SONY

HDCAMCORDER

HDW-700A

HDCAM

OPERATION MANUAL English

1st Edition

Serial No. 10001 and Higher

WARNING

To prevent fire or shock hazard, do not

expose the unit to rain or moisture.

To avoid electrical shock, do not open

the cabinet. Refer servicing to qualified

personnel only.

For the customers in U.S.A

This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to Part 15

of theFCC Rules. These limits are designed to provide

reasonable protection against harmful interference when

the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in

accordance with the instruction manual, may cause

harmful interference to radio communications. Operation

of this equipment in a residential area is likely to cause

harmful interference in which case the user will be required

to correct the interference at his own expense.

You are cautioned that any changes or modifications not

expressly approved in this manual could void your

authority to operate this equipment.

The shielded interface cable recommended in this manual

must be used with this equipment in order to comply with

the limits for a digital device pursuant to Subpart B of Part

15 of FCC Rules.

For the customers in the USA and Canada

RECYCLING NICKEL-CADMIUM BATTERIES

NICKEL-CADMIUMBATTERY.

BATTERY MUST BE RECYCLED OR

DISPOSED OF PROPERLY.

Nickel-Cadmiumbatteries arerecyclable.

You can help preserve our environment by

returning your unwanted batteries to your

nearest Sony Service Centre or Factory

Service Centre for collection, recycling or

properdisposal.

Note: In some areas the disposal of nickel-

cadmiumbatteries inhousehold orbusiness

trash may be prohibited.

For the Sony Service Centre nearest you call 1-800-222-

SONY(United Statesonly)

For the Sony Service Centre nearest you call 416-499-

SONY(Canadaonly)

Caution: Donothandle damagedorleaking nickel-cadmium

batteries.

Ni-Cd

Table of Contents

Chapter 1 Overview

1-1 Features....................................................................................... 1-1

1-1-1 CameraFeatures................................................................ 1-1

1-1-2 VTRFeatures..................................................................... 1-3

1-2 ExampleofSystemConfiguration........................................ 1-4

1-3 Precautions................................................................................ 1-6

Chapter 2 Locations and Functions of Parts and

Controls

2-1 PowerSupply............................................................................... 2-1

2-2 AccessoryAttachments.............................................................. 2-3

2-3 AudioFunctions.......................................................................... 2-5

2-4 Shooting andRecording/PlaybackFunctions........................2-13

2-5 SetupMenuOperatingSection................................................ 2-27

2-6 TimeCodeSystem......................................................................2-29

2-7 WarningsandIndications.......................................................... 2-35

2-8 WarningsandIndicationsontheDisplayPanel..................... 2-38

Chapter 3 Recording and Playback

3-1 AboutCassettes......................................................................... 3-1

3-1-1 LoadingandUnloadingaCassette................................ 3-1

3-1-2 PreventingAccidentalErasure...................................... 3-4

3-2 Recording................................................................................... 3-5

3-2-1 BasicProcedure.............................................................. 3-5

3-2-2 ContinuousRecording................................................... 3-9

3-3 CheckingtheRecording– Playback...................................... 3-12

3-3-1 Checking the last Three Seconds of the Recording –

Recording Review..................................................... 3-12

3-3-2 Checking the Recording on the ColorVideo Monitor –

Playbackin Color....................................................... 3-13

Table of Contents 1

Chapter 4 Adjustments and Settings for

Recording

4-1 Adjusting the Black Balance and the White Balance and

CorrectingtheWhiteSpots................................................... 4-1

4-1-1 Adjusting the Black Balance....................................... 4-2

4-1-2 Automatic Correction of White Spots in the Image.... 4-4

4-1-3 AdjustingtheWhiteBalance......................................... 4-5

4-2 SettingtheElectronicShutter............................................... 4-9

4-2-1 ShutterModes................................................................ 4-9

4-2-2 SelectingtheShutterModeandSpeed.......................... 4-10

4-3 AdjustingtheAudioLevel..................................................... 4-13

4-4 SettingtheTimeData........................................................... 4-17

4-4-1 Settingthe User Bits.................................................... 4-17

4-4-2 SettingtheTime Code.................................................. 4-19

4-4-3 Enteringthe RealTime intheVITC............................. 4-21

4-4-4 SynchronizingtheTime Code...................................... 4-23

4-5 SetupMenu DisplayontheViewfinderScreen................. 4-28

4-5-1 Basic Use of the Setup Menu..................................... 4-31

4-6 Status Display on the ViewfinderScreen 4-34

4-6-1 Layout of the Status Display on the Viewfinder Screen 4-34

4-7 Setup Using the OPERATION Menu.......................... 4-38

4-7-1 Findinga Page.............................................................. 4-39

