Sony SS-CCP500 Manuale utente

SS-CCP500/CVP100

US Model

Canadian Model

AEP Model

UK Model

Australian Model

Chinese Model

SS-CCP500

E Model

SS-CCP500/CVP100

SERVICE MANUAL

SPEAKER SYSTEM

Sony Corporation

Home Audio Company

ShinagawaTec Service Manual Production Group

9-929-597-12

2001F1600-1

© 2001.6

• SS-CCP500 is the speaker system in

CMT-CP100/CP100K/CP500MD/CP500MDK.

• SS-CVP100 is the speaker system in CMT-VP100.

SPECIFICATIONS

Ver 1.1 2001. 06

Speaker system Two-way, bass reflex

system

Speaker units 12 cm dia., cone type

woofer

2.5 cm dia., semi-dome-

type tweeter

Rated impedance 6 ohms

Dimensions (w/h/d) Approx. 150 ×252 ×

255 mm

Mass Approx. 2.6 kg net per

speaker

Design and specifications are subject to change

without notice.

Photo : SS-CCP500

2

SS-CCP500/CVP100

EXPLODED VIEW AND PARTS LIST

NOTE:

• Items marked “*” are not stocked since they

are seldom required for routine service. Some

delayshould be anticipatedwhen ordering these

items.

• Themechanical partswith no referencenumber

in the exploded views are not supplied.

Ref. No. Part No. Description Remarks

1 X-4953-471-1 NET ASSY, SPEAKER

2 A-4412-854-A BOX ASSY, SPEAKER (CCP500)

2 A-4735-099-A BOX ASSY, SPEAKER (CVP100)

1

2

Ver 1.1 2001. 06

3

SS-CCP500/CVP100

MEMO

SS-CCP500/CVP100

REVISION HISTORY

Clicking the version allows you to jump to the revised page.

Also, clicking the version at the upper right on the revised page allows you to jump to the next revised

page.

Ver. Date Description of Revision

1.1 2001.06 Chinese model addition.

Correction of Exploded view snd parts list. (SPM-01015)

1.0 2001.02 New
