VAC316-3
Operating Manual
GENERAL OPERATION
FILTER CLEANING
1. The clear flow filters may be cleaned on the machine by switching the machine off,
operating the filter shaker approximately 10 times and allowing the dust to settle.
2. The clear flow filters may be periodically removed for cleaning, if required, by blowing
off the dust with compressed air or brushing/vacuum cleaning. This should be carried
out as follows: -
(a) electrically isolate the machine prior to maintenance
(b) operate the shaker 10 times and allow dust to settle
(c) access to the clear flow filters is gained by removing the induction head which is
held in position by two lower toggle clips.
COLLECTION DRUM REMOVAL AND FITTING
To lower the drum, stand behind the cleaner and pull the catch upwards. This will allow the
handle to rise and the drum, will descend to the ground. The drum can now be rolled away
from the cleaner on its own castors.
To replace the drum push it back against the support pins and raise it by pulling the handle
down until it engages under the catch.
COLLECTION OPTIONS
WET PICK UP (can be used with swarf basket & stand)
The float valve assembly must be used when collecting liquids to prevent entry of liquids
into the motor.
1. Do not leave the hose end immersed in the liquids being a collected. Ensure that air is
entrained as well as liquid. (This helps prevent a whirlpool action of the liquid in the
collection bin)
2. Frequently check that the float valve is clean and free to operate.
Part no: 546339900 wet option assy, 546338400 float assy
SWARF BASKET
Do not fill the swarf basket so full that it overflows or is too heavy to lift.
If the material being collected is very wet, or in liquid, a float valve assembly must be used.
Part no: 546340100 Swarf basket (inc stand)
PLASTIC BAG COLLECTION (Light materials collection only)
1. Remove the drum from the machine. Lift the spring plunger knob, on the inlet casting,
upwards and insert the stub pipe. Ensure that the slot in the casting of the stub pipe in the
12 o’clock position and push in until it is inline with the spring plunger knob. Release the
plunger knob to lock the stub pipe in position.
2. Fit the plastic bag into the collection bin and stretch the open end of the plastic bag over
the top of the collection bin.
3. Push the plastic bag over the stub pipe so that the stub pipe penetrates the plastic bag.
(It helps if a hole or cut is made in the bag first)
4. The collection bin with plastic bag may be fitted to the machine in the normal way.
5. When emptying, it may be easier, dependent on how full the bag is, to remove the stub
pipe.Part no: 016724400 Plastic bag (500g), 536313800 Stub pipe