4-7-2 Selecting the Items for Which the “!” LED is to Light. 4-40

4-7-3 SettingtheMarker Display.......................................... 4-42

4-7-4 Selectingthe Display Items.......................................... 4-43

4-7-5 SettingtheGAINSelectorValues................................. 4-45

4-7-6 SettingtheViewfinder................................................... 4-47

4-7-7 SettingtheAutomaticIris.............................................. 4-48

4-7-8 Settingthe Battery,D5600K Mode andSelecting the Lens

File................................................................................. 4-50

4-7-9 OperatorFile................................................................. 4-52

4-8 Paint Menu........................................................................... 4-54

2 Table of Contents

4-9 UsingtheSetupCard.............................................................. 4-64

4-9-1 Handlingthe Setup Card............................................. 4-64

4-9-2 Using Data on the Setup Card.................................... 4-66

Chapter 5 Setting Up The Camcorder

5-1 PowerSupply............................................................................ 5-1

5-1-1 Usinga BP-L60A/L90A Battery Pack.......................... 5-1

5-1-2 UsingaBP-90ABattery Pack........................................ 5-4

5-1-3 Avoiding BreaksinOperation Due to DeadBatteries... 5-5

5-1-4 UsinganACAdaptor..................................................... 5-6

5-1-5 Usingthe Anton Bauer UltralightSystem.................... 5-7

5-2 Adjusting theViewfinder......................................................... 5-8

5-2-1 Adjusting theViewfinder Position.............................. 5-8

5-2-2 DetachingtheViewfinder...............................................5-10

5-3 MountingtheLens..................................................................... 5-12

5-4 AdjustingtheFlangeFocal Length......................................... 5-13

5-5 AudioInputSystem .................................................................. 5-15

5-5-1 UsingtheSupplied Microphone.................................... 5-15

5-5-2 UsinganExternal Microphone...................................... 5-18

5-5-3 Attaching a UHF Portable Tuner (for a UHF Wireless

MicrophoneSystem)..................................................... 5-23

5-5-4 ConnectingLineInputAudio Equipment...................... 5-27

5-6 TripodMounting........................................................................ 5-28

5-7 AttachingtheShoulderStrap.................................................. 5-30

5-8 AdjustingtheShoulderPad Position...................................... 5-32

5-9 PuttingOntheRainCover...................................................... 5-33

5-10 Connectingthe RemoteControlUnit................................... 5-36

Table of Contents 3

4 Table of Contents

Chapter 6 Maintenance

6-1 Testing theCamcorderBeforeShooting............................. 6-1

6-1-1 Preparations forTesting............................................... 6-1

6-1-2 Testingthe Camera........................................................ 6-2

6-1-3 Testing theVTR............................................................. 6-6

6-2 Maintenance...........................................................................6-10

6-2-1 Cleaning theVideoHeads............................................6-10

6-2-2 CleaningtheViewfinder...............................................6-10

6-3 OperationWarnings..............................................................6-12

Appendix

Specifications........................................................................................A-1

VideoCamera Section...............................................................A-2

VTRSection..............................................................................A-3

SuppliedAccessories.................................................................A-6

RecommendedAdditionalEquipment.......................................A-6

Glossary..................................................................................................A-9

Index........................................................................................................1-1

1-1 Features

The HDW –700A HD Camcorder combines a HD color video camera, of

which effective picture elements is 1920(H) x 1080(V) and which uses

2/3 inch FIT1) CCD2) imagers with 2,000,000 picture elements, with an

HDCAMportable videocassette recorder. Its excellentportability and

dust- and water-proof construction make it ideal as a camcorder for

ENG3) and EFP4) in the same way as the earlier DVW-700, which is the

Digital BETACAM model. The introduction of a new method of

processingHD digital signalsimproves the imagequality even further

and simplifies setup (initialization) operations.

1-1-1 Camera Features

The features of the HDW-700Acamera are described below.

•2/3 inch FIT CCDs with 2,000,000 picture elements provide a compact

and lightweight unit with excellent image quality.

• Existing 2/3 inch lenses can be used.

• Digitalsignal processing has improved picture quality,stability, and

reliability.

• A setup menu enables you to control features such as status displays,

messages, and markers; to select various types of settings; to toggle

switches; and to operate a setup card.

• Blur-free shooting is ensured by a built-in, high-performance electronic

shutter that provides a variety of modes, such as ECS5) mode which

reduces flickering on the monitor screen and S-EVS6) mode which

improves vertical resolution.

• Selectablevideo gain ensuresa noise-free image.

• Asimpleswitchoperation enables automatic adjustment ofthe black set,

black balance, and white balance. Memory functions make it easy to

replicatethewhitebalancesettingappropriateforthelightingconditions.

