Soundstream Picasso PCO-8 Manuale utente

2013

SUBWOOFERS

PCO-8 PCO-10 PCO-12

Thank you for choosing SOUNDSTREAM woofers. Designed and engi-

neered in the USA, this product combines innovative technology with

the finest materials to consistently deliver Absolutely State of the Art

performance, sound quality, reliability, and value. This SOUNDSTREAM

product reflects our commitment to offer you unparalleled perfor-

mance and quality for years of dependable service and listening en-

joyment.

Pressed Paper Pulp Cone

Rubber Surround

2.0” 4-layer VC on Aluminum Former

Nickel Plated 8ga. Compression Terminals

Poly-Cotton Suspension Spider

Vented T-Yoke Back-plate

Polpropylene Molded Dust Cap

Textured Basket with Voice Coil Cooling

Features, Parameters, & Dimensions

www.SOUNDSTREAM.com

Impedance 4ohm 4ohm 4ohm

Re4.0473 3.9753 4.0953

Fs43.92 29.68 32.07

Qes 0.8606 0.6981 0.5749

Qms 4.9025 4.1628 3.9285

Qts 0.7321 0.5978 0.5015

Le(mh) 2.5446 2.3920 2.5441

dIam 8Inch 10Inch 12Inch

sd50.2655 In^2 78.5398 In^2 113.0973 In^2

Vas (L) 38.1034 79.8825 175.5596

BL8.1734 11.8511 14.0423

mms 51.4638 133.2297 177.8864

sen 87.49 86.41 88.42

Rms/max 240/600 360/900 500/1200

cut dIam 7.8Inch 9.6Inch 11.6Inch

mount d. 4Inch 5Inch 6Inch

pco-8 pco-10 pco-12

Enclosure Construction

Enclosure Dimensions

Enclosure Recommendations

www.SOUNDSTREAM.com

Included in this manual are a number of different enclosure sugges-

tions. These are by no means the only enclosures to use, but they

provide a starting point to determine the correct enclosure for your

needs many factors must be addressed (amount of power, vehicle,

placement, crossovers, etc) Therefore, as always, SOUNDSTREAM

recommends that your subwoofer be installed by an authorized

SOUNDSTREAM dealer.

All enclosures should be made of .75” (3/4”) material only. When pos-

sible, make the baffle 1.5” (1 ½) thick and add .75” (3/4”) to the depth

of the enclosure to compensate. All volumes INCLUDE vent/port and

subwoofer displacements. DO NOT change the volume unless you

plan on adding a substantial amount of bracing. For added per-

formance, applying a coat of fiberglass resin to the interior walls will

greatly improve sealing the enclosure. Adding a thin layer of poly-fill

will improve response by smoothing out reflections within the enclo-

sure.

pco-8 pco-10 pco-12

seaLed pco-8 pco-10 pco-12

mIn .45cu Ft. .75cu Ft. 1.0cu Ft

optImum .75cu Ft. 1.0cu Ft. 1.25cu Ft.

poRted

mIn .75cu Ft. 1.0cu Ft. 1.5cu Ft.

poRt WxL 4Inch x7.5Inch 3Inch x4.5Inch 5Inch x4.5Inch

F3 (hz) 53 48 55

optImum 1.0cu Ft. 1.5cu Ft. 1.75cu Ft.

poRt WxL 4Inch x6.35Inch 4Inch x8.5Inch 5Inch x4Inch

F3 (hz) 42 39 42
