Z100 / Z300 Z500 Z700

OWNER’S MANUAL

PLEASE CAREFULLY READ THIS ENTIRE MANUAL BEFORE

OPERATING YOUR NEW ELLIPTICAL

Table of Contents

Product Registration…………………………………………………………………………..2

Important Safety Instructions…………………………………………………………………3

Important Electrical Information………………………………………………………………4

Important Operation Instructions……………………………………………………………..4

Assembly Instructions………………………………………………………………………….5

Operation of Your New Elliptical……………………………………………………………...15

Manufacturer’s Limited Warranty……………………………………………………………..27

EL7 Elliptical

Thank you for your purchase of this quality elliptical trainer from Spirit Manufacturing, Inc.

Your new elliptical was manufactured by one of the leading fitness manufacturers in the

world and is backed by one of the most comprehensive warranties available. Through

your dealer, Spirit will do all we can to make your ownership experience as pleasant as

possible for many years to come. The local dealership where you purchased this elliptical

is your administrator for all Spirit warranty and service needs. Their responsibility is to

provide you with the technical knowledge and service personnel to make your experience

more informed and any difficulties easier to remedy.

Please take a moment at this time to record the name of the dealer, their telephone

number, and the date of purchase below to make any future, needed contact easy. We

appreciate your support and we will always remember that you are the reason that we are

in business. Please complete and mail your registration card today and enjoy your new

elliptical.

Yours in Health,

Spirit Manufacturing, Inc.

Name of Dealer_______________________________________________

Telephone Number of Dealer___________________________________

Purchase Date_______________________________________________

RECORD YOUR SERIAL NUMBER

Please record the Serial Number of this fitness product in the space provided below.

Serial Number_______________________________________

The self-addressed product registration card must be completed in full and returned to Spirit

Manufacturing, Inc or visit: www.spiritfitness.com/warranty.htm to register online.

EL7 ver. A

CONGRATULATIONS ON YOUR

NEW ELLIPTICAL AND WELCOME

TO THE SPIRIT FAMILY

Product Registration

EL7 Elliptical

DANGER - To reduce the risk of electric shock disconnect your elliptical from the electrical

outlet prior to cleaning and/or service work.

WARNING - To reduce the risk of burns, fire, electric shock, or injury to persons, install the

elliptical on a flat level surface with access to a nominal 110-volt, 15-amp grounded outlet

with only the elliptical plugged into the circuit..

DO NOT USE AN EXTENSION CORD UNLESS IT IS A 14AWG OR BETTER, WITH ONLY

ONE OUTLET ON THE END: DO NOT ATTEMPT TO DISABLE THE GROUNDED PLUG BY

USING IMPROPER ADAPTERS, OR IN ANY WAY MODIFY THE CORD SET. A serious

shock or fire hazard may result along with computer malfunctions. See Grounding

Instructions, page 4.

■Do not operate elliptical on deeply padded, plush or shag carpet. Damage to both

the carpet and

elliptical may result.

■Keep children away from the elliptical. There are obvious pinch points, moving parts

and other caution areas that can cause harm.

■ Keep hands away from all moving parts.

■ Never operate the elliptical if it has a damaged cord or plug. If the elliptical is not working

properly, call your dealer.

■ Keep the cord away from heated surfaces.

■Do not operate where aerosol spray products are being used or where oxygen is

being administered. Sparks from the motor could ignite a highly gaseous environment

■ Never drop or insert any object into any openings.

■ Do not use outdoors.

■To disconnect, turn all controls to the off position, then remove the plug from the outlet.

■Do not attempt to use your elliptical for any purpose other than for the purpose it is

intended.

■The hand pulse sensors are not medical devices. Various factors, including the user’s

movement, may affect the accuracy of heart rate readings. The pulse sensors are

intended only as exercise aids in determining heart rate trends in general.

■Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable

for use on your elliptical. Quality athletic shoes are recommended to avoid leg fatigue.

Important Safety Instructions

Important Electrical Information

WARNING!

●NEVER remove any cover without first disconnecting AC power supply.

●If A.C. voltage varies by ten percent (10%) or more, the performance of your elliptical may be

affected. Such conditions are not covered under your warranty. If you suspect the voltage is

low, contact your local power company or a licensed electrician for proper testing.

●NEVER expose this elliptical to rain or moisture. This product is NOT designed for

Use outdoors, near a pool or spa, or in any other high humidity environment. The operating

temperature specification is 40 to 120 degrees Fahrenheit and humidity limit is 95%,

non-condensing (no water drops forming on surfaces).

EL7 Elliptical

EL7

4Elliptical

Important Operation Instructions

●NEVER operate this elliptical without reading and completely understanding the results of any

operational change you request from the computer.

●Understand that changes in resistance do not occur immediately. Set your desired level on

the computer console and release the adjustment key. The computer will obey the command

gradually.

