Sony XR-C5100 Guida rapida

MICROFILM

SERVICE MANUAL

US Model

Canadian Model

E Model

XR-C5100

Model Name Using Similar Mechanism XR-4800

Tape Transport Mechanism Type MG-25F-136

AUDIO POWER SPECIFICATIONS (US model)

POWER OUTPUT AND TOTAL HARMONIC DISTORTION

17 watts per channel minimum continuous average power into 4 ohms,

4 channels driven from 20 Hz to 20 kHz with no more than 1% total

harmonic distortion.

Cassette player section

Tape track 4-track 2-channel stereo

Wow and flutter 0.08% (WRMS)

Frequency response 30 – 18,000 Hz

Signal-to-noise ratio 58 dB

Tuner section

Tuning range FM tuning interval:

87.5 – 107.9 MHz

(US, Canadian model)

50 kHz/200 kHz switchable

87.5 – 108.0 MHz (at 50 kHz step)

87.5 – 107.9 MHz (at 200 kHz step)

(E model)

Antenna terminal External antenna connector

Intermediate frequency 10.7 MHz

Usable sensitivity 8 dBf

Selectivity 75 dB at 400 kHz

Signal-to-noise ratio 65 dB (stereo),

68 dB (mono)

Harmonic distortion at 1 kHz

0.5% (stereo),

0.3% (mono)

Separation 35 dB at 1 kHz

Frequency response 30 – 15,000 Hz

Capture ratio 2 dB

AM (MW)

Tuning range AM tuning interval:

530 – 1,710 kHz

(US, Canadian model)

MW tuning interval:

9 kHz/10 kHz switchable

531–1,602 kHz (at 9 kHz step)

530 – 1,710 kHz (at 10 kHz step)

(E model)

Antenna terminal External antenna connector

Intermediate frequency 10.71 MHz/450 kHz.

Sensitivity 30 µV

SW (E model)

Tuning range SW tuning interval:

SW1: 2,940 – 7,735 kHz

SW2: 9,500 – 18,135 kHz

(except for 10,140 – 11,575 kHz)

Antenna terminal External antenna connector

Intermediate frequency 10.71 MHz/450 kHz

Sensitivity 50 µV

SPECIFICATIONS

US, Canadian Model

FM/AM CASSETTE CAR STEREO

E Model

FM/MW/SW CASSETTE CAR STEREO

– Continued on next page –
