Sonytec Y MP3 Soul 100 Manuale utente
www.sonytec.com 1
www.sonytec.com 2
Subject
Operational Notes ........………...…….….............3
Player overview ..............................……............5
Accessories .....................................……...........7
LCD .................................................……...........8
Turning the power on/off .................……...........9
Playing MP3 music ..........................……......... 10
Use menu under the playing mode ....…...........12
Voice Recording Function ...................……......14
The menu under Voice Recording mode .….....17
Exit the voice recording mode ...............….......19
Setting EQ (Equalizer).......................................20
Setting Repeat mode.........................................21
Setting LCD contrast.........................................27
Setting Auto Off time.........................................29
Setting voice recording Parameter ...................30
To Delete files .....................................……......32
www.sonytec.com 3
Examine memory Information(Memory Info).....21
EQ (Equalizer) ....................................…..........22
Repeat mode ......................................…..........24
The Backlight ......................................…….......27
Examine the utilization of the internal memory .29
USB Connection .......................................…....30
System Requirements .................................….31
Installation of Manager Software .................….32
How to use Digital Audio Management System .33
Sending files to Digital Audio ......................…...34
Sending files from Digital Audio to PC .........…..37
Formatting the memory of Digital Audio ......…...39
To Delete files ........................................……....41
To refresh USB connection ....................……....43
Internal Memory Display .........................……...44
Pre-listen ................................................……....45
Trouble Diagnosis ................................…..........47
Technical Spec .....................................…….....56
www.sonytec.com 4
Operational Notes
If the Mp3 player will not be operated for a
prolonged period, remove the batteries to avoid
possible damage caused by electrical leakage.
The Mp3 player should be kept in areas free
from extreme temperature changes, moisture
and dust.
Set the HOLD switch to the release position
before operation.
Do not drop the player, which probably
cause battery fall off or damage its surface.
Battery Status (Time unit: hour)
Battery Digital Audio
Alkaline battery
Size AAA×1 12
www.sonytec.com 5
*Battery life may vary with different using
condition, manufacturer and manufacture date.
*Please change the battery under following
conditions:
Indicator appears and display the
“Low Battery” then shut down.
All buttons make no response and are not
workable even after the battery is taken out and
reinstalled.
Note:
To avoid static electricity, please If possible,
avoid operating the player in extremely dry
environment.
If the player stops running under proper
operation, please reset it by taking out battery
.
www.sonytec.com 6
Player overview
Front
Play/pause (stop)/power
LCD
USB port
FF/Mode/Rew
www.sonytec.com 7
Side face
Volume+/Volume-
Hold button
www.sonytec.com 8
Accessories
Installation CD USB Cable
Stereo Phone
Manual/
Maintenance Certificate
www.sonytec.com 9
AAA Battery
LCD
Repeat modes include Repeat, Repeat All,
Random,
Preview and Normal (Normal mode isn’t illustrated
in the figure.)
Equalizer modes include Jazz, Classic, Rock, Pop
Play repeat mode
Hold icon
Battery indicator
Type of the song
Current situation
Playback time indicator
Play
Song Number
Playback time
the song ID3 tag or
file name
www.sonytec.com 10
and Normal
Turning the power on/off
The power will be turned on when PLAY/STOP
button is pressed momentarily. In 2 seconds, a
glorious picture with blue backlight appears. The
backlight will be turned on by user setting and will
last different seconds if some button is pressed; if
not, the backlight will be automatically turned down
after user setting seconds.
Pressing PLAY/STOP button for more than
3 seconds until “Power OFF” appears on the
screen, then it’s safe to turn the power off.
