ONSIP OS101
User’s Guide
D1BD
D1BD User’s Guide
Rev. 1.0 (Dec 6, 2013)
2
Directions
ONSIP D1BD is designed for indoor use only. When using ONSIP D1BD in an outdoor or equivalent
environment, you must use a water-resistant housing for the installation.
Be careful not to cause any physical damage by dropping or throwing the ONSIP D1BD. Especially keep
the device out of reach from children.
Do not disassemble ONSIP D1BD. You will void the warranty when disassembled.
Use only 12VDC power adapters.
If you would like to use the ONSIP D1BD for security, monitoring, please check the legal regulations within
the country.
D1BD User’s Guide
Rev. 1.0 (Dec 6, 2013)
3
Revision History
Date Rev No Description
Dec 6
th
, 2013
1.0 First manual revision creation.
Caution
Any changes or modifications to this device could void the warranty.
D1BD User’s Guide
Rev. 1.0 (Dec 6, 2013)
4
1.
Introduction................................................................................................................................................... 5
1.1. Overview ............................................................................................................................... 5
1.2. Specification .......................................................................................................................... 6
1.3. Applications of ONSIP D1BD................................................................................................. 7
2.
Product Description ..................................................................................................................................... 8
2.1. Contents................................................................................................................................ 8
2.2. Preview ................................................................................................................................. 9
2.3. Physical description..............................................................................................................10
2.4. Functional Description ..........................................................................................................10
3.
Getting Started........................................................................................................................................... 11
3.1. PC Requirement...................................................................................................................11
3.2 Quick Installation Guide.........................................................................................................12
4.
Troubleshooting ..........................................................................................................................................18
4.1. No power is applied..............................................................................................................18
4.2. Cannot connect to the Video ................................................................................................19
4.3. Windows Vista or Windows 7 ...............................................................................................20
4.4. Technical Assistance ............................................................................................................23
Table of Contents
D1BD User’s Guide
Rev. 1.0 (Dec 6, 2013)
5
1. Introduction
1.1. Overview
The ONSIP D1BD is a single channel IP video encoder which transmits synchronized video data in real time with
D1 resolution at full frame rate. This is possible through multi-codec (H.264, MJPEG) technology, which provides
high quality video with highly compressed data streams. The ONSIP D1BD can be connected, controlled and
monitored from a remote location through an IP connection over the internet or intranet.
The ONSIP D1BD is easy to install and owner will experience cost and space savings in the installation owing to
the state of the art technologies embedded in the system. Based on Embedded Software Solution (Embedded
Web Server, Embedded Streaming Server, Network Protocol), the ONSIP D1BD ensures unprecedented
performance and stability to be an ideal video server solution for system integration solutions.
.
D1BD User’s Guide
Rev. 1.0 (Dec 6, 2013)
6
1.2. Specification
Category Sub-Category Details
Video
Compression H.264/MJPEG
Resolution
NTSC (30 frames/sec Max.) : 704x480,
640x480, 704x240, 352x240, 176x112
PAL/SECAM (25 frames/sec Max.) :
704x576, 640x480, 704x288, 352x288,
176x144
Network
Interface RJ-45, 10/100 Mbps
Access network Static, DHCP, PPP/PPPoE
Application IPv4/6, TCP, UDP, IGMP, ICMP, ICMPv6 etc.
I/O CVBS Video input
Power Supply DC Adapter 12V DC adapter
Motion Detection 3 zones Arbitrary shape with independent sensitivity
Upgrade Firmware upgrade over IP network
Administration Remote administration over IP network
Client & Viewer
Web Viewer Simple viewing over internet explorer
Speco-NVR Standard VMS software
Dynamic IP support
DDNS support Supported
Security
Video stream encryption
ID and Password protection
IP filtering for restricting administrative
Time management
Sync to PC Synchronize to PC only once
Manual Manual time setting
Internet Time
Server Synchronize to Time Server
DLS Daylight savings
SDK support
Active-X
HTTP
Source filter
D1BD User’s Guide
Rev. 1.0 (Dec 6, 2013)
7
1.3. Applications of ONSIP D1BD
Security surveillance (buildings, stores, manufacturing facilities, parking lots, banks, government facilities,
Military etc.)
• Real time Internet broadcasting
• Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.)
• Remote Learning
• Weather and environmental observation
D1BD User’s Guide
Rev. 1.0 (Dec 6, 2013)
8
2. Product Description
2.1. Contents
Open the package and check if you have the followings:
Components Description Remarks
ONSIP D1BD ONSIP D1BD Encoder
Quick Reference Guide Quick installation guide
D1BD User’s Guide
Rev. 1.0 (Dec 6, 2013)
9
2.2. Preview
ONSIP D1BD
ONSIP-Installer VMS Software
(Speco-NVR)
H.264 1CH IP Encoder PC software to allocate an IP
address to the ONSIP D1BD
PC software to view and record the
A/V streaming data transmitted from
ONSIP D1BD
D1BD User’s Guide
Rev. 1.0 (Dec 6, 2013)
10
2.3. Physical description
2.3.1. External View
Figure 2-1. External view of ONSIP D1BD
2.4. Functional Description
RJ-45: 100Mbps Ethernet (RJ-45).
12VDC Input.
Apply power through 12VDC Input.
CVBS Video In: Connect conventional analog video signal.
