SonicWALL TZ 190 Manuale utente
COMPREHENSIVE INTERNET SECURITY
™
b
SonicWALL Internet Security Appliances
SonicWALL TZ 190 Wireless
Getting Started Guide
SonicWALL TZ 190 Wireless Getting Started Guide Page 1
SonicWALL TZ 190 Wireless
Getting Started Guide
Thank you for your purchase of the SonicWALL TZ 190 Wireless, the ultimate
security platform for home and small office deployments.
With integrated support for SonicWALL's Gateway Anti-Virus, the SonicWALL
TZ 190 Wireless delivers powerful, yet easy-to-use protection against malicious
users and viruses. The SonicWALL TZ 190 Wireless security appliance also
supports SonicWALL's Content Filtering Service to provide enhanced
productivity and network utilization.
This Getting Started Guide contains installation procedures and configuration
guidelines for deploying a SonicWALL TZ 190 Wireless on your network. For
detailed configuration information, refer to the SonicOS Enhanced
Administrator’s Guide on the SonicWALL Resource CD or on the Web at:
<http://www.sonicwall.com/us/support.html>.
Page 2 READ BEFORE CONTINUING - Important Information Regarding WWAN Service Providers
READ BEFORE CONTINUING -
Important Information
Regarding WWAN Service Providers
It is important to understand that not all WWAN service providers operate in the
same way or support all the same feature sets. Because of this, there exists
some inherent “service provider-specific” variances in service area and more
importantly, in supported features. Along with feature limitations may also come
certain restrictions such as bandwidth constraints and networking limitations.
Before purchasing a WWAN PC card and service plan, check to make sure that
the WWAN service provider offers support for the features you need.
Before committing to a service contract with a WWAN service provider, it may
be helpful to ask these questions:
• What types of traffic are allowed over the WWAN network?
• Do they offer “static” or “dynamic” IP addressing?
• Are there any inbound connection limitations?
• Are single or multiple hosts allowed?
• Do they support VPN traffic?
• What are the data transfer limits (inbound and outbound)?
• What are common data transfer speeds and how much of the
coverage area supports 3G or faster technology?
SonicWALL TZ 190 Wireless Getting Started Guide Page 3
Document Contents
This document contains the following sections:
Completing Pre-Configuration Tasks - page 5
Preparing Your WWAN PC Card - page 11
Registering Your SonicWALL - page 29
Connecting for Initial Setup - page 31
Running the Setup Wizard - page 37
Verifying Your WWAN Connection - page 43
Connecting to Your Network - page 47
Appendix
Appendix A: Configuring DHCP IP Addressing - page 51
Appendix B: Troubleshooting Internet Connectivity - page 52
Appendix C: Safety Instructions and Regulatory Information - page 53
1
2
3
4
5
6
7
Page 4 READ BEFORE CONTINUING - Important Information Regarding WWAN Service Providers
SonicWALL TZ 190 Wireless Getting Started Guide Page 5
Completing Pre-Configuration Tasks
In this Section:
This section provides pre-configuration information. It is necessary to review
this section before setting up your SonicWALL TZ 190 Wireless.
•System Requirements , on page 6
•Check Package Contents , on page 7
•Obtain Configuration Information , on page 8
•Obtain Internet Service Provider (ISP) Information , on page 9
•Obtain WWAN Service Provider Information , on page 10
1
Page 6 System Requirements
System Requirements
Before you begin the setup process, check to ensure that you have a computer
that meets the following requirements. This computer is used to manage your
SonicWALL TZ 190 Wireless during the setup process.
• Windows Vista, Windows XP, Windows 2000 or Windows NT
• 40MB of disk space available
• One available 10/100 Ethernet (LAN) port
• A Web browser supporting Java and HTTP uploads. Internet Explorer 6.0
or higher, Netscape Navigator 4.7 or higher, Mozilla 1.7 or higher are
recommended
• LAN interface set to obtain an IP address automatically (DHCP addressing
enabled)
Note: In order to connect to the SonicWALL TZ 190 Wireless, your
computer must be set to obtain an IP address automatically
using DHCP. For more information on configuring DHCP on
your computer, turn to Appendix A: Configuring DHCP IP
Addressing , on page 51.
SonicWALL TZ 190 Wireless Getting Started Guide Page 7
Check Package Contents
SonicWALL TZ 190 Wireless
Standard power adapter
DB9 -> RJ45 (CLI) Cable
Wireless antenna pair
Ethernet cable
SonicWALL Resource CD
Getting Started Guide
Release Notes document
1
2
3
4
5
6
7
8
Any Items Missing?
If any items are missing from your
package, please contact SonicWALL
support.
A listing of the most current support
options is available online at:
<http://www.sonicwall.com/us/support.html>
*The included power cord is intended for use
in North America only. For European Union
(EU) customers, a power cord is not
included.
1
2
4
3
5
SonicOS Release Notes
Contents
67
8
SonicWALL
Getting Started Guide
COMPREHENSIVE INTERNET SECURITY
SonicWALL
Resource CD
link/act
10/100
wan opt
signal
link/act
wwan
WiFiSec
on/act
wlan
TZ 190
wireless
Page 8 Obtain Configuration Information
Obtain Configuration Information
Please record and keep for future reference the following setup information:
Registration Information
Networking Information
Administrator Information
Serial Number:
Record the serial number found on the bottom panel of
your SonicWALL appliance.
Authentication Code:
Record the authentication code found on the bottom panel
of your SonicWALL appliance.
LAN IP Address:
. . .
Select a static IP address for your SonicWALL appliance
that is within the range of your local subnet. If you are
unsure, you can use the default IP address
(192.168.168.168).
Subnet Mask:
. . .
Record the subnet mask for the local subnet where you are
installing your SonicWALL appliance.
Ethernet WAN IP Address:
. . .
Select a static IP address for your Ethernet WAN. This
setting only applies if you are already using an ISP that
assigns a static IP address.
Admin Name:
Select an administrator account name.
(default is admin)
Admin Password:
Select an administrator password.
(default is password)
SonicWALL TZ 190 Wireless Getting Started Guide Page 9
Obtain Internet Service Provider (ISP) Information
Record the following information about your current Internet service:
If you connect via You likely use Please record
Cable modem,
DSL with a router DHCP No Internet connection information is usually
required, although some service providers
require a host name.
Host Name:
Home DSL PPPoE User Name:
Password:
Note: Your ISP may require your user name in
the format: name@ISP.com
T1/E1,
Static broadband,
Cable or DSL with
a static IP
Static IP IP Address: . . .
Subnet Mask: . . .
Default Gateway
(Router IP Address): . . .
Primary DNS: . . .
Secondary DNS
(optional): . . .
Dial-in to a server PPTP Server Address:
User Name:
Password:
