Solera FV211016-63 Manuale utente
Connection and protection box for PV strings (2
inputs - 1 output)
DC connection and protection box for photovoltaic installations (2 inputs - 1
output). With 1250VDC transient surge protection, 16A 1000VDC fuses. Cut-off
switch-disconnector in 4P 63A 1000VDC output. Dimensions 270x250x160. With
MC4 multicontact connectors mounted for the input and cable gland mounted
for the output. Assembled grounding cable gland.
Common applications: Industrial environment
Features
Enclosure type Box protection strings PV
Installation method Surface
Use Industrial
Location type Exterior and interior
No. Modules (18 mm) 12
Modules per row 12
Metallic DIN profile Yes
Dimensions outside (mm) (width x height
x depth)
270x250x160
Case material Insulation
Frame and door material Insulation
Case color Grey (RAL7035)
Cap color Grey (RAL 7035)
Door color Blue
Door opening Vertical
Ticket type Pre-punched
No. of inlets and size (mm) SUP/INF: 4xØ20, 4xØ25, 6xØ40. LAT: 8xØ40
Fixation System (For surface) Inside with plug, outside with bracket or flange.
Sealable Yes
FV211016-63
Portalámparas y Accesorios Solera S.A. Pol. Ind. Fuente del Jarro C/ Villa de Madrid, 53 46988 Paterna (Valencia) España
+34 961 322 301 | solera@psolera.com | www.psolera.com
Technical data
Regulations
Sustainability
Linkable Vertically and horizontally
Lid closure system Ultra-fast metal screw
Door closing system Handle
Possibility of mounting strips Yes (not included)
Possibility of mounting with key / padlock Key
Possibility of mounting DIN rail Yes (included)
Valid for photovoltaic installations Yes
Protection Degree (IP) IP65
Protection Degree (IK) IK08
Impact shock resistance Strong
Insulation class Class II
UV resistance Yes
Free of halogens Yes
Suitable for saline environments Yes
CE marking Yes
UK marking Yes
CMim marking Yes
According to Regulations UNE/EN UNE-EN 60364-7-712:2017
According to REBT Yes
According to European Directive 2014/35 /
EU. Low voltage directive
Yes
According to European Directive
2011/65/UE (RoHS)
The box does not correspond to the definition of Electrical and Electronical
Equipment (EEE), but the included devices are affected individually.
According to European Directive
2012/19/UE (RAEE2)
The box does not correspond to the definition of Electrical and Electronical
Equipment (EEE), but the included devices are affected individually.
FV211016-63
Portalámparas y Accesorios Solera S.A. Pol. Ind. Fuente del Jarro C/ Villa de Madrid, 53 46988 Paterna (Valencia) España
+34 961 322 301 | solera@psolera.com | www.psolera.com
Logistics and packaging
Sketch
Unit EAN code 8423220229594
EAN code container 8423220229594
EAN code packaging 18423220229591
Units Container 1
Units Packaging 8
Pallet Units 100
Packaging Measures cm 56x70,5x37,5
Unit weight (gr) 2800
Container Weight (Kg) 2,80
Packaging Weight (Kg) 23,38
Tariff code 85371098
FV211016-63
Portalámparas y Accesorios Solera S.A. Pol. Ind. Fuente del Jarro C/ Villa de Madrid, 53 46988 Paterna (Valencia) España
+34 961 322 301 | solera@psolera.com | www.psolera.com
Declaration of conformity (0.14MB) Assembly instructions (3.48MB)
Commercial doc. (4.93MB) Commercial doc. (6.32MB)
SOLERA: Industrial cabinets IP65, IK08
Documentation and downloads
