WallDim1 & WallDim5
DMX controllers
USER MANUAL AND
INSTALLATION GUIDE
2(615) 599-1505 www.springtree.net
Table of Contents
1. Product Information
Description................................................................................................................................3
Features....................................................................................................................................3
2. Installation
Power supply.............................................................................................................................4
Mounting....................................................................................................................................4
Connecting..............................................................................................................................4-5
3. Programming
Programming..........................................................................................................................6-8
4. Technical Specications
Dimensions...............................................................................................................................9
4. Troubleshooting
Troubleshooting.......................................................................................................................10
Contact us...............................................................................................................................10
3(615) 599-1505 www.springtree.net
Product Information
Description
The WallDim1 and WallDim5 are stand alone, in-wall true
DMX controllers. Fully addressable and ready to control one
DMX channel on the WallDim1 or 5 consecutive channels with
the WallDim5. No need for programming or additional consoles.
With the WallDim1 and WallDim5 you are ready to control
any 1-5 DMX channel light or device right out of the box.
Features
• Self-contained 1 and 5 channel DMX control
• Stackable (Highest takes precedence)
• DMX IN and OUT
4(615) 599-1505 www.springtree.net
Installation
Power Supply
The Springtree WallDim1 and WallDim5 uses a standard 12V power supply (provided). Be sure
to ground your unit to prevent damage. ***See “Connecting Power and Grounding” on page 5***
Mounting
The Dim1 and Dim5 come with a single gang mud ring but can also be mounted in a RACO
2 gang electrical box with a RACO 1 device mud ring cover seen below. ***Only the mud ring with
tabs will t.***
Connecting DMX
Connect as shown below. Power in is to the left. DMX out is in the center and DMX in is to
the right. Attention audio people: DMX is backwards from audio. Pin 2 is negative and pin 3 is posi-
tive. Most of the time pin 2 will be a white or red wire. Pin 3 will always be black.
DMX Wiring
Pin 1 = Ground
Pin 2 = Negative
Pin 3 = Positive (Hot)
INOUT
PWR
Included
+ =
5(615) 599-1505 www.springtree.net
Installation - cont.
Connecting Power and
Grounding
The WallDim1 and WallDim5 comes with
a short power whip that connects to the 12v pow-
er supply that is provided. If there is power close
simply connect the WallDim1 or WallDim5 to the
power supply. If power is not nearby, power can be
extended with 18 gauge low voltage cable.
The Springtree WallDim1 and Wall-
Dim5 should be grounded in order to prevent
static shock damage. Using a short 18 gauge
whip the WallDim units can be grounded to
the outlet that is providing power.
G - +
6(615) 599-1505 www.springtree.net
Dip Switches
The WallDim1 and WallDim 5 DMX addressing is done via dip switches on the back. The
WallDim unit should be addressed to whatever DMX channel you would like to control. For example
to control DMX address 001 the dip switch #1 should be turned on. For DMX address 005 the dip
switches #1 and #3 should be on. Refer to the dip switch chart on the following pages for more ad-
dressing.
Programming - DMX dip switches
7(615) 599-1505 www.springtree.net
Programming - DMX dip switches cont.
8(615) 599-1505 www.springtree.net
Programming - DMX dip switches cont.
9(615) 599-1505 www.springtree.net
Technical Specications
Dimensions:
• Power: 12V
• Weight: .3 lbs
• Finish: Black or White
Aluminum
Safety Precautions
• To reduce the risk of electrical shock or re, do not expose this unit to moisture.
• Be sure that the local power outlet matches that of the required voltage for your unit.
• Do not attempt to operate this unit if the power cord has been frayed or broken. Do not attempt
to remove or break o the ground prong from the electrical cord. This prong is used to
reduce the risk of electrical shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• This xture is intended for indoor use ONLY!
• Keep this manual for as long as you own this product!
4 3/4”
(12cm)
3” (7.62cm)
10 (615) 599-1505 www.springtree.net
Ocehours:
Monday-Friday,
8:30 AM to 5:00 PM CT
Telephone:
(615) 599-1505
E-mail:
Website:
www.springtree.net
Troubleshooting
Lightsnotresponding?
1. Check that the 12V power supply is plugged in and connected to the WallDim1 or
WallDim5 unit.
2. Check that the DMX cables are connected properly and are wired correctly.
3. Check the dip switches. Is your xture addressed the same as the WallDim1 or Wall-
Dim5 unit?
Contact us
Springtree Media Group would like to thank you for choosing our company for
your lighting needs! If you have any questions or concerns, please contact us.