1)FIT: Frame InterlineTransfer

2)CCD: Charge-Coupled Device

3)ENG: ElectronicNewsGathering

4)EFP: ElectronicFieldProduction

5)ECS: Extended ClearScan

6)S-EVS: SuperEnhancedVerticaldefinitionSystem Chapter 1 Overview 1-1

○○○ ○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

• Characterdisplay functions onthe viewfinder indicateswitch settings,

automatic black and white balance adjustment, status indications, and

warnings.

• Thewarning system usesvarious types ofwarning indicators and

sounds to inform you ofVTR faults, end of tape, low battery, etc.

• The camcorder is equipped with a dual-wheel filter disk for adjusting

the filter setting to shooting and lighting conditions.

• Override function which makes fine adjustment of the reference value

for brightness of automatic iris control is provided.

• Abuilt-in circuit produces a color bar signal for easy adjustment of the

color monitor.

• The remote control unit controls camera functions and VTR functions.

• Setup data specified by the camera operator, including the various

marker settings, can be stored in the camcorder itself or on a setup

card as an operator file, and then can be recalled.

• Setupdata specified byvideo engineers, including the variousdetail

settings, can be stored in the camcorder itself and on a setup card as a

reference file, and then can be recalled. It is possible to shorten time for

setting with duplicating the stored reference file to the other cameras

through the setup card,

• Setupdata specified byvideo engineers, includingthevideo settings,

can be stored as a scene file. It is possible to recall the setup data

appropriate for the scene.

• Correction value to use a lens extender and for each lens can be stored

as a lens file, and then can be recalled. It is possible to shorten time for

adjustment when replacing the lens.

• Ahigh-performanceviewfinder isadjustableforward, backward, and

sideways, and has a full range of auxiliary equipment.

1-2 Chapter 1 Overview

Altri manuali per HDCAM HDW-700A

Indice

Altri manuali Sony Videocamera

Sony

Sony HXR-MC1500P Manuale utente

Sony

Sony MHS-CM1/V - Webbie Hd™ Mp4 Camera Manuale utente

Sony

Sony DCR-DVD205 Nero Express 6 Manuale utente

Sony

Sony HVR-Z7J Manuale utente

Sony

Sony D8 Digital Handycam DCR-TRV210E Manuale utente

Sony

Sony MHS-TS10 - Bloggie™ Touch Camera Manuale operativo e di manutenzione

Sony

Sony Handycam DCR-SR190E Manuale utente

Sony

Sony HANDYCAM DCR-HC51E Manuale utente

Sony

Sony Handycam CCD-TR300 Manuale utente

Sony

Sony HANDYCAM Manuale utente

Sony

Sony Handycam HDR-CX190E Manuale utente

Sony

Sony DCR-PC1000 Manuale utente

Sony

Sony DVCAM DSR-PD150 Manuale utente

Sony

Sony Handycam CCD-TR40 Manuale utente

Sony

Sony Handycam CCD-TR415E Manuale utente

Sony

Sony Handycam CCD-FX310 Manuale utente

Sony

Sony HDR-AS300R Guida di riferimento

Sony

Sony DCR-TRV130 - Digital8 Camcorder Manuale utente

Sony

Sony Digital Handycam DCR-PC8E Manuale utente

Sony

Sony DCR-IP210E Manuale utente

Sony

Sony Handycam Vision DCR-SC100E Manuale utente

Sony

Sony PMW-EX1R Manuale utente

Sony

Sony Video 8 Handycam CCD-TR7 Manuale utente

Sony

Sony HDR UX1 - AVCHD 4MP High-Definition DVD... Manuale utente

Manuali Videocamera popolari di altre marche

Toshiba

Toshiba CAMILEO Z100 Manuale utente

Panasonic

Panasonic NV-VS40B Manuale utente

Canon

Canon RC 260 Manuale utente

Brinno

Brinno TimeLapse TLC200 Manuale utente

JVC

JVC GR-SXM68AC Guida rapida

Panasonic

Panasonic AG-HMC152EN Manuale utente

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Manuale utente

MYDLINK

MYDLINK DCS-6100LH Manuale utente

SECURECOM

SECURECOM V-5014B Manuale utente

Panasonic

Panasonic HDC-SD100 Manuale utente

Sharper Image

Sharper Image U-VIDEO Manuale utente

JVC

JVC AA-V15EG Manuale utente

Canon

Canon LEGRIA HV40 Manuale utente

RCA

RCA CC616 Manuale utente

Panasonic

Panasonic NVM40 Manuale utente

ATIK Cameras

ATIK Cameras Horizon Manuale utente

Sharp

Sharp ViewcamZ VL-Z8H Manuale utente

Philips

Philips M620/21 Manuale utente
