Sony VCT-FS7 Manuale utente

SERVICE MANUAL

Sony Corporation

Published by Sony Techno Create Corporation

VCT-FS7

SPECIFICATIONS

LIGHT WEIGHT ROD SUPPORT

9-896-107-01

2014K33-1

US Model

Canadian Model

AEP Model

Chinese Model

Ver. 1.0 2014.11

Dimensions (W / H / D) Approx. 118 × 63.2 × 250 mm (4 3/4× 2 1/2× 9 7/8inches)

Mass Unit: 980 g (2 lb 2.6 oz), Rod (1): 160 g (5.6 oz)

Supplied items Operating Instructions (2), screws (+B M3×8) (10),

screw (3/8 in.) (1) , Φ15 rods (2)

Design and specications are subject to change without notice.

he VCT-FS7 is an accessory that attaches to Sony PXW-FS7 camcorders to

improve camera stability when shooting. Attaching the unit to the PXW-FS7 also

enables the camera to be mounted on a VCT-14/VCT-U14 tripod attachment.

Note: PXW-FS7 is not included in this unit.

VCT-FS7

SECTION 1

EXPLODED VIEW

1 3-729-072-01 SCREW, +K (4X8)

2 X-2591-123-1 V SHOE (7000) ASSY

3 4-564-770-01 FRONT BASE

4 4-458-121-01 LEVER, INSIDE

5 4-458-124-11 SPRING, ROD LOCK

6 4-562-252-01 SCREW, ROD LOCK

7 4-546-932-01 RING, ROSSETTE

8 A-2068-906-A BASE ASSY, REAR

9 3-626-781-03 STOPPER

10 3-364-941-11 SCREW (+B) (2.6X5), NYLOK

11 X-2590-808-1 SHOULDER PAD ASSY (SA)

(Adjustable shoulder pad)

#1 7-627-556-58 SCREW +P 2.6X5

*#2 7-688-004-02 W 4, SMALL

#3 7-682-548-09 SCREW +B 3X8

#4 7-623-923-01 WASHER 2.6, NYLON

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

Note:

• -XX and -X mean standardized parts, so

they may have some difference from the

original one.

• Items marked “*” are not stocked since

they are seldom required for routine ser-

vice. Some delay should be anticipated

when ordering these items.

• The mechanical parts with no reference

number in the exploded views are not sup-

plied.

• Color Indication of Appearance Parts Ex-

ample:

KNOB, BALANCE (WHITE) . . . (RED)



Parts Color Cabinet’s Color

not supplied

#4 #4

#1 #1

not supplied

Ref. No. Part No. Description Remark

VCT-FS7

SECTION 2

ACCESSORIES

*4-564-777-01 MANUAL, INSTRUCTION

(JAPANESE, ENGLISH, FRENCH, GERMAN)

*4-564-777-11 MANUAL, INSTRUCTION (SPANISH, DUTCH,

ITALIAN, PORTUGUESE, SIMPLIFIED CHINESE)

501 4-458-485-02 15X250 ROD (1 piece) (Φ15 rod)

502 4-564-773-01 SCREW, BINDING 3/8

(Retaining screw (3/8 in.) for rear base)

503 7-682-548-09 SCREW +B 3X8 (1 piece)

(Retaining screw (+B M3x8) for rear base)

504 4-547-069-11 VF ROD (for Service)

501

ø 15 rods (2)

502

Retaining screw (3/8 in.) for rear base (1)

503

Retaining screws (+B M3 u8) for rear base (10)

504

Viewfinder rod

Note: This part is not an accessory.

The length of the viewfinder rod may be insufficient

when attaching the PXW-FS7 adjustable shoulder pad

at the forefront position.

In that case, use the viewfinder rod (for service),

which is 20 mm longer than the standard viewfinder rod.

• Items marked “*” are not stocked since

they are seldom required for routine ser-

vice. Some delay should be anticipated

when ordering these items.

VCT-FS7

REVISION HISTORY

Checking the version allows you to jump to the revised page.

Also, clicking the version at the top of the revised page allows you to jump to the next revised page.

Ver. Date Description of Revision

1.0 2014.11 New
