Sony VAIO PCG-V505CP Istruzioni per l'installazione

Hardware Guide

PCG-V505 series

Hardware Guide

Read this first

Notice

This manual and the software described herein, in whole or in part, may not be reproduced, translated, or reduced to any

machine-readable form without prior written approval.

Sony Corporation provides no warranty with regard to this manual, the software, or other information contained herein and hereby

expressly disclaims any implied warranties or merchantability or fitness for any particular purpose with regard to this manual, the

software or such other information. In no event shall Sony Corporation be liable for any incidental, consequential, or special damages,

whether based on tort, contract, or otherwise, arising out of or in connection with this manual, the software, or other information

contained herein or the use thereof.

Macrovision: This product incorporates copyright protection technology that is protected by U.S.patents and other intellectual property

rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited

viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

In the manual, the ™ or ® marks are not specified.

Sony Corporation reserves the right to make any modification to this manual or the information contained herein at any time without

notice. The software described herein is governed by the terms of a separate user licence agreement.

Please note that the illustrations in this manual may not necessarily apply to your model. Please see the Specifications

sheet for the specific configuration of your VAIO.

Hardware Guide

Read this first

ENERGY STAR

As an ENERGY STAR Partner, Sony has determined that this product meets the ENERGY STAR guidelines for energy efficiency.

The International ENERGY STAR Office Equipment Program is an international program that promotes energy saving through the use of

computers and their office equipment. The program backs the development and dissemination of products with functions that

effectively reduce energy consumption. It is an open system in which business proprietors can participate voluntarily. The targeted

products are office equipment such as computers, displays, printers, facsimiles and copiers. Their standards and logos are uniform

among participating nations.

ENERGY STAR is a U.S. registered mark.

Owner's record

The serial number and model number are located on the bottom of your Sony computer. Record the numbers and refer to them if you

call VAIO-Link. See also the printed Specifications document.

Hardware Guide

Read this first

Safety information

General

❑Opening the unit, for whatever reason, could lead to damages that are not covered by the guarantee.

❑To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.

❑To prevent fire or shock hazard, do not expose your VAIO computer to rain or moisture.

❑If reporting a gas leak, do not use the modem or a telephone in the vicinity of the leak.

❑Avoid using the modem during a severe electrical storm.

❑To change the backup battery, please contact your nearest Sony Service Centre.

❑Before you connect peripherals, turn off the computer and all peripherals.

❑Connect the power cord only after connecting all cables.

❑Turn on the computer only after turning off all peripherals.

❑Do not move your computer while the system is in Standby mode.

❑The magnetic properties of some objects can have serious consequences for your hard disk drive. They

can erase the data on the hard disk drive and cause the computer to malfunction. Do not place your

computer near or on any objects which emit magnetic fields, mainly:

❑TV sets

❑Speakers

❑Magnets and magnetic bracelets.

Audio/video

❑Audio and picture distortion may occur if this equipment is positioned in close proximity to any

equipment emitting electromagnetic radiation.

Hardware Guide

Read this first

Connectivity

❑Never install modem or telephone wiring during a severe lightning storm.

❑Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.

❑Take care when installing or modifying telephone lines.

❑Use your computer only with the supplied AC adapter. To disconnect your computer completely from

mains voltage, unplug the AC adapter.

❑Make sure that the socket outlet is easily accessible.

❑Never touch uninsulated telephone wire or terminals unless the telephone line has been disconnected

at the network interface.

Hardware Guide

Read this first

Regulatory information

Sony hereby declares that this product is in compliance with the essential requirements and other relevant provisions of European

Directive 1999/5/EC (radio equipment and telecommunications terminal equipment Directive).

Declaration of Conformity

The European Union is targeting the free movement of goods for the internal market and to prevent technical barriers to trade. This

effort has resulted in several EU Directives asking that manufacturers make their products comply with essential standards.

Manufacturers are required to affix the "CE" mark on the products they sell and to draw up a "Declaration of Conformity" (DoC).

Primarily, the Declarations of Conformity are intended for the market surveillance authorities as proof that products satisfy the required

standards. Additionally, Sony provides these EU DoC's on the website http://www.compliance.sony.de as a service to our customers.

You can search for all Declarations of Conformity available for a specific product by typing in the model name in the search box above.

A list of matching documents will be displayed and can be downloaded. Please note that the availability of declarations depends on

the scope of the EU Directives and the individual product specifications.

