Specialized Globe Throttle Manuale utente

What’s included

What’s required

# INCLUDED ITEMS QTY DESCRIPTION

AGlobe Throttle 1

# REQUIRED ITEMS QTY DESCRIPTION

BSmall Globe torque wrench 1

C2.5 mm hex bit 1 HMI display bolt

D3 mm hex bit 1 Throttle bolt

This document will guide you through installing and using your new

throttle. Please read through the entire manual before beginning

installation, and thoroughly inspect the throttle and its components

before using it.

Assemble the throttle

zPower off the bicycle on the HMI display (A).

zUsing a 2.5 mm hex key, loosen and shift the HMI display to install

the throttle (B).

zUsing a 3 mm hex key, open the throttle clamp (C) and mount

the throttle between the HMI display and the grip on the left side

of the handlebar.

zPosition the throttle in a comfortable position for operation, then

using the small Globe torque wrench and a 3 mm Hex bit, torque

the throttle screw (D) to 2 Nm.

zRe-position the HMI display to the desired angle and view, then

using the small torque wrench and 2.5 mm hex bit, tighten the

HMI display bolt (A). Do not over-tighten the bolt.

zLocate the throttle cable connector at the top of the cable wrap

(A). Remove the blind plug (B) and connect it to the throttle’s

connector, ensuring the connection is secured.

Hold on to your blind plug. If the throttle is disconnected, it

is essential to replace the blind plug to ensure the wiring

harness remains weatherproof.

Activate the throttle

zThe throttle must be activated in the app before the throttle will

work.

zDownload the Globe app from your app store.

zConnect your bicycle to the app and, navigate to the settings

screen and activate the throttle.

The Throttle must be installed before activating it on the

Globe app

Using the throttle

zPress down on the th rottle lever (A) to increase your speed.

zRelease the throttle lever (B) to reduce your acceleration and

speed.

Maintenance

zRegularly check the wiring and connections to ensure they are

secure and functioning correctly.

zKeep the throttle clean and free of debris.

zBefore every ride, ensure the throttle is working correctly and not

sticking or becoming stuck in any position.

zIf you experience any problems with the throttle or notice any

damage, discontinue use and contact Rider Care for assistance.

WARNING! Do not use the throttle if it is damaged in any

way or you notice it not functioning properly. In that case,

power off the bicycle and contact Rider Care for assistance.

Safety information

WARNING! Always keep your hands on the handlebars

when riding. Failure to do so may cause you to lose control

and fall.

WARNING! Use of a throttle and the acceleration and

speed it provides may feel unusual at first. Before your

first use, you should become familiar with its function

and practice riding using the throttle in a controlled

environment without cargo or passengers and away from

traffic. Failure to follow this warning may cause you to lose

and control and fall which can result in serious personal

injury or even death.

WARNING! Before installing and activating the throttle

you should familiarize yourself with applicable local laws

and regulations. Rules may vary by country or state and

may include limits on speed/power, license or registration

requirements, mandatory helmet laws and/or minimum

age requirements. It is your responsibility to ensure that

you comply with all applicable local laws and regulations

regarding your use of the bicycle and also wear safety

equipment appropriate for such use.

User Manual & Assembly Guide

Globe Throttle

Torque specifications

COMPONENTS TOOL TORQUE

Nm in-lbf

Globe HMI display 2.5 mm hex 0.3 2.6

Globe Throttle 3 mm hex 2 17.7

SPECIALIZED BICYCLE COMPONENTS

15130 Concord Circle, Morgan Hill, CA 95037 (408) 779-6229

0000190011 _AG_R1 11/22

We may occasionally issue updates and addenda to this document.

Please periodically check www.globebikes.com or contact Rider Care to make sure you

have the latest information. Info: 877-808-8154
