This manual describes the LORAD LPX-200 Portable

Industrial X-ray Unit and explains the procedures to properly

set up, inspect, operate, and maintain this system.

Intended Use

The LPX-200 is designed to meet the needs of the commercial

NDT user. The system is intended for, but not limited to, the

inspection of materials for:

◆defects

◆inclusions

◆cracks

◆corrosion

◆porosity

SYSTEM OVERVIEW

The LPX-200 can generate x-ray potential up to 200 kilovolts

(kV) and tube current up to 10 milliamperes (mA). The

maximum allowable dissipation is 900 watts. Maximum tube

current is limited automatically by the Control Unit to 10mA,

or to a value that does not cause dissipation greater than 900

watts at a set kV level.

The system offers a 100% duty cycle and consists of the

following assemblies:

◆the Control Unit

◆the Tube Head

◆the Cooling Unit, (liquid cooled units only)

◆the Electric Cooling Fan (air cooled units only)

These assemblies are described in detail next.

Figure 1-1:

The LPX-200 X-ray System

1-2

Chapter 1:Introduction & General Information

LPX-200

Industrial Ima

stem

The Control Unit

The radiographer uses the Control Unit to set the radiographic

exposure parameters, and to activate/deactivate x-ray

emissions from the Tubehead. One hundred feet of cable is

supplied with the system, which enables the Control Unit an

operator to maintain a safe distance from the x-ray Tubehead

during use.

The digital-based, microprocessor-regulated Control Unit

houses all the system pushbutton operating controls, an

exposure factor LCD Screen (for display of exposure factors),

a Message LCD Screen (for display of operating mode and

system messages), and the circuitry required to provide power

to the Tubehead and Cooling Unit.

The Control Unit is enclosed in a metal container with a

removable cover. A collapsible handle is attached to the cover

to provide a means of transporting the Control Unit.

TheTubehead

The Tubehead is a cylindrical aluminum shell assembly

housing the x-ray tube, the high voltage power supply, and the

filament supply. It is insulated with sulfur hexafluoride gas,

pressurized to 50 psi @70°F. Power to operate the x-ray tube

is supplied through a shielded cable that connects the

Tubehead to the Control Unit. The x-ray tube is end

grounded, with an exposed anode which contains a beryllium

window approximately 2 inches from the anode end. Built in

carrying handles are at each end of the Tubehead.

There are two Tubehead models available:

◆Liquid-cooled

◆Air-cooled

The liquid-cooled Tubehead uses a separate Cooling Unit to

dissipate anode heat. These models have a length of twin hose

attaching the Tubehead to the Cooling Unit. Air-cooled

models have an electric cooling fan mounted at the anode end

of the Tubehead. The fan is powered by an interconnecting

cable from the Control Unit.

The Cooling Unit

(liquid-cooled units only)

The Cooling Unit dissipates heat generated at the anode of the

x-ray tube. Liquid coolant from a self-contained reservoir is

pumped through one side of a twin hose assembly, into the

Tubehead. In the Tubehead, coolant flows through a cooling

manifold, into the anode, and then back to the Cooling Unit

through the second half of the twin hose assembly.

Once in the Cooling Unit, coolant passes through a flow

switch that is electrically interlocked with the Control Unit,

and then through a filter to screen out contaminants. From the

filter, coolant flows through a forced air radiator, where

conducted heat is dissipated, and then back into the reservoir.

An electric motor-driven fan and pump assembly circulates

coolant and creates airflow through the radiator. Power is

supplied via an interconnecting cable from the Control Unit.

When properly connected to the system, the Cooling Unit is

automatically activated by a switching circuit within the

Control Unit.

Indice

Altri manuali Spellman Stampante tutto in uno

Spellman

Spellman SPX Series Manuale utente

Manuali Stampante tutto in uno popolari di altre marche

Triumph Adler

Triumph Adler DC 2016 Manuale

Epson

Epson WorkForce WF-2510 Guida utente

Epson

Epson Stylus Scan 2000 Manuale di installazione e funzionamento

Epson

Epson PictureMate Snap PM 240 Manuale di istruzioni

Konica Minolta

Konica Minolta bizhub C35 Manuale utente

Brother

Brother MFC-J430w Manuale utente

Konica Minolta

Konica Minolta BIZHUB 558 Manuale utente

Lexmark

Lexmark MX710 Series Manuale

Brother

Brother MFC-9760 Manuale utente

Lexmark

Lexmark XC8155 Manuale utente

Lexmark

Lexmark X642E Manuale utente

Sharp

Sharp MX-2310U Guida

Aficio

Aficio 200 Manuale utente

Canon

Canon ImageCLASS 2300 Manuale

Ricoh

Ricoh Pro C900 Manuale utente

Lexmark

Lexmark X925 Manuale utente

Brother

Brother Business Smart MFC-J4510dw Manuale utente

Epson

Epson Stylus CX8400 Series Manuale utente