●NEVER use your elliptical during an electrical storm. Surges may occur in your household

power supply that could damage elliptical components. Unplug the elliptical during an

electrical storm as a precaution.

●Use caution while participating in other activities while using your elliptical such as watching

television, reading, etc. These distractions may cause you to lose balance, and that may

result in serious injury.

●Always hold on to a handrail or hand bar while making control changes.

Do not use excessive pressure on console control keys. They are precision set to properly

function with little finger pressure. Pushing harder is not going to make the unit go faster or

slower. If you feel the buttons are not functioning properly with normal pressure, contact your

Spirit dealer.

Grounding Instructions

This product must be grounded. If the electrical system of the elliptical should malfunction or

breakdown grounding provides a path of least resistance for electric current; reducing the risk

of electric shock. This product is equipped with a cord having an equipment-grounding plug.

The plug must be plugged into an appropriate outlet that is properly installed and grounded in

accordance with all local codes and ordinances.

DANGER - Improper connection of the equipment-grounding conductor can result in a

risk of electric shock. Check with a qualified electrician or serviceman if you are in doubt

as to whether the product is properly grounded. Do not modify the plug provided with

the product if it will not fit the outlet; have a proper outlet installed by a qualified

electrician.

This product is for use on a nominal 110-volt circuit, and has a grounding plug that looks like

the plug illustrated below. A temporary adapter that looks like the adapter illustrated below may

be used to connect this plug to a 2-pole receptacle as shown below if a properly grounded

outlet is not available. The temporary adapter should be used only until a properly grounded

outlet, (shown below) can be installed by a qualified electrician. The green colored rigid ear-lug,

or the like, extending from the adapter, must be connected to a permanent ground such as a

properly grounded outlet box cover. Whenever the adapter is used, it must be held in place by

a metal screw.

Grounded Outlet

Grounding Pin Grounded Outlet Box

Metal Screw

Adapter

Tab of

Grounding

Screw

Assembly Pack Check List

#96. 3/8" x 19 x 1.5T

Flat Washer (2pcs) #104. 3/8" x 23 x 2T

Curved Washer (2pcs)

#128. 3/8" x 2T

Spilt Washer (1pc)

#76. 3/8" x 3/4"

Hex Head Bolt (2pcs)

#100. 5/16" x 20x 1.5T

Flat Washer (4 pcs)

#89. 3/8" x 7T

Nylon Nut (2 pcs)

#85. M5x10m/m

#167. 5/16" x 2-1/4"

Hex Head Bolt (4 pcs) #77. 3/8" x 1-1/2"

Hex Head Bolt (2pcs)

#178. Ø5/16" x 1.5T

Split Washer (4pcs) #179. Ø5/16"

Star Washer (4pcs)

Phillips Head Screw (4 pcs)

Step 1

#75. 3/8" x 2-1/4"

Hex Head Bolt (1pc)

EL7 Elliptical

Step 2

#76. 3/8" x 3/4"

Hex Head Bolt (2pcs)

#107. Ø3.5x12m/m

Sheet Metal Screw (6pcs)

#102. 25 m/m

Wave Washer (2 pcs) #131. 3/8" x 30 x 2.0T

Flat Washer (2 pcs)

#107. 3.5x12m/m

Sheet Metal Screw (2pcs)

#82. M5 x 15m/m

Phillips Head Screw (22pcs) #157. M6 x 10m/m

Phillips Head Screw (4 pcs)

#100. 5/16" x 20 x 1.5T

Flat Washer (2 pcs) #79. 5/16" x 1-1/4"

Hex Head Bolt (2 pcs)

#91. 5/16" x 7T

Nylon Nut (2 pcs)

Step 3

Step 4

EL7 Elliptical

Tools

#126. Phillips Screw Driver (1 pc) #125. Short Phillips Screw Driver (1 pc)

#129. 12 / 14 m/m Wrench (1 pc) #124. 13 / 14m/m Wrench (1 pc)

EL7 Elliptical

Assembly Instructions

■UNPACKING THE UNIT

1. Using a razor knife (Box Cutter) cut the outside, bottom, edge of box along the dotted Line. Lift

Box over the unit and unpack.

2. Carefully remove all parts from carton and inspect for any damage or missing parts. If damaged

parts are found, or parts are missing, contact your dealer immediately.

3. Locate the hardware package. The hardware is separated into steps. Remove the tools first.

Remove the hardware for each step as needed to avoid confusion. The numbers in the instructions

that are in parenthesis (#) are the item number from the assembly drawing, for reference.

