Soundigital EVOPS 800.4 Manuale utente

TABLE OF CONTENTS

Introduction ..................................................................................................................

Features ........................................................................................................................

Package contents .....................................................................................................

Safety instructions ....................................................................................................

Technologies

DTM ........................................................................................................

Ultra Compact PCB .........................................................................

Robust Construction ........................................................................

Vibration Absorption Device .........................................................

Low Battery consumption ..............................................................

Marinization with protection index IP64 ....................................

Assembling and Disassembling the Plastic Seals .......................................

Panels description

Audio inputs and controls.............................................................

Power inputs and audio outputs ................................................

Electrical Dimensioning...........................................................................................

Installation sequence................................................................................................

Wiring diagram

Four channels wiring diagram.....................................................

Three channels wiring diagram...................................................

Two channels wiring diagram......................................................

Procedure for setting the gain...............................................................................

Crossovers set up......................................................................................................

Technical specs

Parameters.......................................................................................

Dimensional data...........................................................................

DEAR CUSTOMER,

C O N G R AT U L AT I O N S O N AC Q U I R I N G A P R O D U C T W I T H T H E

HIGHEST QUALITY AND TECHNOLOGY!

You have just purchased a SounDigital product of the highest technology and quality, so

we thank you for your confidence.

SounDigital products are made with raw materials of the highest quality standards, and

the most modern processes, equipment and technology are used in their production.

On this manual you will learn about the product, its features and characteristics, in order to

obtain the best result and to be able to enjoy your music with SounDigital quality and

power.

To better understand and take advantage of all the functions of the product and use it safely,

read this manual carefully and if you have any questions, consult our support by email

info@soundigitalusa.com.

FEATURES

- Resistant to moisture, water splash and dust;

- Compact design;

- Conformal coated circuit board;

- Variable crossover with LP / FULL / HP selector switch;

- High efficiency Class D;

- Robust construction, resistant to vibrations and bumps;

- IP64 Rating.

PACKAGE CONTENTS

- 1 EVOPS Amplifier

- 1 Installation quick guide with warranty card

- 1 Allen wrench 2mm

- 1 Soundigital promotional black sticker

- 1 Soundigital promotional white sticker

INTRODUCTION

SAFETY INSTRUCTIONS

THIS "WARNING" SIGN ALERTS THE USER OF IMPORTANT INFO. NOT

FOLLOWING THIS INSTRUCTIONS MAY CAUSE INJURIES TO THE USER OR

DAMAGE TO THE EQUIPMENT.

Warning!

To prevent injuries to the user or damage to the amplifier, read all safety instructions written

on this manual;

If you are insecure about the installation of this equipment, get in touch with our tech

support or with a professional specialized in car audio/vessel audio installation;

Before proceeding with the installation of any electric equipment on your vehicle/vessel,

unplug the negative (-) terminal of the battery to avoid fires, injuries or damages;

Use your sound system safely. The continuous exposure to sound pressures over 85dB

may cause irreversible hearing damage;

This equipment is for use in DC voltage batteries between 12.6 and 14.4 volts. Before

installing the equipment, check voltage of the batteries;

Choose a ventilated place to install the amplifier ;

Mount the amplifier in a secure way. Avoid mounting it on metallic parts of the

vehicle/vessel, because it may cause ground looping (noise);

Make sure that the location chosen for the amplifier installation does not effect the

operation of the vehicle/vessel;

Please select a dry location to mount your amplifier. The products are designed to operate

in humid environments but the direct contact with water can damage the amplifier.

When passing cables through metallic walls, use rubber O-rings to avoid cable cutting and

short-circuits.

Clean the amplifier periodically with brush or dry cloth to assure the thermal efficiency of

the heatsink.

This product may reach temperatures over 60°C/140°F. Make sure it is cold before touching

it;

Be careful when making holes in the vehicle/vessel. Make sure you are not making holes in

the fuel tank, brake lines, boat hull or electrical cables of the vehicle/vessel;

Make sure the cables are properly secured throughout the installation;

Wear gloves, safety glasses and and all necessary PPE during the installation of

SounDigital amplifiers.

