Sony SVT-124 Manuale utente

24 HOUR TIME LAPSE VCR

SVT-124

■2, 12, 24 hour recording/playback modes (T-120)

■4-heads for clear still playback

■Built-in time/date generator

■Adaptive Picture Control (APC)

■Audio recording in 2, 12, or 24 hour modes

■Auto repeat and Timer recording capabilities

■Alarm recording from Stop or Power Off modes

■Record check, Alarm log, Alarm scan capabilities

■Compact size – only 9-1/2" wide

■30-day battery backup for power failure protection

■Host of reliable safety functions – security lock,

clog detection, warning out

■Tape before end signal output

24 HOUR

TIME LAPSE

VCR

™

SONY

SECURITY

SYSTEMS

SONY

SECURITY

SYSTEMS

8888-SVT-124 Security SS.E 7/1/99 4:51 PM Page 1

SPECIFICATIONS

SVT-124

Video Recording System: Dual Azimuth,

4-heads helical scanning system

Television System: EIA standard, NTSC color

Video Recording Modes: 2, 12, 24 hours (T-120)

Video Input/Output: BNC x 2, 1Vp-p, 75 Ohm unbalanced,

sync negative

Horizontal Resolution:

B&W: 350 lines

Color: 300 lines

Video S/N: 44 dB

Audio Recording: 2, 12, 24 hour modes

Audio Input: Phono x 1, -7.8 dBs, 47 kOhm

Audio Output: Phono x 1, -7.8 dBs, 600 Ohm

Microphone Input: Mini jack x 1, -60 dBs, 600 Ohm

Internal Timer: 1 week, 8 event

Operating Temperature: 41°F to 104°F (+5°C to +40°C)

Power Requirements: AC 120V, 60 Hz

Power Consumption: 18W

Dimensions (WHD): 9-1/2 x 3-7/8 x 13-1/8 inches

(240 x 96.5 x 333 mm)

Weight: 8 lb. 6 oz. (3.8 kg)

Connectors:

Alarm Input: Contact closure

Alarm Output: +5V, 5.7 kOhm

Switch Output: +5V, 5.7 kOhm, field/frame selectable

Tape End Output: +5V, 5.7 kOhm

Warning Output: +5V, 5.7 kOhm

External Timer Input: Contact closure

Remote: Stereo Mini jack (3.5 mm) x 1

Mic In: Mini jack (3.5 mm) x 1

Supplied Accessories:

Operation manual (1)

AC power cord (1)

Optional Accessories:

SVT-RM10: Wired remote control unit; cord length 7 ft. 10 in.

T-120: 120-minute VHS tape

Reproduction in whole or in part without written permission is prohibited.

All specifications are subject to change without notice.

Sony and Nothing Escapes Us are Trademarks of Sony.

SVT-124

Sony Security Systems

Business and Professional Group

3 Paragon Drive

Montvale, New Jersey 07645

TEL: (201) 358-4954 • FAX: (201) 358-4927

Printed in U.S.A. 07/97 S-SVT-124

24 HOUR

TIME LAPSE

VCR

™

SONY

SECURITY

SYSTEMS

SONY

SECURITY

SYSTEMS

REAR PANEL DETAIL

REAR PANEL VIEW

SVT-RM10 REMOTE CONTROL UNIT

8888-SVT-124 Security SS.E 7/1/99 4:51 PM Page 2
