Sony Ericsson F305 Manuale utente
F305
User guide
This is the Internet version of the User guide. © Print only for private use.
2
Congratulations on your purchase of the Sony Ericsson
F305. For additional phone content, go to
www.sonyericsson.com/fun. Register now to get free online
storage and special offers at www.sonyericsson.com/myphone.
For product support, go to www.sonyericsson.com/support.
Instruction symbols
The following appear in this User guide:
> Use the navigation key to scroll and select
Press the navigation key centre
Press the navigation key up
Press the navigation key down
Press the navigation key to the left
Press the navigation key to the right
Note
Tip
Warning
Indicates that a service or function is network- or
subscription-dependent. All menus or functions may
not be available in your phone. Consult your network
operator for more information.
This is the Internet version of the User guide. © Print only for private use.
3
Preparing the phone
To insert the SIM card and battery
1Remove the battery cover and battery if inserted. Slide the
SIM card into its holder with the contacts facing down.
2Insert the battery with the label side up and the connectors
facing each other. Replace the battery cover.
Do not force the battery cover into place. Place the
battery cover carefully onto the phone and close it.
This is the Internet version of the User guide. © Print only for private use.
4
SIM card
The SIM (Subscriber Identity Module) card, which you
get from your network operator, contains information
about your subscription. Always turn off your phone
and detach the charger and the battery before you
insert or remove the SIM card.
PIN code
You may need a PIN (Personal Identification Number) to
activate the services in your phone. Your PIN is supplied by
your network operator. Each PIN digit appears as *, unless it
starts with emergency number digits, for example, 112 or 911.
You can call an emergency number without entering a PIN.
Memory Stick Micro™
Your phone supports Memory Stick Micro™ (M2™). A memory
card adds more storage space to your phone, for example, for
music, ringtones, video clips and pictures. You can share your
saved information by moving or copying it to other memory
card compatible devices.
You can save contacts on the SIM card before removing it
from your phone. You can also save contacts in the phone
memory. See Contacts on page 26.
If you enter the wrong PIN three times in a row, PIN blocked
appears. To unblock it, you need to enter your PUK (Personal
Unblocking Key).
This is the Internet version of the User guide. © Print only for private use.
5
To insert a Memory Stick Micro™ (M2™)
•Open the cover and insert the memory
card.
To remove a M2™
•Open the cover and press the edge of the
memory card to release and remove it.
Charging the battery
The phone battery is partly charged when you buy it. It takes
approximately 2.5 hours to fully charge the battery.
To charge the battery
1Connect the charger to the phone. Press a key to illuminate
the screen and see the charging status.
2To remove the charger, tilt and pull the plug upwards.
You can use the phone during charging. You can charge
the battery for more or less than 2.5 hours. Interrupted
charging does not damage the battery.
This is the Internet version of the User guide. © Print only for private use.
6
To turn on the phone
1Press and hold down .
2Enter your SIM card PIN, if requested.
3Select Yes to use the setup wizard to
configure basic phone settings such
as Time & date, Phone language and
so on.
Standby
After you have turned on the phone and entered your PIN, the
name of your operator appears on the screen. This is called
standby. You can now make and receive calls.
To turn off the phone
•Press and hold down .
In Flight mode the network and radio transceivers are
turned off to prevent disturbance to sensitive equipment.
If you make a mistake when you enter your PIN, you can
press to delete numbers from the screen.
This is the Internet version of the User guide. © Print only for private use.
7
Network coverage
The network bars show the strength of the GSM network
in your area. Move to another location if you have problems
calling and network coverage is poor. No network means you
are not in range of a network.
Battery status
= Good network coverage
= Average network coverage
= The phone battery is fully charged
= The phone battery is empty
Battery status
Network
coverage
This is the Internet version of the User guide. © Print only for private use.
8
Screen icons
These icons may appear on the screen.
Icon Description
Missed call
Handsfree connected
Phone set to silent
Text message received
Picture message received
Email message received
Predictive text input activated
Voice message received
Ongoing call
FM radio playing
Alarm activated
Bluetooth function activated
This is the Internet version of the User guide. © Print only for private use.
9
Phone overview
1Circle gaming key
2Selection keys
3Call key
4Connector for charger,
handsfree and USB cable
5Gaming shortcut key
6Navigation key, directional
gaming keys
7Cross gaming key
8End key, on/off key
9C key (Clear)
10 Centre selection key
11 Silent key
12 Main camera
13 Strap holder
14 Volume keys
15 Camera key
16 Memory card slot
17 Stereo speakers
This is the Internet version of the User guide. © Print only for private use.
10
Navigation
The main menus are shown as icons. Some submenus include
tabs.
To navigate the phone menus
1From standby select Menu.
2Use the navigation key to move through the menus.
To scroll between the tabs
•Press the navigation key left or right.
To go back one step in the menu
•Select Back.
To return to standby
•Press .
To set the phone to silent
•Press and hold down .
To call your voicemail service
•Press and hold down .
To end a function
•Press .
Centre selection key
This is the Internet version of the User guide. © Print only for private use.