STEP 1: Incline Rail Assembly and Console Mast

1. Install the Incline Rail Assembly (2) into the U-channel bracket of the Main Frame (1). Secure

with the six bolts & associated hardware as follows: From the sides install two 3/8”x1-1/2” Hex

Head Bolts (77) with two 3/8”x19mm Flat Washers (96) and two 3/8”x7T Nylon Nuts (89). From

the top install four 5/16”x2-1/4” Hex Head Bolts (167), four 5/16” Split Washers (178), four

5/16”x20 Flat Washers (100), and four 5/16” Star Washers (179), as shown in figure 1, and

tighten with the 13/14 mm Wrench (124) and 12/14mm Wrench (129).

2. Connect the three Incline Motor Power lines by matching the Red, White and Black color codes

of the wires (37) and the 3-pin position Sensor Connector (38).

Locate the Console Mast (12)

and

Console Mast Cover (49)

and

slide the Cover

onto

the Mast as

far as

will

go. Make sure

the Console Mast Cover is

facing the correct way. At the

top opening

the Main

Frame

the

elliptical

there

is a Computer Cable (39) and an incline cable (36). Unravel

and straighten out the

cables and feed them

into the

bottom of the console mast tube and out of the top

opening.

Install the Console Mast (12) into the receiving bracket on the top of the Main Frame (1). Pull

slightly on the cables at the top of the mast while installing. This will ensure the cable does not

get pinched and electrically shorted during the console mast assembly.

Put

one

3/8"

Split

Washer (128)

onto the

3/8"

2-1/4" Long

Hex

Head Bolt (75) and install

through the left side of

the receiving

bracket

into

the

Console

Mast (12). Put the

two 3/8

x 23

Curved

Washers (104)

onto the

two 3/8" x 3/4" Short Hex Head Bolts (76) and install through

the front of the console mast. Using

the

13/14m/m

Wrench,

tighten

the

three

bolts,

and

the

fourth bolt

, which

is pre-installed, firmly. These

bolts should be tightened as

much as

you

possibly can.

4. Plug all of the connectors into the back of the console; Computer Cable (39), two Hand pulse

Cables (44) and Incline cable (36). Secure the Console (32) on the console mounting plate with

four M5x10m/m Phillips Head Screws (85).

EL7 Elliptical

Indice

Altri manuali Spirit Ellittica

Spirit

Spirit E-Glide SE550 Manuale utente

Spirit

Spirit SE500 Manuale utente

Spirit

Spirit XE895 Manuale utente

Spirit

Spirit CE800 Manuale utente

Spirit

Spirit XE395 Elliptical Manuale utente

Spirit

Spirit XE795 Manuale utente

Spirit

Spirit CE900ENT Manuale utente

Spirit

Spirit XE 195 Manuale utente

Spirit

Spirit 16611608000 Manuale utente

Spirit

Spirit Empire SPT0045 Manuale utente

Spirit

Spirit Group Exercise Elliptical Manuale utente

Spirit

Spirit XE 195 Manuale utente

Spirit

Spirit 350 Manuale utente

Spirit

Spirit CE900ENT Manuale utente

Spirit

Spirit XE 195 Manuale utente

Spirit

Spirit XE 125 Manuale utente

Spirit

Spirit XE395 Elliptical Manuale utente

Spirit

Spirit XE395 Elliptical Manuale utente

Spirit

Spirit XE500 Manuale utente

Spirit

Spirit 16117680US Manuale

Spirit

Spirit CE800 ENT Manuale utente

Spirit

Spirit Esprit EL255 Manuale utente

Spirit

Spirit XE850-A27 Manuale utente

Spirit

Spirit 161173195 Manuale utente

Manuali Ellittica popolari di altre marche

Weslo

Weslo Momentum 4.0 Elliptical Manuale operativo e di manutenzione

Progear Fitness

Progear Fitness Air elliptical pro 1307 Manuale utente

Torque Fitness

Torque Fitness XPLLP Manuale utente

Octane Fitness

Octane Fitness PRO3700C Manuale utente

Xterra

Xterra FS5.8e Manuale utente

Bodyguard

Bodyguard E-40 Manuale utente

Bonn Germany

Bonn Germany Concept 2.2 Manuale utente

Precor

Precor Resolute RSL 620 Manuale utente

NordicTrack

NordicTrack E 9.2 Elliptical Manuale utente

Vision Fitness

Vision Fitness X6600iNetTV Manuale utente

Matrix

Matrix MX-A5x Manuale utente

SportsArt Fitness

SportsArt Fitness ECO-NATURAL Elite E874 Manuale utente

Sears

Sears FREE SPIRIT C249 30737 0 Manuale utente

True

True FS-64 Manuale utente

Sport-thieme

Sport-thieme ST 310 Manuale utente

VIRTUFIT

VIRTUFIT CTR 1.1 Manuale utente

Kettler

Kettler GIRO C 1 Manuale utente

CIRCLE FITNESS

CIRCLE FITNESS E7 Manuale utente
