Sony VAIO PCG-SRX51P Manuale utente

Specifications

Model name PCG-SRX51P

Model number PCG-461M

Operating system Microsoft®Windows®XP Professional

Processor Low Voltage Mobile Intel®Pentium®III processor 800A MHz-M

Hard disk drive 30 GB

Standard RAM 256 MB SDRAM (128 MB on board, 128 MB in slot)

Maximum RAM 384 MB

LCD screen 10.4'' XGA (1024x768) p-Si TFT screen

L2 cache memory 512 KB (on die)

Graphics Intel®815EM Chipset with integrated graphics accelerator

Video RAM: max. 11 MB (shared with main memory) with 3D accelerator

DVM (Dynamic Video Memory)

Sound capabilities 16-bit CD-quality stereo sound

Internal modem Built-in V.90/K56Flex (56kbps) data/fax modem

Specifications

DVD-ROM drive External i.LINK™ DVD-ROM drive:

up to 24x max. CD-ROM reading speed

up to 8x max. DVD-ROM reading speed

laser diode properties:

wave length: DVD 660 nm / CD 785 nm

laser output: DVD 14.1 µW / CD 30.2 µW

Telecommunication capabilities Ethernet network, PSTN data connectivity, Wireless LAN, Bluetooth™ functionality

Expansion capabilities One PC Card type I/II Card and CardBus support

Built-in capabilities Stereo speakers, touchpad, Jog Dial™ with back button, MagicGate Memory Stick™

Special buttons Jog Dial™, Wireless switch

Connection capabilities on notebook External speakers/headphone (with MEGA BASS), external microphone, USB port, 1 type I or II

PC Card slot, i.LINK™ (IEEE1394) S400, Ethernet (10 BASE-T/100 BASE-TX), phone line, monitor

connector (on display adapter), MagicGate Memory Stick™ slot

Supplied accessories Rechargeable battery, AC adapter, AC power cord, phone cable,

phone plug, display adapter, i.LINK™ DVD-ROM drive

Power source 16V DC/ AC100 - 240V

Power management ENERGY STAR®compliant

ACPI (Advanced Configuration & Power Interface)

Model name PCG-SRX51P

Model number PCG-461M

Specifications

Battery 6 cells lithium ion

Dimensions

Width

Height

Depth

259.0 mm

27.8 mm to 32.0 mm

194.0 mm

Weight

With battery

1.26 kg

Operating temperature +5°C to +35°C (temperature gradient less than +10°C/hour)

Storage temperature -20°C to +60°C (temperature gradient less than +10°C/hour)

Operating humidity 20% to 80% (not condensed), provided that humidity is less than 65%

at +35°C (hygrometer reading of less than +29°C)

Storage humidity 10% to 90% (not condensed), provided that humidity is less than 20%

at +60°C (hygrometer reading of less than +35°C)

Wireless communication:

Method of communication:

Bluetooth™

Bluetooth™ standard version 1.1

Maximum communication speed (1) Max. 723 kbps

Output Bluetooth™ standard Power Class 1

Model name PCG-SRX51P

Model number PCG-461M

Specifications

Communication distance (2) Approx. 10 –100 m (open space)

Compatible Bluetooth™ profiles (3) Generic Access Profile

Service Discovery Application Profile

Serial Port Profile

Dial-up Networking Profile

Fax Profile

Object Push Profile

Generic Object Exchange Profile

LAN Access Profile

Usable frequency band 2.4 GHz band (2.400 GHz - 2.4835 GHz)

Bluetooth™ software BlueSpace

Wireless communication:

Method of communication:

Wireless LAN

IEEE802.11b standard (IBSS Ad hoc mode support)

Usable frequency band 2.4 GHz band (2.400 GHz - 2.474 GHz)

Maximum communication speed (4) Max. 11 Mbps

Communication distance (5) Approx. 10-100 m (open space)

Wireless channels From 1 to 11

Modulation method DS-SS (IEEE802.11b standard)

Model name PCG-SRX51P

Model number PCG-461M

Specifications

Specifications are subject to change without notice.

(1) The maximum communication speed of the Bluetooth™ standard version 1.1 can vary depending on the obstacles or the distance between

the communication devices, the radio waves, the operating system or the software you use.

(2) Communication distance can vary depending on the obstacles between the communication devices, the radio waves, the operating system

or the software you use.

(3) These profiles show what you can do with devices compatible with the Bluetooth™ functionality.

(4) The maximum communication speed of the IEEE802.11b standard can vary depending on the obstacles or the distance between the

communication devices, the radio waves, the operating system or the software you use.

(5) Communication distance can vary depending on the obstacles between the communication devices, the radio waves, the operating system,

the software you use or the surroundings (walls, etc.).

(6) You can type maximum 5 letters (40 bit) and 13 letters (104 bit).

Length of network key (6) 64, 128 bit

Model name PCG-SRX51P

Model number PCG-461M
