Sony Ericsson S302 Manuale utente
S302
User guide
This is the Internet version of the User guide. © Print only for private use.
2
Thank you for purchasing a Sony Ericsson S302.For
additional phone content, go to www.sonyericsson.com/fun.
Register now to get free online storage and special offers at
www.sonyericsson.com/myphone. For product support, go to
www.sonyericsson.com/support.
Instruction symbols
The following appear in this User guide:
> Use the navigation key to scroll and select
Press the centre selection key
Press the navigation key up
Press the navigation key down
Press the navigation key to the left
Press the navigation key to the right
Note
Tip
Warning
Indicates that a service or function is network- or
subscription-dependent. All menus or functions may
not be available in your phone. Consult your network
operator for more information.
This is the Internet version of the User guide. © Print only for private use.
3
SIM card
The SIM (Subscriber Identity Module) card, which you
get from your network operator, contains information
about your subscription. Always turn off your phone
and detach the charger and the battery before you
insert or remove the SIM card.
PIN code (SIM card lock)
The PIN (Personal Identification Number) code is a SIM card
lock that protects your subscription, but not the phone itself.
If the card is locked, you have to enter the PIN code when you
turn on your phone. To change your PIN code, see SIM card
lock on page 36.
Each PIN digit appears as *, unless it starts with emergency
number digits, for example, 112 or 911. You can call an
emergency number without entering a PIN.
You can save contacts on the SIM card before removing it
from your phone. You can also save contacts in the phone
memory. See Contacts on page 22.
If you enter the wrong PIN three times in a row, PIN
blocked appears. To unblock it, you need to enter your
PUK (Personal Unblocking Key).
This is the Internet version of the User guide. © Print only for private use.
4
Charging the battery
The phone battery is partly charged when you buy it. It takes
approximately 2.5 hours to fully charge the battery.
To charge the battery
1Connect the charger to the phone with the power icon on
the charger facing upwards. Press a key to illuminate the
screen and see the charging status.
2To remove the charger, tilt and pull the plug upwards.
The battery icon on the screen may not appear until the
phone has charged for 30 minutes.
You can use the phone during charging. You can charge
the battery for more or less than 2.5 hours. Interrupted
charging will not damage the battery.
This is the Internet version of the User guide. © Print only for private use.
5
Memory Stick Micro™
Your phone supports Memory Stick Micro™ (M2™). A memory
card adds more storage space to your phone, for example,
music, ringtones, video clips and pictures. You can share your
saved information by moving or copying it to other memory
card compatible devices.
To insert Memory Stick Micro™ (M2™)
•Open the cover and insert the memory card (with the gold-
coloured contacts facing down).
To remove a Memory Stick Micro™ (M2™)
•Press the edge to release and remove.
This is the Internet version of the User guide. © Print only for private use.
6
Turning on the phone
To turn on the phone
1Press and hold down .
2Enter your SIM card PIN, if
requested.
3Select Yes to use the setup
wizard.
Standby
After you have turned on the phone and entered your PIN, the
name of your operator appears on the screen. This is called
standby. You can now make and receive calls.
To turn the phone off
•Press and hold down .
If you make a mistake when you enter your PIN, you can
press to delete numbers from the screen.
If your phone cannot turn on, attach the charger and
charge the phone for 2.5 hours.
If your phone turns itself off when being transported, turn
the automatic keylock on. This prevents things in your
pocket or bag from activating the on/off key accidentally.
This is the Internet version of the User guide. © Print only for private use.
7
Network coverage
The network bars show the strength of the GSM network in
your area. Move to another location if you have problems
calling and network coverage is poor. No network means you
are not in range of a network.
Battery status
= Good network coverage
= Average network coverage
= The phone battery is fully charged
= The phone battery is empty
If you cannot turn on the phone, attach the charger
properly and try charging the phone until it has finished
charging.
Battery status
Network
coverage
This is the Internet version of the User guide. © Print only for private use.
8
Screen icons
These icons may appear on the screen.
Icon Description
Ongoing call
Missed call
Handsfree connected
Phone set to silent
Predictive text input activated
Text message received
Picture message received
Email message received
Voice message received
FM radio playing
Alarm activated
Bluetooth function activated
This is the Internet version of the User guide. © Print only for private use.
9
Phone overview
3
1
210
1 Ear speaker
2Musickey
3Screen
4Selectionkeys
5 Call key
6 Shortcuts menu key
7
Connector for
charger, handsfree
and USB cable
8 Navigation key
9 Centre selection key
10 Volume keys/camera
zoom keys
11 On/off key
End call key
12 C key (Clear)
13 Camera key/video
recorder key
14 Silent key
4
5
6
11
12
13
8
7
14
9
This is the Internet version of the User guide. © Print only for private use.
10
Key
Go to the main menus or select items
Scroll between the menus and tabs
Select options shown immediately above these keys
on the screen
Delete items, such as pictures, sounds and contacts.
On the side:
Press to stop or play music when in the Music player
mode
Press to mute or unmute the radio. Works only if an
audio accessory is connected
Press to move between the Music player and standby
My shortcuts – add your favourite functions to access
them quickly
From standby press to activate Camera and video
recorder
Press and hold down to turn the phone on/off
Press to end a call
Press to make a call after you gave entered the phone
number
