Sony XPERIA SERIES Manuale utente

USER GUIDE

1. Charging/Notification light

2. Headset jack

3. Front camera lens

4. Ear speaker/Second

loudspeaker

5. Second microphone

6. Proximity/Light sensor

7.Volume/Zoom key

8. Power key/Fingerprint sensor

11. Charger/USB Type-C™ cable port

12. Main camera lens

13. Laser AF sensor

14. RGBC-IR sensor

15. Flashlight

16. Wi-Fi/Bluetooth®antenna area

17. Nano SIM/Memory card slotcover

18. NFC detection area

19. Main cellular antennaarea

USER GUIDE

9. Camera key

10. Main loudspeaker

20. Main microphone

Fingerprintfunctionalit

y is not available in the

US market.

Assembly

Your device only supports nano SIM cards. The nano SIM cards and the memory

card have separate slots. Make sure you don’t confuse the two.

To prevent data loss, make sure you turn off your device or unmount the

memory card before you drag out the holder to remove the nano SIM card (or

cards) or memory card from the device.

To insert a nano SIM card and a memory card

Do not cut your SIM card, as this may damage your device.

1. Drag out the memory card tray and the SIM card tray.

2. Place the SIM card securely in the SIM card tray, as shown in the video.

3. Place the memory card securely in the memory card tray, as shown in the

video.

4. Gently push first the SIM card tray, then the memory card tray, back into

their slots until they fit into place.

To insert one or two nano SIM cards

Using two SIM cards and a memory card at the same time is not possible. The

memory card tray allows you to use either a second SIM card or an additional

memory card. Do not cut your SIM card, as this may damage your device.

1. Drag out the memory card tray and the SIM card tray.

USER GUIDE

2. Place the main SIM card securely in the SIM card tray, as shown in the

video.

3. Place the second SIM card securely in the memory card tray in the correct

orientation, as shown in the video.

4. Gently push first the SIM card tray, then the memory card tray, back into

their slots until they fit into place.

To remove a nano SIM card

1. Turn off your device.

2. With the screen facing down, open the nano SIM/Memory card slot cover.

3. Drag out the SIM and memory card trays using your fingernail.

4. Remove the nano SIM card. Gently push the SIM and memory card trays

back into their slots until they fit into place.

5. Close the nano SIM/Memory card slot cover.

To remove a memory card

1. Turn off your device.

2. With the device facing down, open the nano SIM/Memory card slot cover.

USER GUIDE

3. Remove the memory card from the tray.

4. Close the nano SIM/Memory card slot cover.

Screen protection

Before using your device, remove the protection film by pulling up on the

protruding tab.

It is recommended to protect your device with a Sony branded screen cover or a

protector intended for your Xperia™ model. The use of third party screen

protection accessories may prevent your device from working correctly by

covering sensors, lenses, speakers, or microphones and can invalidate the

warranty.

Starting your device for the first time

It is recommended that you charge the battery for at least 30 minutes before

starting up your device for the first time. You can still use your device while it is

charging. For more information on charging, see Charging your device.

The first time you start your device, a setup guide helps you to configure basic

settings, personalise your device and sign in to your accounts, for example a

Google™ account.

To turn on the device

It is important to use the USB Type-C™ cable (provided) when charging your

device, as other types of USB cables can damage your device. It is

recommended to charge the battery for at least 30 minutes before you turn

on the device for the first time.

1. Press and hold down the power key until the device vibrates.

USER GUIDE

2. Enter your SIM card PIN when requested, then tap .

3. Wait a moment for the device to start.

Your SIM card PIN is initially supplied by your network operator, but you

can change it later from the Settings menu. To correct a mistake made

while entering your SIM card PIN, tap .

To turn off the device

1. Press and hold down the power key until the options menu opens.

2. In the options menu, tap Power off.

It may take a while for the device to shut down.

Why do I need a Google™ account?

Your Xperia™ device from Sony runs on the Android™ platform developed by

Google. A range of Google applications and services is available on your device

when you purchase it, for example, Gmail™, Google Maps™, YouTube™ and the

Play Store™ application, which gives you access to the Google Play™ online store

for downloading Android applications. To get the most out of these services, you

need a Google account. For example, a Google account enables you to do the

following:

Download and install applications from Google Play.

