Documentation

The following documents are included with your Sony VAIO®computer.

❑User Guide

Explains features of your computer. It also includes information about

the software programs included with your computer, as well as

information on solving common problems. User Guide is provided in

the PDF format, which you can easily browse through and print out.

To view the on-screen guide:

1Double-click the VAIO User Guide icon on the desktop.

2Open the folder for your language.

3Select the guide you want to read.

❑Specifications

The online Specifications describe the hardware and software

configurations of your VAIO computer.

To view the online Specifications:

1Connect to the Internet.

2Go to the Sony online support Web site at

http://www.vaio-link.com.

It is strongly recommended to create recovery discs immediately after

your computer is ready for use because there are no recovery discs

provided with the computer.

For instructions on how to create the recovery discs, see “Creating your

own recovery discs” on page 16.

Important

Printed Documentation

❑Quick Start Guide

Describes the process from unpacking to starting up your VAIO.

❑Troubleshooting and Recovery Guide (this booklet)

Contains solutions to common problems and computer malfunctions,

an explanation of how to make a backup copy of your data and

recover your computer system, and sources of support information.

❑Regulations, Warranty, EULA and Service Support

Contains Sony GUARANTEE conditions, Safety / Regulations,

Modem Regulations, Wireless LAN Regulations,

Wireless WAN Regulations, Bluetooth Regulations,

End User Software License Agreement, and

Sony Support services information.

Non-Printed Documentation

Contents

Documentation ....................................................................2

Printed Documentation .......................................................................... 2

Non-Printed Documentation .................................................................. 2

Important ............................................................................................... 2

Introduction to this guide .....................................................5

Troubleshooting...................................................................8

Computer............................................................................................... 8

What should I do if my computer does not start?............................ 8

What should I do if a BIOS error appears

when I turn on my computer? .................................................. 9

What should I do if the power indicator (Green) lights

but my screen stays blank? ................................................... 10

What should I do if my computer or software

stops responding? ................................................................. 10

What should I do if the battery indicator is flashing

and my computer does not start? .......................................... 10

What should I do if a message window, notifying of

incompatibility or improper installation of the battery pack,

appears and my computer enters Hibernate mode? ............. 11

What should I do if Windows does not start,

showing a message, when I start my computer? .................. 11

What should I do if I cannot remember the BIOS password? ....... 11

System Security................................................................................... 12

How can I protect my computer against security threats,

such as viruses?.................................................................... 12

How do I keep my antivirus software updated? ............................ 12

Troubleshooting

Before using your computer.............................................. 14

Creating your own recovery discs........................................................16

To create recovery discs ...............................................................17

Backing up and restoring your data using

Backup and Restore Center ......................................................... 18

To back up your data..................................................................... 18

To create a restore point ............................................................... 23

Backing up and restoring your data with the VAIO software................ 26

To back up your data with Rescue Data........................................26

To restore your data with VAIO Data Restore Tool .......................28

Restoring the preinstalled software or software drivers ....................... 29

To use Reinstall Programs or Drivers............................................ 29

Finding out what to do in case of computer malfunctions ...... 30

If your computer does not work properly..............................................30

If Windows starts ........................................................................... 31

If Windows does not start .............................................................. 32

Recovering your VAIO system.......................................... 33

Before starting the recovery process ................................................... 33

Recovering your VAIO system when you can start Windows .............. 35

To restore the C drive.................................................................... 35

To restore your entire computer system........................................ 36

Recovering your VAIO system when you cannot start Windows ......... 37

Changing the partition sizes ............................................. 38

About hard disk partitioning ................................................................. 38

Creating a hard disk partition ...............................................................38

To create a partition with the Windows feature ............................. 39

To create a partition with recovery discs ....................................... 39

Erasing everything on your hard disk ............................... 40

Erasing all of your data on your hard disk with

Wipe and Erase Data ................................................................... 40

Recovering your VAIO system

Introduction to this guide

This guide covers the following important areas:

❑If you have any problems with your VAIO®computer, solutions are

offered in this booklet in the form of a troubleshooting guide. See

“Troubleshooting” on page 8.

