SOULLIFE STA-A7 Manuale utente
I n s t r u c t i o n s h e e t
STA-A7 5MP WIFI IP CAMERA
※ Please read this instruction sheet carefully before
using the product and keep it properly
Packing list
After open packing list box, please check product body and
accessories as blow:
Camera x 1
x 1Bottom plate
01
Screw x 6
Wallplug X 4
Adapter X 1
Conditions of use:
1. WIFI is in 2.4GHz network ( 5GHz network is not supported );
2. WIFI signal ≥ 3 cells (at installation location), you can test it by
your mobile.
Interface
Before use, please pay attention to the interface and button
of camera.
02
ScrewPower Supply Bottom plate
IR Sensor
4pcs white LEDs
4pcs array LEDs
Lens
TF card slot & reset button
Designed for
indoor/outdoor
DC power 12V
Rj45 ethernet port
Microphone
Before installed the camera, pls make sure your phone is in
2.4GHz WIFI network, 5GHz network is not supported
Operation
Tips 1: Scan QR code.
1.Download APP
Tips 2: Search “icsee” in the App Store or Search “icsee pro” in
the Google Play and download
03
Install TF card first, then connect the camera to the power
outlet.(Pls make sure you insert the TF card then power on,
otherwise maybe the TF card cannot be identified by the system)
2.Power on
01. Open the app “iCSee”, choose the “login” (picture 1)
Wire l ess netwo r k configur a tion:
3.Camera configuration
02. Click “+” button to add the device (picture 2)
Picture 1 Picture 2
Pls directly log in if you already have the account No.of Icsee
Pls register if you don’t have the account No, then Logo in.
04
03. Click “Add WIFI camera” (picture 3)
04. Pls make sure your phone is in 2.4GHz WIFI network,
and it must be in the same WIFI both for your phone
and camera. 5GHz network is not supported (picture 4)
Picture 3 Picture 4
05
05. Pls input WIFI router password, then confirm (picture 5)
06. The phone is connecting the device in the same
WIFI, pls wait. (picture 6)
Picture 5 Picture 6
06
. . . . . . . . . .
TP-LINK_65BA
Picture 7 Picture 8
08. After confirm then you can select or create a new name
for the device (picture 8)
07
07. After heard a camera voice “connect successfully”,
Will enter to “set pwd”, then confirm (picture 7)
Onl in e
Living Ro om
If you cannot install the camera, pls push the ”reset”
button, Restore factory settings, then repeat again.
You have to restore to the factory settings if more than 5
minutes you couldn’t connect your phone with camera.
09. After click “save” will enter to video preview (picture 9)
Picture 9
08
Note: For PC version pls download APP from below website:
Then download the first one:
Product Information: P6S Wi-Fi Pantilt AI IP Cameras
How to use App
Select your smart camera on iCSee APP home page, then
access various features and change settings according to
notifications.
The camera can save the video in the SD card or upload it to the
cloud storage server.
If you use SD card to save video, you must install SD card
to the camera, please make sure your SD card has good
quality; otherwise it will fail to record and even cause the
camera to crash.
If you want to use cloud storage, you can enter
“Settings” – “Cloud Service” to set up.
1.Record video
You can set motion detection on the camera, when the camera
detects a moving object, the camera will send alarm
notifications.(picture 10)
2.Alarm and notifications
Http://www.ipcam.xin
09
