SP-B80HI / SP-B80I Planetary Mixer
Figure 1
GUARANTEE
SPAR provides one year guarantee,
either the date of dispatch from our factory, or
the date of purchase from one of our
approved distributors. We will replace any
defected parts resulted from faulty design,
material or workmanship. In addition to this,
any repair must be carried out by our
authorized Service Agent. All defective parts
without no alteration or repair can be returned
to SPAR or the nearest authorized
representative, postage paid within one year
warranty.
SP-B80HI / B80I is a floor type planetary
mixer designed for commercial use by the
professional caterer. It has a total bowl
capacity of 80 Quart, combined with 4-speed
gearbox to ensure that all mixing
requirements can be met.
The intended use of the mixer is the food
processing industry, which not including the
pharmaceutical industry, chemical industry,
printing, etc.
INSTALLATION
The installation of mixer should comply
with a technician.
The mixer is lubricated and ready to run,
when it leaves the factory. During the
transportation or fitting, please do not lean
over 35 degree to avoid the gear oil leaking
from the gear oil container. Please use forklift
to transporting. Please see Figure 1.
ELECTRICAL CONNECTION
Before connecting the mixer to the
electrical supply, please check that the details
on the rating plate (located on the rear of the
mixer) correspond to the details of your
electrical connection.
The mixer is supplied with a trailing lead
fitted with a trailing lead fitted with a molded
plug. If the style of plug is unsuitable for the
socket you plan to use, the plug must be cut
off and replaced with an appropriate plug. In
terms of the 3-phase, when the mixer is
located and connected with the plug, please
make sure that the shaft goes clockwise. If
the shaft goes counterclockwise, please
replace the wires: R.S.T. (USA) L1, L2, L3,
(Europe). To replace the wires each other
until the shaft goes clockwise.
The mixer should be plugged into a
switched socket which isolates all poles and
has a minimum contact clearance of 3mm
and locates close to the mixer for use in an
emergency and to facilitate servicing (max.2
meters of cable). The machine must be
incorporated into a potential equalization
system.
The leakage current for this appliance is
no greater than 1 mA/KW. If the electrical
supply cable to the machine becomes
damaged, it must be replaced by a qualified
electrician using cable which is 3.0
specification or higher and suitable for a 3HP
motor load. The ground wire is fixed to the
machine and this connection must be kept
intact.
Note: The mixer MUST be grounded.
-The minimum requirement for all electrical
equipment is correct operation between aire
temperature of +5and +40.
-Electrical equipment is capable of operating
correctly when the relative humidity does not
exceeding 95% at a maximum temperature of
+40.
-Electrical equipment is capable of operating
correctly at altitude up to 1000m.
-Electrical equipment is designed to withstand
to protected against the effects of
transportation, and storage temperature
within a range of -25to +55and for
short periods not exceeding 24h at up to +70
.
