Speco PVS-CAMB Manuale utente

speco technologies

PVS– CAMB

B/W CCD OBSERVATION CAMERA

WITH VARIFOCAL LENS

speco technologies

200 New Highway

Amityville, NY 11701

Toll Free : 1-800-645-5516

In Metro NY : 631-957-8700

www.specotech.com

OPERATION MANUAL

INSTRUCTION MANUAL

B/W CCD OBSERVATION CAMERA

WITH VARIFOCAL LENS

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE

PARTS INSIDE, REFER FOR SERVICE TO QUALIFIED

SERVICE PERSONNEL.

The exclamation point within an equilateral triangle is intended

to alert the user to the presence of important operating and

maintenance (servicing) instructions in the literature

accompanying the appliance.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE

THIS APPLIANCE TO WATER OR WET LOCATIONS.

1 PVS-CAMB

MEMO

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION

MEMO

DIMENSION

FRONT SIDE

PVS-CAMB 2

GENERAL FEATURES

yDigital signal processing

y0.02 LUX sensitivity

yBack Light Compensation

50mm

DIGITAL CCD CAMERA

125mm

50mm

BACK

50mm

SPEAKER

OUT OUT

POWER

MONITOR

50mm

SENSOR

TRIGGER G B+

ESC AGC

ON ON

ESC AGC

OFF OFF

SPEAKER

+ GND

3PVS-CAMB

SPECIFICATIONS

Always use discretion when installing video and or audio surveillance

equipment especially when there is perceived privacy or an expectation of

privacy. Inquire regarding federal, state and or local regulations applicable

to the lawful installation of video and or audio recording or surveillance.

Party consent may be required.

PVS-CAMB 4

ITEM PVS-CAMB

Image Sensor Varifocal Lens (3.5mm ~ 8mm)

Effective Pixels 512H ×492V (270K pixels)

Scanning System 525 Lines 2:1 Interlace

Scanning

Frequency 15.734KHz(H), 59.94Hz(V)

Resolution 420TV – Lines

Shutter Speed 1/60 ~ 1/100,000 sec

S/N Ratio More than 50dB (AGC off)

Sync. System Internal

Min. Illumination 0.02LUX (F1.2)

Video Output VBS 1.0 Vp-p (75 ohm load)

Lens C/CS MOUNT

Power Supply DC 9.5V ~ 16V

Power

Consumption 90mA(DC12V)

Operating Temp. -10℃~ +50℃

Operating Humidity 90% RH max.

Weight Approx. 250g

Accessory 60ft cable , stand, wrench

Option : PIR sensor

SPECIFICATIONS

yESC ON/OFF

yAGC ON/OFF

ySPEAKER ON/OFF

yAUDIO

ySENSOR (TRIGGER,G,B+) FOR PIR

50mm

ESC AGC

ON ON SPEAKER

ESC AGC

OFF OFF

OUT IN

POWER

MONITOR

50mm

DIN JACK CONFIGURATION

①DC 12V OUTPUT ② N.C

③ VIDEO INPUT ④ PIR INPUT

⑤AUDIO INPUT ⑥AUDIO OUTPUT

SNESOR CABLE CONFIGURATION

(RED: DC 12V)

(BLACK : GND)

(WHITE : TRIGGER)

SENSOR

TRIGGER G B+

SPEAKER

+ GND

⑥ ⑤

④ ③

② ①
