Sony HT-S2000 Guida di riferimento

User Manual of Product 1:

Sony HT-S2000: 3.1ch Dolby Atmos/DTS:X Soundbar

Surround Sound Home Theater with Bluetooth Technology

User Manual of Product 2:

Sony SA-SW3 200W Wireless Subwoofer for

HT-A9/A7000/A5000/A3000/S2000 and STR-AN1000,Black

Help Guide

Sound Bar

HT-S2000

Model: YY2079C

Install the app to use the speaker system

To use the speaker system with all the available functions and improved performances, update the software of the

speaker system and the “Sony | Home Entertainment Connect” app to the latest versions.

How to Use/Parts and Controls

About the App Required to Use the Speaker System

Devices that Can Be Connected to the Speaker System

Parts and Controls

Bar Speaker

Supplied Remote Control

Remote Control Screen of the App

Initial Setup

Installing the Speaker System

Installing the Bar Speaker

Mounting the Bar Speaker on a Wall

Connecting to a TV

Connecting to the AC Outlet (mains)

Performing Initial Settings with the “Sony | Home Entertainment Connect” App

Listening to Music/Sound

Listening to TV Sound

Adjusting Sound Quality

Listening to Sony TV Sound with the BLUETOOTH® Function

What You Can Do by Connecting a TV with the BLUETOOTH Function

Listening to TV Sound by Connecting the Speaker System and TV Wirelessly

Listening to Sound of the Paired TV

Listening to Music/Sound with the BLUETOOTH Function

Listening to Music by Pairing the Mobile Device that is Connected for the First Time

Listening to Music from the Paired Device

Listening to Music on a USB Device (models with the (USB) port only)

Setting the Wireless Function to On or Off

Using the Speaker System by Interlocking with a TV

Operating the Speaker System by Interlocking with a TV (Control for HDMI Function)

Operating the Speaker System by Interlocking with a TV Compatible with the “BRAVIA” Sync Function

Changing the Settings with the App

[Wireless Speaker Connection Settings]

[Sound Settings]

[HDMI Settings]

[Bluetooth Settings]

[System Settings]

[Easy Initial Setup]

Troubleshooting

Resetting the Speaker System

Additional Information

Specifications

Playable Types of Audio Files for the USB Device (models with the (USB) port only)

Supported Audio Formats

Trademarks

Licenses

Notes on Use

Customer Support Website

Help Guide

Sound Bar

HT-S2000

About the App Required to Use the Speaker System

Use a smartphone with the “Sony | Home Entertainment Connect” app installed to operate and configure the settings on

the speaker system.

Install the “Sony | Home Entertainment Connect” app on your smartphone.

The app allows you to perform the following operations and settings.

Initial settings of the speaker system

Operations such as volume adjustment, input selecting, etc.

Changing the settings of the speaker system to the desired settings

Connecting the optional rear speakers and/or subwoofer and performing initial settings

Updating the software of the speaker system to the latest version

Checking the support information and latest update information

The supplied remote control can only be used to perform operations and settings that are frequently used when viewing

content.

Related Topic

Supplied Remote Control

Remote Control Screen of the App

Help Guide

Sound Bar

HT-S2000

Devices that Can Be Connected to the Speaker System

The speaker system supports object-based audio formats such as Dolby Atmos and DTS:X.

Blu-ray Disc™ player, set-top box, cable box, satellite box, gaming console, etc.

Rear speakers

Subwoofer

You can listen to sound of a TV with the speaker system by connecting the speaker system and TV with an HDMI cable

or BLUETOOTH function.

Listening to TV Sound

What You Can Do by Connecting a TV with the BLUETOOTH Function

USB device (models with the (USB) port only)

You can play music files stored on a USB device with the speaker system by connecting the USB device to the (USB)

port of the speaker system.

Listening to Music on a USB Device (models with the (USB) port only)

Mobile device

Use the “Sony | Home Entertainment Connect” app to perform operations and settings of the speaker system.

You can listen to sound of a mobile device with the speaker system by connecting the speaker system and mobile device

with the BLUETOOTH function.

Listening to Music by Pairing the Mobile Device that is Connected for the First Time

Optional speakers

You can operate the optional rear speakers/subwoofer with the app.

For the supported optional speakers, confirm on the Sony website.

Help Guide

Sound Bar

HT-S2000

Bar Speaker

Front

Rear

(Power)

Turns the speaker system on. When tapping while the speaker system is turned on, it is set to standby mode.

(Input)

Selects the input for playback on the speaker system.

(BLUETOOTH)3.

+/– (Volume)4.

BLUETOOTH indicator

Flashes twice repeatedly in blue: During BLUETOOTH pairing standby status.

Flashes in blue: BLUETOOTH connection is being attempted.

Lights in blue: BLUETOOTH connection has been established.

Front panel display6.

Remote control sensor

Point the remote control at the remote control sensor of the bar speaker to operate the speaker system.

Related Topic

Connecting to a TV

Connecting to the AC Outlet (mains)

(USB) port

FOR SERVICE port

The port type differs depending on countries/regions.

IR repeater

Transmits the remote signal of the TV remote control to the TV.

DC IN terminal3.

TV IN (OPTICAL) jack4.

HDMI OUT (TV (eARC/ARC)) jack

Connect a TV that has an HDMI input jack with an HDMI cable. The speaker system is compatible with eARC and

ARC. ARC is the function that sends TV sound to an AV device such as the speaker system from the TV’s HDMI jack

through an HDMI cable. eARC is an extension of ARC and enables transmission of the object audio and multi-

channel LPCM content that cannot be transmitted with ARC.

Help Guide

Sound Bar

HT-S2000

Supplied Remote Control

About the replacement of batteries for the remote control

INPUT (Input)

Selects the input for playback on the speaker system.

Each time you press the button, the input source switches as follows.

[TV] - [BT] - [USB] (models with the (USB) port only) - [TV] ...

(Power)

Switches between power on and standby on the speaker system.

SOUND FIELD (Sound field)

Turns the surround sound effect on the speaker system on and off.

VOICE (Voice mode)

Turns the voice mode function of the speaker system on and off.

(Volume) +(*)/–

Adjusts the volume of the speaker system.

NIGHT (Night mode)

Turns the night mode function of the speaker system on and off.

(Muting)

Turns off the sound of the speaker system temporarily.

BASS (Bass level) +/–

Adjusts the volume of the built-in subwoofer in the speaker system or the optional subwoofer when connecting it.

(Volume) + has a tactile dot. Use it as a guide during operation.
