Sony TA-MR2ES - 2 Channel Amplifier Manuale utente

Key Features

TA-MR2ES

Distributed Audio Amplifier

•Infrared Communication Port for quick and convenient wireless connectivity

•Advanced Integration Capabilities fit seamlessly into most integrated entertainment solutions

•Infrared Input Port: For use with IR keypads and repeater systems

•Unique IR Code Sets Allow up to 12 units to be operated independently

within 1IR repeater system

•Attractive Silver Metallic Finish

Additional Features

General Features

•2-channel Amplifier For use with

multi-room systems and A/V receivers

•Volume and Mute Control Using IR

Eliminates need for an external volume

control

•12V Trigger Input For activation by

other devices

•12V Trigger Output with Delay Powers

multiple amps without tripping circuit

breakers with 1.5 second delay

•Audio Signal Sensor Automatically activates

power when audio signal is detected

•Discrete Power On and Off For use with

macro-driven controllers

•Back Panel IR Code Generator Enables

simple IR code learning directlyfrom device

•Gain Controls Allows balancing of source

output with amplifier output, easily accessible

by installer behind front knockout panel

•19-inch Rack Mountable For easy

installation, rack-mount hardware supplied

•5Y

ear Parts & Labor Limited Warranty

backed by Sony quality and dependability

•35W x 2: 8 ohms 20Hz-20kHz,THD 0.09%

•40W x 2: 4 ohms 20Hz-20kHz,THD 0.09%

Features

TA-MR2ES

Distributed Audio Amplifier

General

•Silver Finish Distributed Audio

Amplifier

•35W x 2 (8 ohms 20Hz-20kHz,

THD 0.09%)

•40W x 2 (4 ohms 20Hz-20kHz,

THD 0.09%)

•Audio Signal Sensor Activation

•19-inch Rack Mountable

IR Programming

•12 Distinct IR Code Sets

•IR Programming from Back Panel

•Vol +/- and Mute On/Off (Toggle)

Inputs and Outputs

•12V Trigger In x 1

•12V Trigger Out With 1.5 sec

Delay x 1

•IR Input Port with

Pass-Through x 1

•IR Output Port x 1

©2005 Sony Electronics Inc. All rights reserved. Features and specifications are subject to change without notice. Sony is a trademark of Sony. All other trademarks are trademarks of their respective owners.

Sony Electronics Inc.

1Sony Drive

Park Ridge, NJ 07656

For moreinformation:

http://www.sony.com/dn

Specifications

General

•Power Consumption:

100W

•Power Requirements:

120V, 60Hz

•Frequency Response:

5-100Khz, +0.5/-2dB

•Residual Noise: <150_V

or less

•Channel Separation:

60dB/45dB

Audio Input

•Sensitivity: 150mV

•Impedance:

50kilo Ohms

•S/N: 94dB (A-weighted

filter, 150mV input level)

Audio Output

•Voltage: Minimum 2V

without clipped

•Impedance: 1 kilo Ohms

•S/N: 102dB (A-weighted

filter, 2V output)

Supplied

Accessories

•Instruction Manual

•AC Power Cord x 1

•Rack Mount Ear x 2

•Rack Mount Screw x 8

Weights and

Measures

•14 lbs. 5 oz (6.5 kg)

•17” x 2 5/8” x 13 7/8”

(430 x 67 x 350 mm)

UPC Code

•TBD
