Sony PMC-107L Manuale utente

3-862-981-13 (1)

1998 by Sony Corporation

Personal

Component

System

Operating Instructions page 2EN

Manual de instrucciones página 2ES ES

PMC-20L

PMC-107L

Introduction2EN

Warning

To prevent fire or shock hazard, do

not expose the player to rain or

moisture.

To avoid electrical shock, do not open

the cabinet. Refer servicing to

qualified personnel only.

Information

This Compact Disc player is classified as

a CLASS 1 LASER product.

The CLASS 1 LASER PRODUCT label is

located on the bottom exterior.

Warning

Do not install the appliance in a confined

space, such as a bookcase or built-in cabinet.

Notice for customers in the United

Kingdom

A moulded plug complying with BS 1363 is

fitted to this equipment for your safety and

convenience.

Should the fuse in the plug supplied need to

be replaced, same rating fuse approved by

ASTA or BSI to BS 1362, (i.e. marked with

or mark) must be used.

If the plug supplied with this equipment has

a detachable fuse cover, be sure to attach the

fuse cover after you change the fuse. Never

use the plug without the fuse cover. If you

should lose the fuse cover, please contact

your nearest Sony service station.

Note

The name of the switch to turn on/off this

player is indicated as below:

PMC-20L:

“OPERATE”: All countries

PMC-107L:

“OPERATE”: European countries

(excluding central and

eastern Europe)

“POWER”: Other countries

CAUTION

You can use this player on AC power

source only. You cannot use it on

batteries.

When you use this player for the first time,

or when you have not used it for a long

time, leave it connected to AC power

source for about one hour to charge the

built-in backup battery for the clock, timer,

preset radio stations, etc. You can use the

player during charging. The player will

charge the battery automatically as long as

it is connected to a power source.

When you disconnect the AC power cord

after charging, be sure to turn the power

off first. Once fully charged, the backup

battery will last for about 30 minutes

without being connected to any power

sources.

If the stored data are erased, reenter them

when you use the player again.

Introduction

Basic Operations

3EN

Table of contents

Basic Operations

4Playing a CD

6Listening to the radio

8Playing a tape

10 Recording on a tape

The CD Player

12 Using the display

13 Locating a specific track

14 Playing tracks repeatedly

(Repeat Play)

15 Creating your own program

(Program Play)

The Radio

17 Presetting radio stations

18 Playing preset radio stations

The Timer

19 Setting the clock

20 Waking up to music

22 Falling asleep to music

Setting Up

23 Hooking up the system

25 Selecting the audio emphasis

(Sound Mode/MEGA BASS)

Additional Information

26 Precautions

28 Troubleshooting

30 Maintenance

31 Specifications

32 Index

Basic Operations4EN

Playing a CD

Basic Operations

For hookup instructions, see pages 23 - 24.

1Press 6PUSH OPEN/CLOSE

down to open the CD

compartment and place the CD

on the CD compartment.

2Close the lid of the CD

compartment.

3Press ^(direct power-on).

The player plays all the tracks

once.

Display

With the label side up

1,23

Playing time

Track number

PUSH

OPEN/CLOSE

PUSH

OPEN/CLOSE

Basic Operations

5EN

Use these buttons for additional operations

6PUSH OPEN/CLOSE

VOLUME +, –

To Press

adjust the volume VOLUME +, – (VOL +, –

on the remote)

stop playback p

pause playback ^(Pon the remote)

Press the button again to

resume play after pause.

go to the next track +

go back to the previous track =

remove the CD 6PUSH OPEN/CLOSE

turn on/off the player OPERATE (or POWER, see

page 2)

Tip

Next time you want to

listen to a CD, just press

^. The player turns on

automatically and starts

playing the CD.

OPERATE

(or POWER)

Basic Operations6EN

Listening to the radio

For hookup instructions, see pages 23 - 24.

1Press BAND until the band you

want appears in the display

(direct power-on).

2Hold down TUNING/TIME SET

+ or – until the frequency digits

begin to change in the display.

The player automatically scans

the radio frequencies and stops

when it finds a clear station.

If you can't tune in a station,

press the button repeatedly to

change the frequency step by

step.

Display

Indicates an FM stereo

broadcast.

12 2

BAND

PRESET PRESET

TUNING/TIME SET

Basic Operations

7EN

Use these buttons for additional operations

VOLUME + , –

PLAY MODE

MONO/ST ISS

To Press

adjust the volume VOLUME +, – (VOL +, – on

the remote)

turn on/off the radio OPERATE (or POWER, see

page 2)

To improve broadcast reception

Keep the FM wire aerial as horizontal as possible (see

page 24).

MW/LW

Keep the MW/LW loop aerial (supplied) away as far

as possible from the player and then reorient the

aerial (see page 24).

Tips

• If the FM broadcast is

noisy, press PLAY

MODE•MONO/ST ISS

until “Mono” appears in

the display and the

radio will play in

monaural.

• Next time you want to

listen to the radio, just

press BAND. The player

turns on automatically

and starts playing the

previous station.

OPERATE

(or POWER)

Basic Operations8EN

Playing a tape

For hookup instructions, see pages 23 - 24.

1Press p6 to open the tape

compartment and insert a

recorded tape. Use TYPE I

(normal) tape only. Close the

compartment.

2Press (.

The player turns on (direct

power-on) and starts playing.

With the side you want

to play facing you

Display

Basic Operations

9EN

Use these buttons for additional operations

To Press

adjust the volume VOLUME +

– (VOL +, –

on the remote)

stop playback p6

fast-forward or rewind the tape )

pause playback P

Press the button again to

resume play after pause.

eject the cassette p6

turn on/off the player OPERATE (or POWER,

see page 2)

Tip

Next time you want to

listen to a tape, just

press (. The player

turns on automatically

and starts playing the

tape.

)

VOLUME +, –

OPERATE

(or POWER)

Basic Operations10EN

Recording on a tape

For hookup instructions, see pages 23 - 24.

1Press p6 to open the tape

compartment and insert a blank

tape. Use TYPE I (normal) tape

only.

2Select the program source you

want to record.

To record from the CD player,

insert a CD (see page 4) and press

pon the CD section.

To record from the radio, press

BAND and tune in the station

you want (see page 6).

With the side you want to

record on facing you

Display

BAND

PRESET PRESET
