CZE MANUAL 1 118030-001 REV F
Chapter 1
INTRODUCTION
1.1 Description of The CZE Series
he CZE series of high voltage power supplies
provides very well regulated, low ripple high voltage
in a highly efficient, compact design. The
dramatically reduced size of these modules, compared to
traditional high voltage modules, is obtained by a state-of-
the-art off-line resonant converter. The resonant converter
utilizes a unique control scheme, which allows constant
frequency operation while maintaining high efficiency.
High operating frequency allows for very low ripple and
excellent dynamic response capabilities.
The DC output voltage and current are controllable over
the full range of operation. Monitoring and control
signals are provided for simple, yet flexible control of the
power supply. The CZE series operates from 24VDC
±10%. (User should specify the input voltage at the time
of ordering). The CZE series operates at 9W continuous.
The series does not require forced air cooling. The
ambient temperature must be kept below the maximum
rating as specified in 1.2. Consult Spellman Sales
Department for higher power capabilities of the CZE
series.
The standard warranty applies to the CZE series modules.
Consult factory about the warranty for custom modules.
1.2 CZE Specifications
•Output Control: Voltage and current are externally
programmable over the entire range from zero to
maximum rating via 0-10VDC reference or
potentiometer. (Other scale factors for control and
monitoring can be provided i.e. 1 volt per 10KV, 1
volt per 1mA etc.).
•Input
Voltage: 24Vdc ±10%. Consult the factory for
other input voltages.
•Voltage Regulation:
Load Regulation: 0.01% of full voltage for a no
load to full load change.
Line Regulation: ±0.01% of full voltage over the
specified input voltage range.
•Current Regulation:
Load Regulation: 0.05% ±25uA from 0 voltage to
full voltage.
Line Regulation: ±0.01% of full current over the
specified input voltage range.
•Ripple:
0.1% p-p of output voltage.
•Polarity:
Reversible via TTL Signal in Polarity Control Signal
Pin.
•Stability:
0.01% per hour after 1/2 hour warm up.
•Temperature Coefficient:
100 ppm per °C.
•Temperature:
Operating: 0°C to +50°C
Storage: -40°C to +80°
•Monitoring:
0 to 10VDC corresponding to 0 to 100% of output
voltage
0 to 10VDC corresponding to 0 to 100% of output
current.
0 to 10VDC corresponding to 0 to 100% of load
return current input.
Ground Fault Indication (GFI): +15V = Fault;
Output Impedance: = 4.7kOhma.
(Other scale factors available).
•Control:
Control signal for high voltage enable/disable.
IMPORTANT
This control signal in not a safety
interlock and should not be used for
protection from high voltage generation
for safety purposes.
