SA-VS110

Key Features

5.1ch speaker package

Dynamic sound with SLIM design

2 way 3 drivers speaker system

Sound Reproduction up to 70kHz 20mm tweeter

Deep base with 25cm active subwoofer

SONY Design matching wall mountable

Sony Electronics Inc.

•

16530 Via Esprillo

•

San Diego, CA 92127

•

1.800.222.7669

•

www.sony.com

Last Updated: 10/07/2010

SA-VS110

Please visit the Dealer Source for current

information at www.sony.com/dealersource

Features

Center Speaker

General

CabinetMaterial: Plastic

EnclosureType: Bass Reflex

FrontGrille: Fixed Cloth

SpeakerType: 2 way 3 drivers speaker

system

Front Speaker

General

CabinetMaterial: Plastic

EnclosureType: Bass Reflex

FrontGrille: Fixed Cloth

SpeakerType: 2 way 3 drivers speaker

system (SS

FV310)

Surround Speaker

General

CabinetMaterial: Plastic

EnclosureType: Bass Reflex

FrontGrille: Fixed Cloth

SpeakerType: 2 way 3 drivers speaker

system

Subwoofer

General

CabinetMaterial: Particle Board

EnclosureType: Bass Reflex

Finishtype:

PP Sheet

FrontGrille: Fixed Cloth

SpeakerType: Active Subwoofer

Convenience

LevelControl: Yes

PhaseSwitch: Yes

Power Save Mode: Yes

Specifications

Audio

FrequencyRange: 28Hz

70kHz

Center Speaker

Audio Specs

Maximum Input Power: 100W

Output Sound Pressure Level: 81dB (1W,

1m)

RatedImpedance: 8 Ohms

Inputs and Outputs

InputType: Push type

Weight and Measurements

Dimensions(Approx.): 12 5/8" x 2 3/8" x

2" (320 mm x 60 mm x 50 mm)

Tweeter Unit Size: 20mm, cone type

Weight(Approx.): ( lb 2 oz (0.5 kg)

Woofer Unit Size: 40mm x 70mm, cone type

(x2)

Front Speaker

Audio Specs

Characteristic Sensitivity Level: 81dB (1W,

1m)

Maximum Input Power: 100W

RatedImpedance: 8 Ohms

Weight and Measurements

Dimensions(Approx.): Without stands: 2" x

15 3/8" x 2" (50 mm x390 mm x50 mm),

with desktop stands: 5 3/8" x 16 1/4" x 5

3/8" (135 mm x 410 mm x 135 mm)

Tweeter Unit Size: 20mm cone type

Weight(Approx.): Without stands: 1 lb 4 oz

(0.56 kg), with desktop stands: 1 lb 15 oz

(0.88 kg)

Woofer Unit Size: 40mm x 70mm, cone type

(x2)

Surround Speaker

Audio Specs

RatedImpedance: 8 Ohms

Inputs and Outputs

InputType: Push Type

Weight and Measurements

Dimensions(Approx.): Without stands: 2" x

15 3/8" x 2" (50 mm x390 mm x50 mm),

with desktop stands: 5 3/8" x 16 1/4" x 5

3/8" (135 mm x 410 mm x 135 mm)

Tweeter Unit Size: 20mm cone type

Weight(Approx.): Without stands: 1 lb 4 oz

(0.56 kg), with desktop stands: 1 lb 15 oz

(0.88 kg)

Woofer Unit Size: 40mm x 70mm, cone type

(x2)

Subwoofer

Inputs and Outputs

InputType: RCA Pin

Power

Power Requirements (frequency): 60Hz

Power Requirements (voltage): 120V

Weight and Measurements

Dimensions(Approx.): 11 1/2" x 14" x 15

3/4" (290 mm x 355 mm x 400 mm)

PowerOutput: 100W (6 ohms, 100 Hz, 10%

THD)

Speaker Unit Size: 250mm, cone type

Weight(Approx.): 25 lb 6 oz (11.5 kg)

Supplied Accessories

Desktop stand for 4 Speakers

Speaker Cord 8.2' x 3, 26.2' x 2 (2.5m x3,

8m x2)

RCA Pin Cord 6.5' (2m)

Foot (for Subwoofer) x4"

Color:

Black

UPC Code:

027242798533
