orientation.
DIRECTION OF LIGHTING
REV.
DESCRIPTION
DATE
PAR
4
DRAWING PER MODEL
15 SEP 2022
JFOL
3
MOUNTING HOLE
27 JUN 2022
JFOL
2
HOLES SIZE AND POSITION ADJUSTED
13 OCT 2020
JFOL
1
UPDATE OF THE NOTE
26 MAR 2020
JFOL
A A
B B
2
2
1
1
PROJECT:
WEIGHT:
"
THICKNESS
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
VISION SOLAIRE INC ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
VISION SOLAIRE COM IS
PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
DIMENSIONS ARE IN INCHES
DEFAULT TOLERANCES:
ANGULAR
1°
TWO PLACE DECIMAL
.06"
THREE PLACE DECIMAL
.031"
HOLES
.005"
MATERIAL
FINISH
DRAWN
DATE
NAME
VS
TITLE:
SIZE
A
DWG. NO.
REV
SCALE: 1:5
UNLESS OTHERWISE SPECIFIED:
JFOL
24MAY2019
SHEET 1 OF 1
H44_DRL_LXZX
DO NOT SCALE DRAWING
4IN POST
DRILLING PATTERN FOR
LX & ZX
4
P.4/5
LX25-LX50
.45 x4
6.63
2.50
DIRECTION OF LIGHTING
NOTE:
The installation of
the lamp on the
top of the post
requires drilling the
post as per the
presented drilling
pattern. The lamp
will be secured
using one bolt
through the lamp
post.
The hole should be
pointing in the
direction of the
desired orientation.
REV.
DESCRIPTION
DATE
PAR
4
DRAWING PER MODEL
15 SEP 2022
JFOL
3
SIMPLIFICATION OF THE DRILLING PATTERN
27 JUN 2022
JFOL
2
HOLE SIZE AND POSITION ADJUSTED
13 OCT 2020
JFOL
1
UPDATE OF THE NOTE
26 MAR 2020
JFOL
A A
B B
2
2
1
1
PROJECT:
WEIGHT: 36.54
"
THICKNESS
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
VISION SOLAIRE INC ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
VISION SOLAIRE COM IS
PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
DIMENSIONS ARE IN INCHES
DEFAULT TOLERANCES:
ANGULAR
1°
TWO PLACE DECIMAL
.06"
THREE PLACE DECIMAL
.031"
HOLES
.005"
MATERIAL
FINISH
DRAWN
DATE
NAME
VS
TITLE:
SIZE
A
DWG. NO.
REV
SCALE: 1:5
UNLESS OTHERWISE SPECIFIED:
JFOL
26 MAR 2020
SHEET 1 OF 1
H55S_DRL_LXZX
DO NOT SCALE DRAWING
5IN POST
DRILLING PATTERN FOR
LX & ZX
4
P.5/5
LX95
