Sony NW-E95 - Network Walkman Istruzioni per il montaggio

1GB

Operating Instructions

MP3 File Manager

Ver 1.1

for Sony Network Walkman

To go to contents you want to read, open the PDF bookmarks and click

the title, or click the title in the “Table of Contents” of the Operating

Instructions.

2-591-026-21(1)

2GB

Table of Contents

What you can do with the MP3 File Manager ......................................................................... 3

Transferring MP3 audio files from the computer to your Network Walkman ......................... 4

Display of MP3 File Manager .................................................................................................. 6

Erasing audio file ..................................................................................................................... 7

Ordering audio file ................................................................................................................... 7

3GB

What you can do

with the MP3 File

Manager

You can transfer MP3 audio files to your

Network Walkman in the same MP3 format.

(The SonicStage software converts MP3

audio files into ATRAC3plus format.)

The MP3 File Manager software is pre-

installed on the Network Walkman at the

factory; thereby no installation is

necessary.

However, be sure to install the

SonicStage software from the

supplied CD-ROM in your

computer before using the MP3

File Manager software. The

computer will not recognize your

Network Walkman unless you

install the SonicStage software (in

the supplied CD-ROM) first. If you

use a computer that is not installed with

the SonicStage software, you need to

install the driver file for your Network

Walkman from the Sony customer

service website (http://www.sony.com/

walkmansupport).

System requirements

•OS:Windows XP Media Center Edition

2004

Windows XP Media Center Edition

Windows XP Professional

Windows XP Home Edition

Windows 2000 Professional

Windows Millennium Edition

Windows 98 Second Edition

(The MP3 File Manager software does not

support the Simplified Chinese OS of

Windows 98 Second Edition and Windows

Millennium Edition.)

•CPU: Pentium II 400MHz or higher

•RAM: 64MB or more

•HDD: 5MB or more

•Display: 16-bit color or higher, 800 ×600

dots or better

•USB port (Supports USB (Previously

called USB1.1))

On language support

The ability to display the languages on your

MP3 File Manager will depend on the

installed OS on your PC. For better results,

please ensure that the installed OS is

compatible with the desired language you

want to display.

–We do not guarantee all the languages will

be able to be displayed properly on your

MP3 File Manager.

–User-created characters and some special

characters may not be displayed.

4GB

Transferring MP3

audio files from

the computer to

your Network

Walkman

1Connect your Network Walkman

to your computer.

Connect the small connector of the

supplied dedicated USB cable into the

USB jack on the Network Walkman,

then the large connector to a USB port

on your computer.

“CONNECT” appears in the display.

The above illustration is a sample.

Refer to the Operating Instructions for

your Network Walkman about the

connection.

2Click [My Computer]-[removable

disk:]*on your computer.

*[Network Walkman] in the case of

Windows XP Media Center Edition

2004/Windows XP Media Center

Edition/Windows XP Professional/

Windows XP Home Edition

3Click [Esys] folder to open in the

removable disk.

4Double-click

[MP3FileManager.exe] to start it.

5Drag the MP3 audio files you want

to transfer to your Network

Walkman and drop them to the

MP3 File Manager screen.

You can also transfer MP3 format

audio files to your Network

Walkman by dragging a folder.

Dedicated USB cable

(supplied)

to a USB port

to the USB jack

ACCESS

lamp

5GB

Notes

•After transferring, be sure to close the case cover

to prevent liquid from entering.

•Do not disconnect the USB cable or remove your

Network Walkman when the MP3 File Manager

software is running. If you do, operation is not

guaranteed.

•The ACCESS lamp blinks while your Network

Walkman accesses the computer.

•Do not disconnect the USB cable or remove your

Network Walkman when the ACCESS lamp is

blinking. The data being transferred may be

destroyed.

•Install Service Pack 3 or later when you use

Windows 2000.

• With the Network Walkman, priority is given to

the display of ID3 Tag information. (ID3 Tag is

the format that adds music title or artist name

information, etc., to an MP3 file. The Network

Walkman supports version 1.0/1.1/2.2/2.3/2.4.)

• Use of your Network Walkman with a USB hub

or a USB extension cable is not guaranteed.

Always connect your Network Walkman to the

computer directly using the dedicated USB cable.

•Some USB devices connected to the computer

may interfere with the proper operation of your

Network Walkman.

•The control buttons on your Network Walkman

are all disabled while it is connected to a

computer.

•You can display the data stored in the built-in

flash memory using Windows Explorer when

your Network Walkman is connected to the

computer.

• MP3 audio files compliant with the MP3 File

Manager software are the one sampling frequency

rate of 44.1 kHz, bit rate 8 – 320 kbps.

If the MP3 File Manager software

is accidentally erased by

formatting, etc.

You can restore it by downloading the MP3

File Manager software from the Sony

customer service website

(http://www.sony.com/walkmansupport).

6GB

Display of MP3 File Manager

1Album list

Double-click this to show the included

track list. Double click again to hide the

track list.

2Track list

3button

Click this button to erase selected

albums or tracks.

4button

Click this button to erase all the albums

or tracks.

5button

Clicks this button to finish the MP3 File

Manager.

6Blue line

The selected line turns blue.

You can select several albums or tracks

simultaneously using the CTRL key or

Shift key.

Note

Audio files transferred to the built-in flash memory

using SonicStage software are not displayed on the

MP3 File Manager screen. In addition, audio files

transferred to the built-in flash memory using MP3

File Manager software are not displayed on the

SonicStage software screen.

7GB

Erasing audio file

You can erase a song stored in the built-in

flash memory by track or album using MP3

File Manager.

1Open the MP3 File Manager.

2Select the title you want to erase.

3Click the button in the

screen.

z Tip

You can select several albums or tracks

simultaneously using CTRL key or Shift key.

However, albums and tracks cannot be selected

simultaneously.

Ordering audio file

You can move a song stored in the built-in

flash memory by track or album using MP3

File Manager.

1Open the MP3 File Manager.

2Select the title you want to move.

3Move it by drag and drop.