Synchronise your email, contacts and calendar using Gmail.

Chat with friends using the Duo™ application.

Synchronise your browsing history and bookmarks using the Google

Chrome™ web browser.

USER GUIDE

Identify yourself as the authorised user after a software repair using

Xperia™ Companion.

Remotely find, lock or clear a lost or stolen device using the Android Device

Manager services.

For more information about Android and Google, go to

http://support.google.com.

It is crucial that you remember your Google account username and password.

In some situations, you may need to identify yourself for security reasons

using your Google account. If you fail to give your Google username and

password in such situations, your device is locked. Also, if you have more than

one Google account, make sure to enter the details for the relevant account.

To set up a Google™ account on your device

1. From your Home screen, tap .

2. Find and tap Settings > Accounts & sync > Add account > Google.

3. Follow the registration wizard to create a Google™ account, or sign in if you

already have an account.

You can also sign in to or create a Google™ account from the setup guide

the first time you start your device. Alternatively, you can go online and

create an account at www.google.com/accounts.

To remove a Google™ account

1. From your Home screen, tap .

2. Tap Settings > Accounts & sync > Google.

3. Select the Google™ account that you want to remove.

USER GUIDE

4. Tap > Remove account.

5. Tap Remove account again to confirm.

If you remove your Google™ account, any security features that are linked to

your Google™ account will no longer be available.

Making sure your device is protected

Your device includes security options, strongly recommended in case of loss or

theft:

Set a secure screen lock on your device using a PIN, password or pattern to

prevent anyone from accessing or resetting your device.

Add a Google™ account to prevent others from using your device if it gets

stolen or wiped.

Activate the Android™ Device Manager web service. Using this service, you

can remotely locate, lock or clear a lost device.

Verifying the ownership of your device

Certain protection features require you to either unlock your screen with your

PIN, password, pattern, or enter your Google™ account information. Below are

examples of protection features and their required credentials:

Factory Data Reset protection: You must unlock your screen before you are

allowed to perform a Factory Data Reset.

Android™ Device Manager: If you remotely reset your device using this

service, you must enter the username and password for a Google™

account. The device must be connected to the Internet before the setup

USER GUIDE

process can be completed. Otherwise, you will not be able to use your

device after the reset.

Xperia™ Companion Software repair: Use the Xperia™ Companion software

to perform software repair.

For Android Device Manager, it is necessary to enter information from a

Google account. This can be any Google account which you have set up on the

device as an owner. If you cannot provide the relevant account information

during a setup process, you won't be able to use the device at all.

Screen lock

Fingerprint functionality is not available in the US market.

There are several screen lock options available. The security level of each lock

type is listed below in order of weakest to strongest:

Swipe: no protection, but you have quick access to the Home screen.

Pattern: draw a simple pattern with your finger to unlock your device.

PIN: enter a numeric PIN of at least four digits to unlock your device.

Password: enter an alpha-numeric password to unlock your device.

Fingerprint: place your registered finger on the power key to unlock your

device.

It is very important that you remember your screen lock pattern, PIN or password.

If you forget this information, it may not be possible to restore important data

such as contacts and messages. If you have set up a Microsoft® Exchange

ActiveSync® (EAS) account on your Xperia™ device, the EAS security settings may

limit the lock screen type to only a PIN or password. This occurs when your

network administrator specifies a lock screen type for all EAS accounts for

enterprise security reasons. Contact the network administrator of your company

or organisation to check what network security policies are implemented for

mobile devices.

USER GUIDE

When you have a screen lock selected, tap beside Screen lock for

additional settings.

To change your screen lock type

1. From your Home screen, tap .

2. Find and tap Settings > Lock screen & security > Screen lock.

3. Confirm your current screen lock, choose an option and follow the

instructions on your device.

To create a screen lock pattern

1. From your Home screen, tap .

2. Find and tap Settings > Lock screen & security > Screen lock > Pattern.

3. Choose an option and follow the instructions on your device.

If you enter an incorrect lock pattern five times in a row, you must wait 30

seconds before trying again.

