SONY 3CCD Color Video Camera

Internal Use Only

Sales Manual

DXC-990/990P

DXC-390/390P

New cover.qxp 01.3.2 4:00 PM Page 1

DXC_990/390.qxp 01.3.2 3:45 PM Page 2

CONTENTS

1. PRODUCT CONCEPT P. 2

2. APPLICATIONS P. 3

3. KEY FEATURES P. 4

4. MENU FUNCTION P. 14

5. CAMERA CONNECTORS P. 19

6. CONNECTOR PIN ASSIGNMENTS P. 21

7. SPECIFICATIONS P. 23

8. OPTIONAL ACCESSORIES P. 25

9. SYSTEM EXAMPLES P. 30

10. DIMENSIONS P. 33

11. COMPARISON CHART P. 36

12. TECHNICAL APPENDIX P. 38

13. Q & A P. 42

DXC-390/390P

DXC-990/990P

DXC_990/390.qxp 01.3.2 3:46 PM Page 1

1. Product Concept

1. PRODUCT CONCEPT

High performance/Low cost

Multipurpose Video Camera

DXC-990/990P

●Bayonet mount 3CCD

●High picture quality

●1/2 type Exwave HAD®CCD

●Digital Signal Processor

DXC-390/390P

●C mount 3CCD

●Compact Body

●1/3 type Exwave HAD CCD

●Digital Signal Processor

–

DXC-990/990P, DXC-390/390P Sales Manual

DXC_990/390.qxp 01.3.2 3:46 PM Page 2

2. Applications

DXC-990/990P, DXC-390/390P Sales Manual

–

2. APPLICATIONS

Biotechnology

Industrial Research

Industrial Inspection

Printing

Semiconductor

Remote Camera

Distance Learning

Surveillance

Video Production

Microscopy

DXC_990/390.qxp 01.3.2 3:46 PM Page 3

3. Key Features

–

DXC-990/990P, DXC-390/390P Sales Manual

3. KEY FEATURES

■DynaLatitudeTM Function

• The DynaLatitude function processing enables you to adjust the contrast of each pixel according to

the luminance signal level of each picture element.

• The DynaLatitude function minimizes video level distortion based on video signal histograms in

order to utilize the limited dynamic range of the standard video signal.

• If there is a dark section and bright section in one image (i.e. shade and sunshine), then both parts

will often look vague. The DynaLatitude function allows you to adjust the sharpness of both

sections.

• Even when lighting is favorable, more luminance levels will be allocated to the subject, creating a

clearer, more detailed image.

DXC-990/990P DXC-390/390P

Horizontal Resolution 850 TV Lines 800 TV Lines

Signal to Noise Ratio 63 (NTSC) 62 (PAL) dB 62 (NTSC) 61 (PAL) dB

Sensitivity F11@2000 lx (3200 K) F8@2000 lx (3200 K)

Minimum Illumination 1 lx (F1.4, GAIN:HYPER) 4 lx (F2, GAIN:HYPER)

Output Signal VBS, RGB/SYNC, Y/C, Y/R-Y/B-Y RGB, Y/C, VBS

Dimensions 70 (W) x 72 (H) x 123.5 (D) mm 56 (W) x 50 (H) x 128 (D) mm

Power Consumption Approx. 8.0 W Approx. 7.6 W

Mass 630 g Approx. 370 g

BASIC SPECIFICATIONS

FEATURES

DXC_990/390.qxp 01.3.2 3:46 PM Page 4

3. Key Features

DXC-990/990P, DXC-390/390P Sales Manual

–

Pixel

Number

Luminance Level

Pixel

Number

Luminance Level

Pixel

Number

Luminance Level

Pixel

Number

Luminance Level

The diagrams above are based on estimations, not on actual operation.

■DCC+ Process

•The DCC+ (Dynamic Contrast Control Plus) manages video signal data at three levels - brightness,

hue and saturation. The result is an image with suitable knee correction and without hue distortion.

Clip Level

Knee Point

Luminance

Level BGR W BGR BGR W BGR W

Gray Color Skin Color Skin Color

without Knee Skin Color with

conventional

Knee

BGR W

Skin Color

with DCC+

■DynaLatitude Function

DXC_990/390.qxp 01.3.2 3:46 PM Page 5

3. Key Features

–

DXC-990/990P, DXC-390/390P Sales Manual

■Knee and Black Stretch

•By adjusting the knee, a knee point and knee slope are set so that the highlighted areas of the picture

can be clearly reproduced.

•Contrast in the dark area of the image can be variably adjusted using the Black Stretch function for

a clear view of specific details.

■Pedestal

•Black or dark parts of the picture can be clearly seen by adjusting the black level. Also the R and B

pedestal level can be finely adjusted for each color.

100%

90%

70%

High

Low

Normal

Luminance Level

Amount of light input to camera

20%

Black stretch

Knee

Compress

Stretch

DXC_990/390.qxp 01.3.2 3:46 PM Page 6

3. Key Features

DXC-990/990P, DXC-390/390P Sales Manual

–

■Electronic Shutter Function

•The variable electronic shutter built into the CCD imager enables the DXC-990/990Pand DXC-390/390P

to capture clear images of moving objects. The shutter speed can be manually selected from

a wide range of speeds (up to 1/100000).

•The Flickerless mode allows you to obtain flickerless images even in fluorescent lighting conditions.

•The ClearscanTM mode reduces the horizontal bands that appear in computer displays when shooting

the display with a conventional video camera.

■Long Term Exposure Function

•When shooting very dark objects or objects in dark lighting conditions, you can manually set the

shutter speed to 1/60 of a second or more to allow more light to accumulate on the CCD sensors,

resulting in enhanced sensitivity.

•By synchronizing the WEN pulse of the camera signal output with an external memory unit such as

a frame grabber unit/board, it is possible to obtain a still picture video.

Example: When the value is set to 250 H

(NTSC) 250 63.56 us (1H) + 34.78 us (constant)

= 15924.78 us

= 1/62.8 s

(PAL) 250 64 us (1H) + 35.6 us (constant)

= 16035.6 us

= 1/62.4 s

Example: When the value is set to 5 FRM

(NTSC) 5 1/30 = 0.167 s

(PAL) 5 1/25 = 0.2 s

DXC_990/390.qxp 01.3.2 3:46 PM Page 7

3. Key Features

–

DXC-990/990P, DXC-390/390P Sales Manual

■Digital Detail

•The detail function adjusts the sharpness of object outlines with minimal noise using digital signal

processor technology

•The unique feature of the function is that the horizontal detail frequency can be changed.

■Linear Matrix

•The Linear Matrix function provides sophisticated electronic adjustment for accurate color reproduction

by adjusting color saturation and hue.

•Besides four preset settings, the R,G,B levels can be independently adjusted.

■Partial Enhance Function

•This function allows a particular color to be selected, and its hue, saturation and detail altered.

•In addition, the detail produced by the high resolution of the camera can be softened or emphasized

in certain parts of the image by Partial Enhance function.

•The designated active area can be set by simply adjusting the area detect cursor.

<Original Waveform> <Enhance signal> <Waveform after

Enhancement>