TECHNOLOGIES

The DTM* is a dynamic thermal management system which always maintains a high

efficiency of the amplifier by accelerating the thermal exchange of electronic components

with the heatsink

* Patent. Required

ALUMINIUM

HEATSINK

CONDUCTIVE

COOPER LAYER

ELECTRONIC

COMPONENT

DYNAMIC THERMAL MENAGEMENT - DTM

An intelligent layout, with great use of the

P C B a r e a a n d t h e u s e o f m o d e r n

co mpo ne nts wit h re d uc ed s tru ct ure

g u a r a n t e e S o u n D i g i t a l p r o d u c t s a

compact design, at the same time robust

and with excellent thermal efficiency.

ULTRA COMPACT PCB

ROBUST CONSTRUCTION

Thinking about the application of power sports, the product has an extremely robust assembly, both

the correction points and the layout of the plate were designed to withstand high vibrations, bumps

and impacts.

TECHNOLOGIES

VIBRATION ABSORPTION DEVICE

*Efficiency measured at power supply only

SounDigital amplifiers are known for their low

consumpt ion of ba ttery, and th is featu re was

improved on the EVOPS Line. The new I-POWER

SUPPLY is even more modern, which replaces the

old toroidal transformers by a new generation of "E-

E" core transformers delivers efficiency above 90%

*,ensuring more hours of sound without battery

recharge.

I - POWER SUPPLY

SounDigital added a new device to the EVOPS products which act like shock absorbers

reducing the impact of vibration on the eletronic circuit board, thereby increasing the life

and reliability of the amplifiers.

HIGH SOUND

WAVE ENERGY

LOW SOUND

WAVE ENERGY

ABSORPTION DEVICE

MARINIZATION WITH PROTECTION INDEX IP64

The product is protected against ingress of dust particles and water droplets from all sides, beyond

that, the plate receives a conformal coating treatment to protect the components from moisture.

ASSEMBLING AND DISASSEMBLING THE PLASTIC SEALS

1. Squeeze the assembled Flexible Plastics Seals

2. Pull out the Plastics Seals

DISASSEMBLING THE PLASTICS SEALS

132

1. Hold the disassembled Flexible Plastics Seals and fit them in their specific housing;

2. Each connector has its specific Plastic Seal;

3. Make sure the Flexible Plastics Seals are perfectly fitted.

ASSEMBLING THE PLASTICS SEALS

132

Potentiometer

Plastic Seal

RCA

Plastic Seal

Slide switch

Plastic Seal

PANELS DESCRIPTION

Variable crossover control - 45Hz to 850Hz

Crossover Switch

Low Pass - Full - High Pass

Variable Gain Control

Audio input - RCA connector

CH3/CH4

CH1

CH3

CH1/CH2

CH3/CH4

CH1/CH2

CH2

810

CH4

PANELS DESCRIPTION

"Power ON" LED indicator (Blue)

Negative power supply connector (GND)

Remote power supply connector (REM)

Positive power supply connector (+12VDC)

Positive speaker connector

Negative speaker connector

Positive speaker connector

Negative speaker connector

CH2

CH1

CH4

CH3

CH2

CH1

CH4

CH3

22 21 20 19 18 17 16 15 14 13 12 11

C 4H

ELECTRICAL DIMENSIONING AND AUDIO INPUTS

ELECTRICAL DIMENSIONING

For proper operation of your SounDigital amplifier, you need the proper dimensioning of the

electrical system and the cables used.

The table below shows the minimum section of GND cables, +12VDC cables and speaker

output cables according to the power generated by the amplifier.

We recommend the use of ONLY OFC (Oxygen Free Copper) Cables on the installation of

our products.

POWER CABLE

GROUND CABLE

SPEAKER CABLE

800

WRMS

10mm² - 7 AWG

2x1.5mm² - 15WG
