Sony ICD-35 - Ic Recorder Manuale utente
3-866-556-21 (1)
IC Recorder
1999 by Sony Corporation
ICD-35
Operating Instructions
Mode d’emploi
GB
FR
2GB
Table of Contents
What is the ICD-35 IC recorder? ................................................................. 4
Features .......................................................................................................... 5
Getting Started
Step 1: Installing the Battery........................................................................ 6
Step 2: Setting the Clock............................................................................... 8
Basic Operations
Recording Messages ................................................................................... 10
Playing Back Messages............................................................................... 13
Erasing Messages ........................................................................................ 16
Advanced Operations
Moving Messages to a Different File — Move Function ....................... 18
Adjusting the Playback Speed .................................................................. 20
Adding a Recording to a Previously Recorded Message ...................... 21
Playing Back a Message at a Desired Time with an Alarm ................... 22
Preventing Accidental Operation — HOLD function ........................... 26
GB
3GB
Menu Settings
Selecting the Recording Mode .................................................................. 27
Turning off the Beep Sound ....................................................................... 28
Selecting the Microphone Sensitivity....................................................... 30
Playing Back All Messages in a File Continuously ................................ 31
Selecting the Illumination Mode of LCD Back Light ............................. 32
Additional Information
Precautions ................................................................................................... 33
Troubleshooting........................................................................................... 34
Specifications ............................................................................................... 35
Index to Parts and Controls ....................................................................... 36
Menu map .................................................................................................... 38
Index ............................................................................................................. 40
GB
4GB
What is the ICD-35 IC recorder?
The ICD-35 IC recorder enables you to record and play back oral messages
in the built-in IC memory.
rRecording
When a new message is recorded, it is automatically added after the last
recorded messages.
Unlike with tape recorders, you do not need to worry about recording
over previously recorded messages by mistake.
Since you do not need to search for the end of the last recording, you can
start recording quickly whenever you wish.
rPlayback
With this IC recorder, you can quickly locate the message you want to play
back.
Reviewing the current recording is also very easy.
rErasing
You can quickly erase unwanted messages with an easy operation. When a
message is erased, the next message automatically advances, leaving no
blank space.
Meet Mr. Brown at
2 p.m. tomorrow.
11:30, November 1 12:00, November 1 10:00, November 2
Don’t forget
to call Mary Make remittance
at ABC bank
9:00, November 4
Send a card to
Miss Smith
Message 1 Message 2 Message 3
Message 1 Message 2 Message 3 Message 4
Message 4
Before
Erase Message 3
After
Remaining messages
are renumbered.
Message 1 Message 2 Message 5
Message 4Message 1 Message 2
Message 3
Message 3
5GB
Features
•16 minutes (SP)/32 minutes (LP) recording time
As you can record for 32 minutes maximum (in LP mode), this unit is
useful for recording messages, appointments or meetings.
•Organizing message files
You can choose among 3 different files to record and store your
messages.
You can easily move messages from one file to another (see page 18).
Up to 99 messages can be recorded in each file.
•Alarm function
You can start playing back a desired message with an alarm on a desired
date and time (see page 22). You can use this function to remind you of
the time of the meeting, etc.
•Playback speed control
You can play back messages rapidly (+30%) or slowly (–15%) (see page
20). This is useful when playing back a long recording such as a meeting.
•Adding a recording to previously recorded message
You can add a recording to the message being played back to count as
one message.
6GB
If the battery compartment
lid is accidentally detached,
attach it as illustrated.
Step 1: Installing the Battery
1
2
Slide and lift the battery
compartment lid.
Insert a LR03 (size AAA)
alkaline battery with correct
polarity, and close the lid.
1
To take out the battery
Take out the battery by pushing
the ’side of it as illustrated.
Getting Started
1
2
2
7GB
Clock setting display appears when you insert battery for the first time, or
when you insert battery after the unit has been without battery for a
certain period of time. Please refer to Steps 2 to 4 in “Step 2: Setting the
Clock” on pages 8 and 9 to set the date and time.
Replacing the battery
“i“ appears on the display when the battery becomes weak and it flashes
when the battery is exhausted. Replace the battery with a new one.
Battery life*
With continuous use, approx. 10 hours recording/5 hours playback
* Using Sony alkaline battery LR03 (SG)
* Using in LIGHT OP mode, playing back through the internal speaker with
VOL control at around 3
The battery life may shorten depending on the operation of the unit.
Notes
• Do not use manganese batteries for this unit.
• When you replace the battery, insert the new one within 3 minutes after you
removed the exhausted one. Otherwise, the display may show the clock
setting display or incorrect date and time when you reinsert the battery. In this
case, set the date and time again.
The recorded messages, however, will remain.
• Do not charge a dry battery.
• When you are not going to use the unit for a long time, remove the battery to
prevent damage from battery leakage and corrosion.
Getting Started
8GB
Step 2: Setting the Clock
1Press MENU to enter
the menu mode.* 2Press –=once to display
“SET DATE”.
3Press (pPLAY/STOP.
The year digits will flash.
2Press (pPLAY/STOP.
The month
digits will flash.
3Set the month and day in
sequence, then press
(pPLAY/
STOP.
The hour
digits will
flash.
1Press –=or
++ to select
the digits of
the year.
Clock setting display appears when you insert battery for the first time, or
when you insert battery after the unit has been without battery for a
certain period of time. In this case, proceed from Step 2.
Display the clock setting display.
Set the date.
1
2
* The “ALARM” display may
appear instead of the “MODE”
display (see page 38).
9GB
Set the time.
Exit from the menu mode.
Press MENU.
3
2Press (pPLAY/STOP.
The minute digits will flash.
3Set the minute.
4Press (pPLAY/STOP at the
time signal.
The display will return to
“SET DATE”.
4
1Press –=or ++ to select the digits of the hour.
Getting Started
10GB
Recording Messages
You can record up to 99 messages in each file (A, B and C).
Since a newly recorded message is automatically added behind the last
recorded message, you can start recording quickly without searching for
the end of the last recording.
Select the file.
Start recording.
During recording, the OPR indicator lights up in red.
You do not need to keep pressing REC START/STOP while recording.
1
Press FILE repeatedly until
the the desired file is
displayed.
Current file
1Press REC START/STOP.
Current message
number
Remaining recording time
2Speak to the built-in
microphone.
2
OPR indicator
e.g. Message 1 Message 2 Blank space
Newly recorded message
Basic Operations