There are more troubleshooting topics on the Sony online support

Web site. Go to http://www.vaio-link.com.

Always read these sections before contacting VAIO-Link or your local

Sony dealer directly.

You can also search for more information by using Windows Help and

Support. Windows Help and Support is a comprehensive resource for

practical advice, tutorials, and demonstrations to help you learn to use

your computer. Use the Search feature, Index, or table of contents to

view all Windows Help resources, including those that are on the

Internet.

To access Windows Help and Support, click Start and Help and

Support. Or go to Windows Help and Support by pressing and holding

the Microsoft Windows key and pressing the F1 key.

❑An important part of using your computer is being able to perform a

recovery of the system and applications. This booklet explains everything

you need to know about recovering your system. It is very important that

you read this section before using your computer, and always before

attempting to make a recovery of any kind. See “Before using your

computer” on page 14.

Troubleshooting

Computer

What should I do if my computer does not start?

❑Make sure your computer is securely plugged into a power source and

turned on. Make sure the power indicator shows the power is on.

❑Make sure the battery pack is installed properly and charged.

❑Make sure the floppy disk drive (if applicable) is empty.

❑If your computer is plugged into a power strip or an uninterruptible power

supply (UPS), make sure the power strip or UPS is plugged into a power

source and turned on.

❑If you are using an external display, make sure it is plugged into a power

source and turned on. Make sure the brightness and contrast controls

are adjusted correctly. See the manual that came with your display for

more information.

❑

Disconnect the AC adapter and remove the battery pack. Wait three to five

minutes. Reinstall the battery pack, reconnect the AC adapter, and then

press the power button to turn on your computer.

❑Condensation may cause your computer to malfunction. If this occurs, do

not use the computer for at least one hour.

❑Remove any extra memory modules you may have installed since

purchase.

❑Check that you are using the supplied Sony AC adapter. For your safety,

use only the genuine Sony rechargeable battery pack and AC adapter,

which are supplied by Sony for your VAIO computer.

Troubleshooting

What should I do if a BIOS error appears when I turn

on my computer?

On all models except VGC-RM series models, if the message “Press <F1>

to resume, <F2> to setup” appears at the bottom of the screen, follow these

steps:

1Press the F2 key.

The BIOS setup screen appears. If not, restart the computer and press

the F2 key several times when the VAIO logo appears.

2Set the date (month/day/year). Press the Enter key.

3Press the m key to select System Time, and then set the time (hour:

minute: second). Press the Enter key.

4Press the , key to select the Exit tab, and then press the F9 key.

At the confirmation prompt, press the Enter key.

5Select Exit Setup, and press the Enter key.

At the confirmation prompt, press the Enter key.

Your computer restarts.

If this occurs frequently, contact VAIO-Link.

On VGC-RM series models, if the message “Press <F1> to resume, <F2> to

setup” appears at the bottom of the screen, follow these steps:

1Press the F2 key.

The BIOS setup screen appears. If not, restart the computer and press

the F2 key several times when the VAIO logo appears.

2Set the date (month/day/year) with the Tab key and +/- keys.

3Press the mkey to select System Time, and then set the time (hour:

minute: second) with the Tab key and +/- keys.

4Press the ,key to select the Exit tab, and then select Load Optimal

Defaults and press the Enter key.

At the confirmation prompt, press the Ykey.

5Select Exit Saving Changes and press the Enter key.

At the confirmation prompt, press the Ykey.

Your computer restarts.

If this occurs frequently, contact VAIO-Link.

What should I do if the power indicator (Green)

lights but my screen stays blank?

Follow these steps:

1Press and hold the power button for more than four seconds to check that

the power indicator goes out. Then turn on your computer again.

2If your computer screen still stays blank, unplug the AC adapter, remove

the battery pack, and leave the computer for about a minute. Then

reinstall the battery pack, plug in the AC adapter, and turn on the

computer again.

What should I do if my computer or software stops

responding?

