SCD-XA777ES

ES Super Audio CD Player

• Tri-Powered Digital to Analog Converters

• 6 Super Audio Digital to Analog Converters (1 Per Channel)

• Frame and Beam Chassis Design

• Triple Audio Boards

• Dual R-Cone Power Transformers

• Dual User Assembly Optimized for SACD/CD Playback

Playback Section

• Multi-Channel Super Audio

CD Playback Capability

• CD/CD-R/CD-RW Playback

Capability

• Tri-Powered Super Audio

D/A Converter System

• Multi-Channel Direct

Stream Digital™ Decoder

• Multi-Channel Management

System

• Discrete Laser/Optical Pick

Up System with Dual

Lasers

• Direct Digital Synch D/A

Clock System

• Direct Disc Selection plus

Track Access via Jog Dial®

Control

• 32 Step Programming

• All Disc/All Track Repeat

Functions via Remote

• SACD Text/CD Text

Capability

Construction

• Fixed Line Output

• Unbalanced Audio Output

• Optical and Coaxial Digital

Outputs for CD Selection

• 6 Multi-Channel Analog

Output, plus Stereo Line

Level Output for CD and

SACD

• Control A-1 II for

Connection to Sony

Components

• Frame and Beam Chasis

Construction

• Dual R-Core Power

Transformers

• Gold Plated Line Outputs

• Aluminum Front Panel

• Off-Center Insulator Feet

KEY FEATURES

ADDITIONAL FEATURES

Product Information

Double Layer

Bottom Plate

Front Panel

Front Chassis

Rear Panel

Audio Circuit Board

R-core Transformer

(copper plate)

Main Digital

Board

Mechanism

Drive Unit

Frame and Beam Chassis

ADDITIONAL FEATURES

KEY TECHNOLOGY

Specifications

SACD Playback

• PlaybackFrequencyRange:

2Hz - 100kHz

• Frequency Response:

2Hz - 50kHz (-3dB)

• Dynamic Range:

More than 108dB

• Harmonic Distortion:

Less than 0.0018%

• Wow and Flutter:

Below Measurement Limit

(±0.001% W-Peak)

CD Playback

• DAC Converter:

Super Audio D/A

• Frequency Response:

2Hz - 20kHz (± 0.5dB)

(EIAJ)

• Dynamic Range:

More than 99dB

• Harmonic Distortion:

Less than 0.0020% (EIAJ)

• Wow and Flutter:

Below Measurement Limit

(±0.001% W-Peak)

• Total Output Level:

Digital Opt: -18dB(fix)

Digital Coax: 0.5Vp-p (fix)

Analog Unbalance:2Vrms

(fix)

Headphone: 10mW

Inputs and Outputs

• 5.1 Channel RCA Output

• 2 Channel RCA Output

• Coaxial / Optical Digital

Output (CD Only)

General

• Power Requirements:

AC120V, 60Hz

• Power Consumption (in

Operation): 38W

Accessories

Supplied Accessories

• Instruction Manual

• Remote Control

• AA Battery x 2

• Detachable Power Cord

Weights & Measures*

• Dimensions (W x H x D):

17" x 5.4" x 16.1"

• Weight: 35 lbs.

Product Information

SCD-XA777ES

ES Super Audio CD Player

reserved. Features and specifications are

subject to change without notice.

*Weights and Measures are approximate.
