Sony Ericsson Z500a Manuale utente

Z500 Series front cover.fm Page 1 Tuesday, August 3, 2004 4:21 PM

This is the Internet version of the user's guide. © Print only for private use.

Contents

Getting started . . . . . . . . . . . . . . . . . . 4

Assemble the phone, SIM card, battery, make a call.

Getting to know your phone . . . . . . . 10

Phone overview, use the menus, enter letters,

file manager.

Calling . . . . . . . . . . . . . . . . . . . . . . . . 21

Calls, phonebook, voice control, call options.

Messages . . . . . . . . . . . . . . . . . . . . . . 41

Text messaging, picture messaging, email, My friends,

messaging glossary.

Imaging . . . . . . . . . . . . . . . . . . . . . . . 57

Camera, video recorder, pictures, screen saver.

Entertainment . . . . . . . . . . . . . . . . . . 63

Media player, sounds, themes, games.

Connectivity . . . . . . . . . . . . . . . . . . . . 68

Internet and email settings, synchronizing,

PC applications.

More features . . . . . . . . . . . . . . . . . . . 73

Time and date, alarm clock, calendar, tasks,

SIM card lock, etc.

Troubleshooting . . . . . . . . . . . . . . . . . 83

Why doesn’t the phone work the way I want?

Additional information . . . . . . . . . . . . 86

Sony Ericsson web site, technical assistance, safe and

efficient use, warranty, declaration of conformity.

Icons . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Icon descriptions.

Index . . . . . . . . . . . . . . . . . . . . . . . . . 96

Sony Ericsson Z500a

This is the Internet version of the user's guide. © Print only for private use.

Sony Ericsson

GSM 850/1800/1900

First edition (September 2004)

This manual is published by Sony Ericsson Mobile

Communications AB, without any warranty.

Improvements and changes to this manual

necessitated by typographical errors, inaccuracies of

current information, or improvements to programs

and/or equipment, may be made by Sony Ericsson

Mobile Communications AB at any time and without

notice. Such changes will, however, be incorporated

into new editions of this manual.

©Sony Ericsson Mobile Communications AB, 2004

Publication number: AE/LZT 123 1761 R1A

Please note:

Some of the services in this manual are not

supported by all networks. This also applies to the

GSM International Emergency Number 112.

Please contact your network operator or service

provider if you are in doubt whether you can use a

particular service or not.

Please read the Guidelines for safe and efficient use

and the Limited warranty chapters before you use

your mobile phone.

The Bluetooth word mark and logos are owned by the

Bluetooth SIG, Inc. and any use of such marks by

Sony Ericsson is under license.

T9™ Text Input is a trademark or a registered

trademark of Tegic Communications.

T9™ Text Input is licensed under one or more of

the following:

U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480,

5,945,928, and 6,011,554;

Canadian Pat. No. 1,331,057;

United Kingdom Pat. No. 2238414B;

Hong Kong Standard Pat. No. HK0940329;

Republic of Singapore Pat. No. 51383;

Euro.Pat. No. 0 842 463(96927260.8) DE/DK, FI, FR,

IT, NL, PT, ES, SE, GB;

and additional patents are pending worldwide.

PlayNow™ is a trademark or a registered trademark

of Sony Ericsson Mobile Communications AB.

MusicDJ™ is a trademark or a registered trademark

of Sony Ericsson Mobile Communications AB.

Java and all Java based trademarks and logos are

trademarks or registered trademarks of Sun

Microsystems, Inc. in the U.S. and other countries.

End-user license agreement for Sun™ Java™

J2ME™.

1Restrictions: Software is confidential copyrighted

information of Sun and title to all copies is retained

by Sun and/or its licensors. Customer shall not

This is the Internet version of the user's guide. © Print only for private use.

modify, decompile, disassemble, decrypt, extract,

or otherwise reverse engineer Software. Software

may not be leased, assigned, or sublicensed, in

whole or in part.

2Export Regulations: Software, including technical

data, is subject to U.S. export control laws,

including the U.S. Export Administration Act and

its associated regulations, and may be subject to

export or import regulations in other countries.

