Sony ICD-BX132 Manuale utente
Easy to use, the ICD-BX132 delivers. Combining simplicity and capability the
ICDBX132 oers: extra-long recording time, add and overwrite functions for
corrections and additions to your recordings, and digital pitch control for
playback for powerful recording capability in the palm of your hand.
Convenient recording
Complete with a large LCD display and front controls, the ICD-BX132 is easy to use while capably
capturing moments as they occur.
Built-in 2 GB ash memory1
2 GB of available internal ash memory provides ample space for recording life’s important
moments-up to 2,087 hours in fact.1
Mono Microphone
Capture thoughts, dictations and other details with great clarity via
the built-in microphone. Via an external microphone (available separately). stereo recordings
can also be made when necessary.
Automatic Record level
The recorder automatically adjusts recording levels for optimum results.
Noise Cut
Noise Cut reduces ambient noise during recording for clearer speech playback.
Low Cut
When activated, Low Cut lter helps reduce the eect of wind noise in your recordings.
Digital Pitch Control
Digital Pitch Control enables the recording to be played at a faster or slower rate without
changing the recording’s pitch.
Alarm Playback
Set a future date and time and the recording will automatically be played.
Easy Search
Rewinds or fast forwards in short increments making it easier to locate a segment in a long
recording for review.
Add/Overwrite
Did you forget a thought or mis-speak? With Add/Overwrite capability, adding to or overwriting
recordings during playback is quick and easy.
Battery Operated
Two AAA batteries (supplied) will deliver up to 20 hours of recording time so you will never miss a
beat.2
Specications
Audio
Format(s)
Supported
Recording -
MP3 les:
Bit Rate: 2 kbps - 192 kbps, VBR
File Extension: .mp3
Playback -
MP3
ICD-BX132 Digital Flash Voice Recorder
Frequency Range
MP3 192k (SHQ): 75 - 15,000 Hz
MP3 128k (HQ): 75 Hz - 15,000 Hz
MP3 48k (Mono) (SP): 75 Hz - 10,000 Hz
MP3 2k (Mono) (LP): 100 Hz - 3,000 Hz
Microphone Built-in, unidirectional microphone
Recording System Digital, Monaural Recording
Audio Features
Microphone
Sensitivity Feature Yes (Hi/Lo)
Recording
Features
4 Modes:
SHQ (192kbps): Super High- Quality monaural mode
HQ (128kbps): High-Quality monaural mode
SP (48kbps): Standard Play monaural mode
HVXC (2kbps): Long Play monaural mode
Convenience
Message Folder(s)
5 Pre-Programmed at factory (5 Maximum)
99 Maximum les per folder
495 Maximum les
Convenience Features
Erase/Protect Yes
Message Folder(s) 5 folders
On-Screen Clock Yes
Safety Lock Hold Function
Search Features Cue/Review, Easy Search
General
Recording and
Playback Times
SHQ - MP3 (192 kbps): 21 hrs 40 min; Max 13hrs battery
life
HQ - MP3 (128 kbps): 32 hrs 35 min; Max 15 hrs battery
life
SP - MP3 (48 kbps MONO): Max 86 hrs 55 min; Max 16
hrs
LP - MP3 (2 kbps MONO): Max 2087 hrs; Max 20 hrs
Recording Media Built-In Flash Memory 2GB³
Type of Use Ultra Portable Voice Recorder
Inputs and Outputs
Headphone
Output(s) 1 (Minijack, Stereo)
Microphone Input 1 (Minijack, Stereo)
Memory
Memory Size 2 GB = 2,147,483,648 bytes
Available: 1.75 GB (1,879,048,192 bytes)
Power
Battery Life
(Approx) Up to 20 hours
Battery Type Alkaline "AAA" x 2
Output Power 300 mW
Power
Requirements Two LR03 (size AAA) alkaline batteries: 3.0 V DC
Speaker
Speaker
Dimensions Approx. 1 1/8 in. (28 mm) diameter
Weights and Measurements
Dimensions
(Approx.) 1.5" x 4.5" x 0.84" (37.5 x 114 x 20.9mm) not including
projecting parts and controls
Dimensions
(Approx) Depth 0.84" (20.9 mm)
Dimensions
(Approx) Height 4.5" (114 mm)
1. 1 GB equals 1073741824 bytes, a portion of which is used for data management
functions.
2. Actual battery life will vary based on network, product settings, usage patterns, battery,
and environmental conditions. Actual storage capacity may vary based on product
settings, usage patterns, operating environment and battery condition.
© 2013 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without
written permission is prohibited. Sony and the Sony make.believe logo are trademarks
of Sony. All other trademarks are trademarks of their respective owners. Features and
specications are subject to change without notice. Non-metric weights and measures are
approximate and may vary. /Updated: March 27, 2013
Dimensions
(Approx) Width 1.5" (37.5 mm)
Weight (Approx.) 3 3/5 oz. (73 g) Including two LR03 alkaline batteries
Accessories
Supplied
Accessories
IC Recorder (1)
LR03 (size AAA) alkaline batteries (2)
Quick Start Guide (1)
