Specifications
MAINstage Digital Surround Sound System
•Surround Sound 5.1 channels, digital
•DSP Processor Zoran 38601-50M IPS
•Surround algorithm Zoran VMD
®
•Class-D amplifiers (4) 2 x 10WRMS <3%THD into 4 Ohms (satellites)
(40W Music)
2 x 10WRMS <3%THD into 4 Ohms (subwoofer)
(40W Music, subwoofer)
•Maximum SPL@1m 95dB
•Main Speakers 2 each 50x70 mm
with Neodymium-sandwich magnets
•Internal Subwoofer 1 each Super-4”with Neodymium-sandwich magnet
•Power Supply Digital, 130kHz 95–265Vac 50/70Wdc
•Inputs (4) Analog One: 125mV/10V Switch selected
Analog Two: 125mV for 80 dB SPL
Digital One: SP/DIF coax
Digital Two: Optical / TosLink
•Outputs (1) Analog: Sub-subwoofer out
•Accessories IR remote control
AngleEase™ TV-top leveling feet
1 each 2m optical
1 each 1/8”mini phone jack cable
•Controls System volume (IR)
Subwoofer level (local)
Source select, mute (IR and local)
Surround/stereo (IR only)
•Modes On/Off/Standby
•Standby Power Less than 4.5W
•Display Four color LEDs
•Chassis color Silver or charcoal gray
•Weight Approx. 2.2kg (4.85lbs)
•Dimensions (WxHxD) 425 x 65 x 230 mm
16.7”x 2.5”x 9”
soundmatters® believes in a policy of continuous product improvement, therefore specifications are subject to change without prior notice.
4 5
Warranty/Service
There are two things you must do to ensure trouble free service in the event you need warranty repairs.
1. Keep your original sales receipt in a safe place. A copy of the receipt will be required to obtain warranty service.
2. Be sure your retail dealer has written the date, the model number, and the serial number (if applicable) of the
Product on the receipt.
To give yourself an extra measure of protection, make a separate record of the information about your purchase and
keep it in a safe place. In the event you misplace the sales receipt, your dealer may be able to give you a copy. Take a
moment now to read the terms of your warranty. Check to be sure your sales receipt is dated and has the Product model
number and serial number (if applicable) on it. Then put it away in a safe place.
When shipping a product in for service:
• Email or call soundmatters for the proper ship to address for servicing and an RMA (return merchandise copy of your
original sales receipt that has the date, the Product model number and serial number (if applicable) written on it.
• Always ship Products in the complete original packing material.
• Avoid shipping Products via the Postal service. If you must use the Postal service, be sure to register and insure the
package.
soundmatters Limited Warranty
soundmatters, inc.(soundmatters) warrants to the original consumer purchaser of the soundmatters Products
described in this manual, that the Product will be free from defects in materials and workmanship for a period of two
(2) years after the date of purchase. soundmatters’ sole obligation under this warranty shall be to provide, without
charge, parts and labor necessary to remedy the defects, if any, that appear during the warranty period.
This warranty is the sole and exclusive express warranty given with respect to the Product. All other express warranties
are hereby excluded. Neither soundmatters nor the authorized dealer who sells the Product is responsible for indirect,
incidental, or consequential damages. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific
legal rights and you may also have other rights, which vary from state to state.
IMPORTANT -- Keep your original sales receipt. Be sure the retail dealer has written on it the date, model number, and
serial number (if applicable) of the Product. This information is required for warranty service.
This warranty is limited to:
• Products purchased from authorized soundmatters retail dealers in North America. soundmatters will supply a list of
authorized dealers on request.
In order to obtain service you must:
• Return the Product, freight prepaid, to the soundmatters dealer from which it was purchased, an authorized
soundmatters independent service agency, or to soundmatters. If necessary you may call soundmatters Customer
Service Department for the names and addresses of authorized independent service agencies in your area.
• Provide proof of purchase in the form of a copy of your original sales receipt, the date, model number, and serial
number (if applicable) of the Product must be written on the sales receipt.
This warranty does not cover:
• Damage that is the result of misuse, abuse, accident (including but not limited to damage by water),faulty hookup,
defective or maladjusted associated equipment, or the use of the Product with equipment for which it was not
intended.
• Cosmetic defects that appear more than thirty (30) days after the date of purchase. Cosmetic damage caused by
improper handling is also excluded.
• Products that are used for commercial purposes.
• The cost of removing or reinstalling the Product.
• Damage that occurs while the Product is being shipped to whoever will service it. See the information above
regarding shipping procedures.
This warranty is void if:
• The Product identification or serial number label is removed or defaced in any way.
• The Product is serviced or repaired by any one other than soundmatters or an authorized soundmatters dealer or
service agency.
For warranty information contact:
soundmatters,inc san francisco, ca 94110