Customer agrees to comply strictly with all such

regulations and acknowledges that it has the

responsibility to obtain licenses to export, re-

export, or import Software. Software may not be

downloaded, or otherwise exported or re-exported

(i) into, or to a national or resident of, Cuba, Iraq,

Iran, North Korea, Libya, Sudan, Syria (as such

listing may be revised from time to time) or any

country to which the U.S. has embargoed goods;

or (ii) to anyone on the U.S. Treasury

Department’s list of Specially Designated Nations

or the U.S. Commerce Department’s Table of

Denial Orders.

3Restricted Rights: Use, duplication or disclosure

by the United States government is subject to the

restrictions as set forth in the Rights in Technical

Data and Computer Software Clauses in DFARS

252.227-7013(c) (1) (ii) and FAR 52.227-19(c) (2)

as applicable.

Part of the software in this product is copyright

©SyncML initiative Ltd. (1999-2002).

Other product and company names mentioned herein

may be the trademarks of their respective owners.

Any rights not expressly granted herein are reserved.

This is the Internet version of the user's guide. © Print only for private use.

Getting started

Assemble the phone, SIM card, battery,

make a call.

More information and downloads are available at

www.SonyEricsson.com.

Instruction icons

The following instruction icons appear in this

user guide:

Assembly

Before you can use your phone you need to:

• Insert the SIM card.

• Attach and charge the battery.

SIM card

When you register as a subscriber with a service

provider, you get a SIM (Subscriber Identity

Module) card. The SIM card contains a computer

chip that keeps track of your phone number, the

services included in your subscription, and your

phonebook information, among other things.

SIM card and battery

information

Always turn off the phone and detach the charger

before you insert or remove a SIM card.

}Use the selection keys or the navigation key

to scroll and select.

%13 Navigating the menus.

%See also page ...

Important

Note

Contact your service provider for details.

If you have been using a SIM card in another phone,

make sure that your information is saved to the SIM

card before you remove it from the other phone. For

example, contacts may have been saved in the phone

memory %24 Phonebook.

This is the Internet version of the user's guide. © Print only for private use.

Getting started

To insert the SIM card and charge

the battery

1Insert the SIM card.

2Make sure the SIM card is aligned and then

slide it under the metal holder.

3Place the battery on the back of the phone with

the label side up and the connectors facing

each other.

4Place the back cover as shown in the picture

and slide it into place.

5Connect the charger to the phone at the flash

symbol. The flash symbol on the charger plug

must face upwards.

6It may take up to 30 minutes before the battery

icon appears on the screen.

7Wait approximately 4 hours or until the battery

icon indicates that the battery is fully charged.

If you do not see the battery icon after this

time, press any key or the navigation key ( )

to activate the screen.

8Remove the charger by tilting the

plug upwards.

It may take up to 30 minutes before the battery icon

appears when charging.

This is the Internet version of the user's guide. © Print only for private use.

Getting started

PIN (Personal Identity Number)

You may need a PIN (Personal Identity Number) to

activate the services in your phone. Your PIN is

supplied by your service provider. When you enter

your PIN, the digits are hidden with an *, unless

your PIN starts with the same digits as an

emergency number, for example 112. This is so

that you can see and call an emergency number

without entering a PIN %24 Emergency calls.

If you make a mistake while entering your PIN,

delete the number by pressing .

Available services

Some services and functions described in this user

guide are network- or subscription-dependent.

Because of this, all menus may not be available in

your phone.

Please consult your service provider for more

information about your subscription.

If you enter the wrong PIN three times in a row, the

SIM card is blocked and the message PIN blocked

appears. To unblock it, you need to enter your PUK

(Personal Unblocking Key), %80 SIM card lock.

Your PUK is supplied by your service provider.

This symbol indicates that a service or function is

network- or subscription-dependent.

This is the Internet version of the user's guide. © Print only for private use.

Getting started

First-time use

Make sure that the phone is charged before you

turn it on.

To turn on the phone

1Press and hold until the phone vibrates.

This indicates that it is powering up.

2Enter your PIN, if you have one for your

SIM card.

3At first start-up, select the language you want

for your phone, that is, the language for

the menus.

4}Yes if you want the setup wizard to help you

get started. Follow the instructions that appear.

When you have turned the phone on, you can use a

setup wizard to quickly and easily prepare your

phone for use.