❑If your computer stops responding while a software application is

running, press the Alt+F4 keys to close the application window.

❑If the Alt+F4 keys do not work, click Start, the arrow next to the Lock

button, and Shut Down to turn off your computer.

❑If your computer does not turn off, press the Ctrl+Alt+Delete keys and

click the arrow next to the Shut down button and Shut Down.

If the Windows Security window appears, click Shut Down.

Turning off your computer with the Ctrl+Alt+Delete keys or the power button may

cause loss of unsaved data.

❑If your computer still does not turn off, press and hold the power button

until the computer turns off.

❑Remove the AC adapter and battery pack.

❑Try reinstalling the software.

❑Contact the software publisher or designated provider for technical

support.

What should I do if the battery indicator is flashing

and my computer does not start?

❑This symptom could be due to the battery pack not being installed

properly. To resolve this symptom, turn off your computer and remove the

battery pack. Then install the battery pack to the computer again. For

details, see the on-screen User Guide.

❑If the symptom persists after performing the above, it means the installed

battery pack is not compatible. Remove the battery pack and contact

VAIO-Link.

Altri manuali per VGN-AR51E

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Sony Computer portatile

Sony

Sony VAIO VPCP113KX/W Manuale utente

Sony

Sony VAIO PCG-F807K Istruzioni per il montaggio

Sony

Sony VAIO VPCEB11FDBI Manuale utente

Sony

Sony VAIO PCG-F540 Manuale utente

Sony

Sony VAIO VPCEE41FX/WI Manuale utente

Sony

Sony VAIO VPCEG37FMP Manuale utente

Sony

Sony VAIO VGN-Z890GNE Manuale utente

Sony

Sony PCG-K47 - VAIO - Mobile Pentium 4 3.2 GHz Manuale utente

Sony

Sony PCG-K27 - VAIO - Mobile Pentium 4 3.06 GHz Manuale utente

Sony

Sony VAIO VGN-FW485J/B Manuale utente

Sony

Sony VAIO VGN-TT190 Manuale utente

Sony

Sony VAIO VPCEE43FX/BJ Manuale utente

Sony

Sony VAIO PCG-NV209 Istruzioni per il montaggio

Sony

Sony VAIO VGN-CR309E/RC Manuale utente

Sony

Sony VAIO VPCCW2 Series Manuale utente

Sony

Sony VAIO VPCP114KX/W Manuale utente

Sony

Sony VGN-A140B Manuale utente

Sony

Sony VAIO VGN-CR510E/Q Manuale utente

Sony

Sony VAIO VGN-AR230G Manuale utente

Sony

Sony VAIO PCG-V505CP Istruzioni per l'installazione

Sony

Sony VGN-SR130E Manuale utente

Sony

Sony VAIO VGN-SZ120P/B Manuale utente

Sony

Sony VAIO Duo 13 SVD132 Manuale utente

Sony

Sony VAIO VPCEH14FMP Manuale utente

Manuali Computer portatile popolari di altre marche

HP ze2401xt - Pavilion Notebook PC Manuale utente

Velocity

Velocity NoteMagix M10 Manuale utente

Dell

Dell Alienware 17 R2 Manuale utente

Toshiba

Toshiba A105-S2236 Manuale utente

HP ENVY 17 Manuale

Winbook

Winbook LM Manuale utente

Dell

Dell Inspiron 1464 Manuale utente

Dell

Dell Inspiron 15R 5537 Manuale utente

HP PROBOOK 4520S Manuale

Dell

Dell Latitude ATG D620 Manuale utente

Dell

Dell Latitude 7310 Manuale utente

Dell

Dell Precision GU806 Manuale utente

Lenovo

Lenovo THINKPAD X32 Manuale utente

HP Compaq tc4200 Guida rapida

Toshiba

Toshiba mini NB300 Manuale utente

Lenovo

Lenovo ThinkPad X201 Tablet Manuale

Lenovo

Lenovo THINKPAD X31 Manuale

Compaq

Compaq Armada E700 Series Manuale utente
