Sony Ericsson T303C Manuale utente

This is the Internet version of the user'sguide. © Print only for private use.

T303c

User guide

This is the Internet version of the user'sguide. © Print only for private use.

Congratulations on your purchase of the Sony Ericsson

T303c. For additional phone content, go to

www.sonyericsson.com/fun. Register now to get free online

storage and special offers at www.sonyericsson.com/myphone.

For product support, go to www.sonyericsson.com/support.

Instruction symbols

The following instruction symbols appear in this User guide:

> Use a navigation key or a selection key to scroll and select.

Press the centre selection key.

Press the navigation key to the left.

Press the navigation key to the right.

Press the navigation key up.

Press the navigation key down.

Note

Tip

Warning

Indicates that a service or function is network- or subscription-

dependent. All menus or functions may not be available in your

phone. Consult your network operator for more information.

This is the Internet version of the user'sguide. © Print only for private use.

Preparing the phone

To insert the SIM card and battery

1Remove the battery cover. Slide the SIM card into its holder with the

contacts facing down.

2Insert the battery with the label side up and the connectors facing

each other. Replace the battery cover as shown in the picture.

Charge the battery

Your phone battery is partly charged when you buy it.

Do not force the battery cover into place. Slide the battery cover

carefully onto the phone and close it.

It may take 30 minutes for the battery icon to appear on the screen.

This is the Internet version of the user'sguide. © Print only for private use.

Non-USB Charger (old type)

USB Charger (new type)

A AC adapter A1 AC adapter connector

A2 AC adapter USB socket B USB cable

B1 USB cable connector B2 USB cable plug

Using the USB charger

To connect the charger and charge the battery

1Connect the USB cable plug to the AC adapter USB socket, as shown

in the above illustration. The USB cable is supplied with your phone.

This is the Internet version of the user'sguide. © Print only for private use.

2Connect the USB cable connector to your phone. Press a key to view

the charging status on the screen. It takes approximately 2.5 hours to

fully charge the battery.

To remove the charger

1Charge your battery until the battery icon indicates a full charge.

2Tilt the USB charger connector upwards to remove it.

Note:

1The USB cable for the new USB charger shown in the illustration (Part. B

in the new-type charger illustration) on page 4 is only intended for

charging your phone. Do not use it for transferring data.

2The USB cable for the USB charger shown in the illustration (Part. B

in the new-type charger illustration) is only intended for connection to the

AC adapter (Part. A in the new-type charger illustration) to charge your

phone. It must not be used for connection to a PC. It can only be used

for charging your phone. Never use it for charging accessories.

3Sony Ericsson strongly recommends that you use only Sony Ericsson

branded original batteries, the part of power supply device in

accordance with YD/ T 1591-2006 specifications of Communications

Industry Standards of P. R. China (Part A in the new-type charger

illustration) and the USB cable supplied with your phone to charge the

phone. The use of third-party products may decrease the performance

of your phone and/or pose a risk to your health or safety.

This is the Internet version of the user'sguide. © Print only for private use.

4Sony Ericsson recommends that you never mix the use the new USB

charger and the old non-USB charger. The phone with new-type

charger in box cannot be charged with the old-type charger, and vice

versa. The use of both the chargers may decrease the performance of

your phone and/or pose a risk to your health or safety.

To turn on the phone

1Press and hold down .

2Enter your PIN if requested. To correct mistakes, press .

3Select OK.

4Select a language.

5Enter the time and date and select Save.

To turn off the phone

•Press and hold down .

Standby

After you have turned on the phone and entered your PIN, the name of

your operator appears on the screen. This is called standby. You can now

make and receive calls.

You can use the phone during charging. You can charge the battery

for more or less than 2.5 hours.

Interrupted charging will not damage the battery.

Use only Sony Ericsson branded original batteries intended for use

with your mobile phone. If you use other batteries you may not be

able to charge your phone.

This is the Internet version of the user'sguide. © Print only for private use.

SIM and PIN

SIM card

The SIM (Subscriber Identity Module) card, which you get from

your network operator, contains information about your subscription.

Always turn off your phone and detach the charger and remove

the battery before you insert or remove the SIM card.

PIN code

You may need a PIN (Personal Identification Number) to activate the

services in your phone. Your PIN is supplied by your network operator.

Each PIN digit appears as *, unless it starts with emergency number digits,

for example, 112 or 911. You can call an emergency number without

entering a PIN.

You can save contacts on the SIM card before removing it from

your phone. Contacts may also be saved in the phone memory.

See Contacts on page 18.

If you enter the wrong PIN three times in a row, PIN blocked.

To unblock, enter your PUK code provided by your network

operator. appears. To unblock it, you need to enter your PUK

(Personal Unblocking Key).

This is the Internet version of the user'sguide. © Print only for private use.

Network coverage

The network bars show the strength of the GSM network in

your area. Try moving to another location if you have trouble

calling and network coverage is poor. No network means you

are not in range of a network.

Battery status

= Good network coverage

= Average network coverage

= The phone battery is fully charged

=The phone battery is empty

= The phone battery is being charged

Battery

status

Network

coverage

This is the Internet version of the user'sguide. © Print only for private use.

Phone overview

Navigation key

C key

Strap

hole

Camera

On/off key,

End key

Shortcut key

Call key

Selection key

Ear speaker

Silent key

Selection key

Screen

Connector for

charger and

handsfree

Centre

selection key

This is the Internet version of the user'sguide. © Print only for private use.

Menu overview

Organizer File manager, Alarms, Calendar, Tasks,

Notes, Timer, Stopwatch, Calculator

Monternet

Entertainment TrackID™, My Games, FM radio, Sound

recorder

Camera

Messaging Write new, Inbox, Call voicemail, Drafts,

Outbox, Sent messages, Saved msgs,

Templates, Settings

Music player Play view, Artists, Tracks, Playlists

Calls*

All Answered Dialled Missed

Contacts New contact

Settings*

General Sounds &

alerts Display Calls Connectivity

Some menus and icons in this document may vary depending on

operator, network or subscription.

* You can use the navigation key to select tabs in sub menus.
