Sony WEGA KD 32FS130 Manuale utente

KD-32FS130

32" FD Trinitron®WEGA®Television

Key Features

FD Trinitron® Picture Tube

ATSC/Clear QAM Tuner

Digital Comb Filter

16:9 Enhanced Mode (V-Compression)

Component Video Input (Y/Pb/Pr -480i)

Clear Edge VM

™(Wideband Velocity Modulation)

Audio Power (10W x 2)

Dolby® Digital Audio Decode

SRS

® Audio Effect

Steady Sound® Automatic Volume Control With BBE®

Technology

Key Technologies

FD Trinitron®WEGA®Flat Screen FD Trinitron

WEGA

Flat Screen Technology is the basis of Sony's

award-winning line of visually flat televisions. The FD Trinitron sets deliver incredible image accuracy, wide

viewing angles, outstanding contrast, and corner-to-corner detail. The visually flat FD Trintron

tube

minimizes annoying glare from light sources, which enhances contrast. Detail, corner-to-corner, is rendered

more accurately because images aren't distorted by a curved screen. Squares are square, straight lines

appear straight, and circles are circular.

ATSC Integrated Tuner allows the reception of local, off-air digital broadcasts providing the viewing of

FREE, true standard definition digital network programming without the addition of a set top box or a monthly

fee.

SRS

®Audio Effect SRS technology retrieves the spatial information that is lost during ordinary audio

compression from any stereo recording and restores the original three-dimensional sound field. As a result,

the reproduced sound is much closer to what the artist originally intended and to that of a live performance. A

natural 3D sound image is created from any two-speaker stereo system. And because it is based on

characteristics of the human hearing system SRS delivers natural, non-fatiguing sound without a discernable

sweet spot limitation, allowing for superb sound from any listening position.

KD-32FS130

32" FD Trinitron®WEGA®Television

Sony Electronics Inc. • 16530 Via Esprillo Drive • San Diego, CA 92127 • 1-800-222-7669 • www.sony.com

Last Updated: 10/12/2005

32FS2

Please visit the Dealer Network for current

information at www.sony.com/dn

Features

General

Auto SAP:

Yes

Channel Fix: Yes

Closed Caption (CC): Yes

Magnetic Quadra Pole: Yes

Video Label: Yes

XDS (Extended Data Service): Yes

Video

Screen or Display Technology:

Trinitron

Technology

Tuner: 8 VBS, ATSC, NTSC, Clear QAM

Video Signal System: ATSC, NTSC

Auto White Balance: Yes

Color Temperature: Cool/Neutral/Warm

Dynamic Picture™ Processor Circuitry: Yes

Trinitone

Color Temperature: Yes

16:9 Enhanced Mode: Yes

Screen Modes (4:3):

Full, Zoom, Horizontal

Expand, Verticial Expand

ClearEdge VM™ Technology:

High, Medium,

Low, Off

Comb Filter:

Digital

Dynamic Focus™ Circuitry: Yes

Vertical Aperture Compensation: Yes

Tilt Correction:

+5 to

Picture Modes: Vivid/Standard/Movie/Pro

Audio

Tone Control(s): Treble and Bass

MTS Stereo Decoder:

Stereo, Auto SAP, Off

Audio Mute: Yes

Speaker On/Off: Yes

Simulated Surround: Yes

SRS

Audio: Yes

Dolby

Digital: Yes

Convenience

Channel Label: Yes

Channel Skip/Add: Yes

Channel Jump: Yes

Favorite Channel: Yes

Speed Surf™ Channel Selection: Yes

Program Guide Access: Yes

Auto Channel Programming: Yes

Menu Color: Yes

Multiple Language Display:

English, Espa

ol,

Fran

ais

Parental Control (V

Chip): Yes

Info Banner: Yes

Programmable Timer:

2 Event

Sleep Timer:

15, 30, 45, 60, 90, Off

Timer Events:

Timer 1, Timer 2

Caption Vision: On/Off/Program

Clock: Yes

Specifications

General

Aspect Ratio:

4:3

Screen Size:

32"

Video

Native Resolution:

480i

Audio

Speaker Type: NA

Speakers (Total):

Tweeter Size: NA

Audio Power Output:

20W Total (10W x 2)

Inputs and Outputs

Analog Audio Input(s):

3 (1 Front/2 Rear) with

Detection

Audio Out (Variable/Fixed): 1 (Rear)

Component Video (Y/Pb/Pr ) Input(s): 2 (Rear)

Composite Video Input(s):

5 (1 Front, 4 Rear)

RF Connection Input(s): 1 (Rear)

Video Input(s): 1 (Rear)

Power

Internal Power Supply: Yes

Power Consumption (in Operation):

185W

Power Consumption (in Standby):

Power Requirements:

AC120V, 60Hz

Regulation and Standard

Compliance

Energy Star

Compliant: Yes

Service and Warranty Information

Limited Warranty: 90 Days Labor / 1 Year

Parts / 2 Years Picture Tube

Dimensions

Weight:

163.2 lbs. (74 kg)

Measurements:

35 3/8" x 27 3/8" x 22 5/8" (898

x 696 x 576 mm)

Supplied Accessories

Remote Control (RM

YD001)

Instruction Manual

AA Battery x 2

Optional Accessories

Television Stand (SU

32FS2)

UPC Code:

0272426714610

Confidential Sony Information. For Internal Use Only.

Features and specifications are subject to change without notice. Non-

metric weights and measures are approximate.

Sony, Clear Edge VM, Dynamic Focus, FD Trinitron WEGA, Program Palette,

Speed Surf, Steady Sound and WEGA are trademarks of Sony. BBE is

trademark of BBE Sound, Inc. SRS and the SRS symbol are trademarks of SRS

Labs, Inc. Dolby Digital is a trademark of Dolby Laboratories Licensing

Corporation. All other trademarks are property of their respective owners.