This product complies with EN 55022 Class B and EN 55024 for use in following areas: residential, commercial and light-industrial.

This product has been tested and found compliant with the limits set out in the EMC Directive for using connection cables not longer

than 3 metres (9.8 feet).

Before activating the built-in modem, please read the Modem Regulations leaflet.

The optical disc drive is classified as a CLASS 1 LASER PRODUCT and complies with the Laser Product Safety Standard EN 60825-1. Repair

and maintenance only by authorised Sony technicians. Improper repairs and use can create safety hazards.

CLASS 1

LASER PRODUCT

TO EN 60825-1

Hardware Guide

Read this first

Please read the Wireless LAN Regulations leaflet before activating the Wireless LAN functionality.

Depending on the country, usage of the Wireless LAN functionality may be restricted. For country-specific details, please refer to the

Wireless LAN Regulations leaflet. The Wireless LAN PC functionality which is incorporated into this unit has passed Wi-Fi certification,

and complies with the interoperability specifications established by WECA (Wi-Fi Alliance).

Hardware Guide

Read this first

Disposing of lithium ion batteries

❑Do not handle damaged or leaking lithium ion batteries. Dispose of promptly and properly at end-of-life.

❑Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type

recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions.

❑The battery pack used in this device may present a fire or chemical burn hazard if mistreated. Do not

disassemble, heat above 60°C (140°F) or incinerate.

❑Dispose of used batteries promptly and properly.

❑Keep away from children.

❑In some areas the disposal of lithium ion batteries in household or business waste may be prohibited.

❑Use the public collection system.

Disposing of internal memory backup battery

❑Your computer is equipped with an internal memory backup battery that should not have to be replaced

during the lifetime of the product. For changing this battery, please contact VAIO-Link.

❑Danger of explosion if the battery is incorrectly replaced.

❑Dispose of properly at end-of-life.

❑In some areas the disposal of lithium ion and other non-hazardous batteries in household or business

waste may be prohibited.Please use the public collection system.

Hardware Guide

Welcome

Congratulations on purchasing a Sony VAIO computer. Sony has combined leading-edge technology in

audio, video, computing and communications to provide you with state-of-the-art personal computing.

Here are the main features you can enjoy:

❑Exceptional performance.

❑Portability - The rechargeable battery pack provides hours of use without AC power.

❑Sony audio and video quality - A high-resolution LCD screen enables you to take advantage of today’s

advanced multimedia applications, games, and entertainment software.

❑Multimedia features – Enjoy audio and video CDs.

❑Interconnectivity – Your computer has Ethernet, USB 2.0 (High-speed/Full-speed/Low-speed) and i.LINK

functionalities. i.LINK is a bidirectional digital interface for exchanging data. With the Memory Stick you

can easily exchange and share digital data with compatible products.

❑Wireless technology – Thanks to the Wireless LAN (IEEE 802.11b) technology, you can communicate

freely, without cables or wires.

❑Windows - Your system includes Microsoft’s Windows XP Professional with Service Pack 1 operating

system.

❑Communications - Access popular online services, send and receive e-mails, browse the Internet.

❑Excellent customer support - If you are experiencing any problems with your computer, please check

the VAIO-Link website for a possible solution:

http://www.vaio-link.com

Before contacting VAIO-Link, please try to solve the problem by reading this guide, your printed Guide

to Troubleshooting and Using the VAIO Recovery and Documentation Disc or the manuals and

help files for the peripherals or software.

Hardware Guide

Welcome

Documentation pack

Your Documentation Pack contains printed information and user guides to read on your computer. The user

guides are compiled in the VAIO Info Centre on the VAIO Recovery and Documentation Disc.

Printed documentation

❑A Getting Started brochure, where you will find a brief description of the items in your box, and how

to setup your computer;

❑A Specifications sheet, containing a table of specifications, a list of bundled software and an overview

of all connectors.

❑A Guide to Troubleshooting, where you will find solutions to common problems, an explanation of

the purpose and use of the VAIO Recovery and Documentation Disc delivered with your computer,

and VAIO-Link information.

❑A Dual Language Operating System leaflet*;

❑A Triple Language Operating System leaflet*;

❑Your Sony Guarantee conditions;

❑A Safety Regulations leaflet;

❑A Wireless Lan Regulations leaflet;

❑A Modem Regulations leaflet.

* Depending on your country. Dual Language Operating Systems are available in Belgium and the Netherlands.

Depending on your country. Triple Language Operating Systems are available in Switzerland.
