Fixscreen®100EVO IM 1 & 6 Description
Fixscreen®100
EVO
IM 1 & 6
+ motor control
Design
•Softline of Square design
•No wrinkles or folds
•Cable can be concealed in side channels
•Can be combined with insect screen or fibreglass, Soltis®fabrics or Insectscreen
•Blackout fabric for inside or outside application
•Profiles available anodised or powder coated in any RAL colour
Comfort
•Control screen: broad range of automatisation
•Option: U-safe safetyswitch
Durability
•The Fixscreen-technology with Smooth Technology ensures a smooth and quiet operation of
the zip in the guide system. This intelligent wind tight guiding system is equipped with a durable top layer:
−results in a screen fabric with no folds or wrinkles
−fabric in every position windtight
•Easy & quicker installation thanks to:
−a patented powerplug: Connect&Go®Technology
−side channels with pre-drilled holes typ: S / G
−fabric roller demounted from front side
Installation method 1 Surface-mounted : outside, in front of the window
Installation method 6 Surface-mounted : inside, in front of the window
Height box 100 mm
Depth box 100 mm
Motor control Joinable, 2-parts (1 or 2 motors)
Minimal width for motor control 795 mm
Maximal width for motor control 4000 mm
Maximal height for motor control 3500 mm
Maximal surface for motor control 10,8 m²
Joinable Rensonmotor Safety First not possible
Maximal width coupled 6000 mm
Maximal height 2700 mm
Maximal surface for motor control 16,2 m²
Box prolongation:
Maximal width incl. box prolongation 6000 mm (> 6000 mm price on request)
Technical features:
CE approved
Windclass EN13561: WK3
Guaranteed windtightness 130 Km/h
Technical possibilities:
Motors: WT electronic: only untill FH ≤ 2700 mm
IO only untill FH ≤ 2700 mm
See page ‘Technical possibilities’
Applicable screens:
Fibreglass fabric Horizontal confectioning of fabric: welding of 2700 mm
Horizontal confectioning of fabric: welding of 3200 mm for a limited selection
Polyester fabric Soltis 86 / 92 Horizontal confectioning of fabric: welding of 1770 mm
Horizontal confectioning of fabric: welding of 2670 mm for a limited selection
Polyester fabric Soltis 93 until the end of stock Horizontal confectioning of fabric: welding of 2670 mm
Blackout screen Satiné 21154 (5) Horizontal confectioning of fabric: welding of 2100 mm
Blackout screen polyester fabric Soltis B92 (3) Horizontal confectioning of fabric: welding of 1700 mm
Insectscreen ISR mesh (6) Horizontal confectioning of fabric: welding of 2400 mm
(3) Limited dimensions with blackout screen: minimal width 1000 mm, maximal width 2000 mm, maximal height 2700 mm
(5) Exclusivily for interior use
(6) Limited dimensions: height ≤ 2700 mm
Note: Polyester fabric can show wrinkles or folds
Guarantee
•10 year guarantee on all concerning the coating of aluminium elements
•7-year guarantee on the Fixscreen®technology :
−Zip remains in side channel
−Optimal adhesion of zip to fabric
•5 years guarantee against any defects during normal use and with regular maintenance
•5 years guarantee on gloss (coating)
•5 years guarantee on the electronic control
•5 years guarantee on the fabric collection
•See our user manual and guarantee certificate
Fixscreen®100EVO