Setup wizard

You can use the setup wizard to help you get

started with the basic settings in your phone. If you

do not want help the first time you turn on your

phone, you can select to use the wizard later.

You can also select to start the wizard from the

menu system at any time. The wizard gives you tips

on how to use the keypad and guides you through

the settings.

This is the Internet version of the user's guide. © Print only for private use.

Getting started

To start the setup wizard from the

menu system

1}Settings }the General tab }Setup Wizard.

2Select language for your phone.

3Follow the instructions that appear to complete

the setup.

To make and receive calls

• Enter the area code and phone number }Call to

make the call. }End Call to end the call.

• When the phone rings }Yes.

To enter the desktop

• Press the center select key ( ).

This is the Internet version of the user's guide. © Print only for private use.

Getting started

To replace the outer covers

1Hold the phone as shown in Illustration 1.

2Apply pressure with the heel of one hand while

pushing away with the thumb of your other

hand. You may need to apply significant

pressure the first time you remove the cover.

3Slide the cover away from the hinge.

4Remove the cover.

5Locate the notches along each side of the

phone. Using the notches as a guide, slide the

back cover upward applying pressure with the

heel of your hand.

6Click the flip cover into place.

Use these instructions to replace the other

outer cover.

Altri manuali per Z500a

Indice

Altri manuali Sony Ericsson Telefono cellulare

Sony Ericsson

Sony Ericsson Cyber-Shot K770 Manuale del proprietario

Sony Ericsson

Sony Ericsson F305 Manuale utente

Sony Ericsson

Sony Ericsson W705 Walkman Manuale utente

Sony Ericsson

Sony Ericsson Walkman W350a Manuale utente

Sony Ericsson

Sony Ericsson C903 Cyber-shot Manuale utente

Sony Ericsson

Sony Ericsson Xperia tipo Manuale utente

Sony Ericsson

Sony Ericsson T637 T637 T637 Guida rapida

Sony Ericsson

Sony Ericsson CYBER-SHOT C510 Guida di riferimento rapido

Sony Ericsson

Sony Ericsson T100 Manuale utente

Sony Ericsson

Sony Ericsson C702 Manuale di programmazione

Sony Ericsson

Sony Ericsson W800i Manuale utente

Sony Ericsson

Sony Ericsson T618 Manuale utente

Sony Ericsson

Sony Ericsson Walkman W595a Manuale utente

Sony Ericsson

Sony Ericsson Z200 Manuale utente

Sony Ericsson

Sony Ericsson Z310a Manuale utente

Sony Ericsson

Sony Ericsson W32S Guida all'installazione

Sony Ericsson

Sony Ericsson XPERIA mini Manuale di servizio

Sony Ericsson

Sony Ericsson A3618s Manuale utente

Sony Ericsson

Sony Ericsson Sony Ericsson Manuale utente

Sony Ericsson

Sony Ericsson Cyber-Shot K770 Manuale utente

Sony Ericsson

Sony Ericsson Cyber-Shot K770 Manuale utente

Sony Ericsson

Sony Ericsson W712a Manuale utente

Sony Ericsson

Sony Ericsson Walkman W350a Manuale utente

Sony Ericsson

Sony Ericsson Z250 Manuale utente

Manuali Telefono cellulare popolari di altre marche

Zte

Zte BLADE A520 Manuale utente

Nokia

Nokia Lumia 620 Manuale utente

Blackbe;rry

Blackbe;rry KEYone Manuale utente

Bea-fon

Bea-fon X5 Premium Manuale utente

Blackbe;rry

Blackbe;rry 8707 Series Manuale utente

Blackbe;rry

Blackbe;rry Storm Istruzioni operative

LG LM-X420QN Manuale utente

LifeWatch

LifeWatch V Manuale utente

Bea-fon

Bea-fon SILVER LINE SL860 Manuale utente

IKI Mobile

IKI Mobile KF4.5i Manuale utente

Hitech

Hitech HT-850 Manuale utente

Yezz

Yezz Fashion F10 Manuale utente

Point Mobile

Point Mobile PM60 Manuale utente

Blackbe;rry

Blackbe;rry Q10 Manuale utente

Blackbe;rry

Blackbe;rry Bold 9900 Manuale utente

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuale utente

LG LM-K420EMW Manuale utente

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale utente