To change the screen lock pattern

1. From your Home screen, tap .

2. Find and tap Settings> Lock screen & security > Screen lock.

3. Draw your screen unlock pattern.

4. Tap Pattern, choose an option and follow the instructions on your device.

To create a screen lock PIN

1. From your Home screen, tap .

USER GUIDE

2. Find and tap Settings > Lock screen & security > Screen lock > PIN.

3. Choose an option. Enter a numeric PIN, then tap CONTINUE.

4. Re-enter and confirm your PIN, then tap OK.

To create a screen lock password

1. From your Home screen, tap .

2. Find and tap Settings > Lock screen & security > Screen lock > Password.

3. Choose an option and follow the instructions on your device.

To activate the Swipe unlock function

1. From your Home screen, tap .

2. Find and tap Settings > Lock screen & security > Screen lock.

3. Draw your screen unlock pattern, or enter your PIN or password depending

on which of these screen lock types is enabled.

4. Tap Swipe, then tap YES, REMOVE.

Fingerprint unlock

Fingerprint functionality is not available in the US market.

You can use your fingerprint to quickly unlock your device. To use this feature,

you need to register a fingerprint and enable this feature in the Fingerprint

Manager first.

The pattern, PIN or password screen lock you set up serves as a backup unlock

method if you enable the Fingerprint unlock option. Selecting other screen lock

types will clear all fingerprint settings.

Indice

Altri manuali Sony Telefono cellulare

Sony

Sony Xperia 1 Guida utente

Sony

Sony Xperia V Manuale utente

Sony

Sony Xperia C2305 Manuale utente

Sony

Sony Xperia Z5 Premium Manuale utente

Sony

Sony Xperia Z3 Compact Guida di riferimento rapido

Sony

Sony Xperia ZL Manuale utente

Sony

Sony ST27i Manuale utente

Sony

Sony Xperia Z1 Compact Manuale utente

Sony

Sony XPeria ST25i Manuale utente

Sony

Sony Xperia T2 Ultra dual D5322 Manuale utente

Sony

Sony Xperia Z1 Manuale utente

Sony

Sony D6502 Manuale utente

Sony

Sony COM-1/W - Mylo™ Personal Communicator Manuale d'uso e manutenzione

Sony

Sony Xperia XA F3116 Manuale utente

Sony

Sony Xperia C5 Ultra Dual Manuale utente

Sony

Sony Xperia M5 Manuale utente

Sony

Sony Xperia Z3 Manuale utente

Sony

Sony Xperia E4 Dual E2114 Guida di riferimento rapido

Sony

Sony Xperia Z5 Compact Manuale utente

Sony

Sony Xperia Z C6603 Manuale utente

Sony

Sony PM0890 Manuale utente

Sony

Sony H8266 Guida utente

Sony

Sony Xperia Z1 Manuale utente

Sony

Sony XPERIA X Performance SOV33 Manuale di servizio

Manuali Telefono cellulare popolari di altre marche

Zte

Zte BLADE A520 Manuale utente

Nokia

Nokia Lumia 620 Manuale utente

Blackbe;rry

Blackbe;rry KEYone Manuale utente

Bea-fon

Bea-fon X5 Premium Manuale utente

Blackbe;rry

Blackbe;rry 8707 Series Manuale utente

Blackbe;rry

Blackbe;rry Storm Istruzioni operative

LG LM-X420QN Manuale utente

LifeWatch

LifeWatch V Manuale utente

Bea-fon

Bea-fon SILVER LINE SL860 Manuale utente

IKI Mobile

IKI Mobile KF4.5i Manuale utente

Hitech

Hitech HT-850 Manuale utente

Yezz

Yezz Fashion F10 Manuale utente

Point Mobile

Point Mobile PM60 Manuale utente

Blackbe;rry

Blackbe;rry Q10 Manuale utente

Blackbe;rry

Blackbe;rry Bold 9900 Manuale utente

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuale utente

LG LM-K420EMW Manuale utente

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale utente
