Sony 55365J Manuale utente

Xperia XZs_00_Introduction.docx

About the User Guide

Thank-you for purchasing this product.

 Before Using This Product

 Descriptions in the User Guide

 Screenshots & Key Labels

 Other Notations

Before Using This Product

 Read "Safety Precautions" and this guide thoroughly beforehand for proper usage.

 Accessible services may be limited by contract conditions.

Descriptions in the User Guide

In the User Guide, most operation descriptions are based on handset at time of purchase.

Unless noted otherwise, descriptions are for Home Screen. Some operation descriptions may be

simplified.

Screenshots & Key Labels

Screenshots in the User Guide may differ in appearance with actual Display. Key labels in the User

Guide are simplified for description purposes and differ with actual Display.

Other Notations

In the User Guide, the product is referred to as "handset."

microSD™/microSDHC™/microSDXC™ Card is referred to as "SD Card."

Xperia XZs_00_Introduction.docx

Accessing Instructions on Handset

For those unfamiliar with handset operation, handset includes an application for

learning touch operation and checking how to make settings.

 Launching Guide

Launching Guide

In Home Screen, (SoftBank) (Guide)

Guide top screen opens.

 Information on usage of (Guide) appears at initial startup. Follow onscreen instructions.

Xperia XZs_01_Getting Started.docx

Parts & Functions

 Handset

 Handset Keys

 CE mark and FCC ID

Handset

Part

Description

Headphone Port

Connect commercially

available headphones.

This port supports

tetrapolar headset that

conforms to the CTIA

standard.

Second Mic

Reduces noise for

calling.

Notification Lamp

Flashes for incoming

transmissions. Lights

while charging.

NFC/Osaifu-Keitai

Detection Area

sticker is attached

at time of purchase.

Front Camera

Use to shoot still

images or videos of

yourself.

Earpiece/Speaker

Hear the other party's

voice here.

Also, hear sound

(music, videos, TV,

etc.) from here.

Proximity/Light

Sensor

Detects surrounding

brightness to

automatically adjust

Display or backlight

and prevent

Touchscreen

Xperia XZs_01_Getting Started.docx

misoperation during a

call.

Display

Touchscreen-type

display, operate with

your fingers on

Display.

Speaker

Speak here.

Part

Description

Camera

Capture still images

and videos.

Internal

Antenna/GPS

Antenna Area

Internal Antenna for

calls, data

communication and

GPS.

RGBC-IR Sensor

Flash/Photo Light

Use as camera flash

when taking photos,

etc.

Wi-Fi®/Bluetooth®

Antenna Area

Internal Antenna for

Wi-Fi and Bluetooth®

feature.

LaserAF Sensor

Nameplate

CE mark, FCC ID,

IMEI information

printed sticker is

attached. Do not

remove nameplate.

Wi-Fi Antenna

Area

Internal Antenna for

Wi-Fi.

Internal Antenna

Area

Internal Antenna for

call and data

communication.

SIM Card/SD Card

Slot

Insert SIM Card/SD

Card.

If SIM Card/SD Card

Slot Cover is pulled

out, handset reboots.

USB Type-C Port

Connect commercially

Xperia XZs_01_Getting Started.docx

available USB Type-C

Cable, etc.

Mic

Speak here.

Handset Keys

Part

Description

Power

Key/Screen

Lock

Key/Fingerpr

int Sensor

()

Long Press for power on/off.

Press for sleep mode on/off.

Or, use Fingerprint

authentication.

Volume/Zoo

m Up/Down

Key

Adjust Volume.

Adjust Zoom while using

Camera.

Camera

Key ( )

Use as Camera shutter.

Long Press to launch Camera.

CE mark and FCC ID

Open the slot cover, and insert a fingernail into the hook at the edge of the label tray,

then pull it out straight.

Xperia XZs_01_Getting Started.docx

SIM Card

SIM Card is an IC card containing phone number and other customer information.

 Inserting SIM Card

 Removing SIM Card

 SIM-Unlocking Handset

Inserting SIM Card

Always unmount SD Card beforehand. For details, see "Unmounting SD Card."

Draw SIM Card/SD Card Slot Cover out using groove

Draw Tray out straight from handset

Xperia XZs_01_Getting Started.docx

Set SIM Card into Tray with IC chip facing up

 Check SIM Card orientation by notch.

 Firmly set SIM Card so as not to come off from Tray.

Insert Tray with SIM Card straight into handset

Xperia XZs_01_Getting Started.docx

 Check Tray orientation.

Push Tray all the way and press it down where indicated ○, and make sure there are no

gaps

Removing SIM Card

Always unmount SD Card beforehand. For details, see "Unmounting SD Card."

Draw SIM Card/SD Card Slot Cover out using groove

Xperia XZs_01_Getting Started.docx

Draw Tray out straight from handset

Remove SIM Card from Tray
