Your Guarantee
If this product is found to be faulty as a result of faulty materials or workmanship within one year from date of
purchase, it will be repaired free of charge.
This guarantee is subject to the following terms:
· Sunpentown must be notied of the fault.
· Proof of purchase must be presented to Sunpentown's nominated representative.
· The warranty will be void if the product if modied, misused or repaired by an unauthorized
person.
· The warranty after repair will not be extended beyond the original one-year period.
· All replacement parts will be new or reconditioned.
· Parts, which are replaced, become the property of Sunpentown.
· The warranty applies for the use of the product in the USA only.
What is NOT COVERED:
· Warranty does not include freight charges.
· Damage due to installation error, product abuse and/or misuse.
· Incidental or consequential damage caused by possible defects with this product.
· Labor cost incurred for the installation and/or removal of a possible defective unit.
· Damage to product caused by improper power supply voltage, accident, re, oods or acts
of nature.
· Failure of product resulting from unauthorized modications to the product.
· Improper installation or failure to perform the necessary maintenance.
· Normal wear and tear on parts or replacement of parts designed to be replaced.
· Damage to personal property from use of product.
· Replacement or repair of household fuses, circuit breakers, wiring or plumbing.
This GUARANTEE is in addition to your Statutory Rights
SUNPENTOWN INTERNATIONAL INC.
14625 Clark Ave. City of Industry, CA 91745
Tel: 800-330-0388
Model: SA-110
ULTRASONIC
AROMA DIFFUSER
Relax and rejunvenate with this Ultrasonic Aroma Diffuser.
Creates instant relaxing aromatherapy by adding your
favorite essenal oil.
By breaking up the mixture of water and essenal oil into
million of micro-parcles, the stream of air is enrely
diffused of acvated ingredients of blended essenal oil.
Under this richly enhanced effect of aromatherpay, your
nerves would be eased and your skin would be moisturized.
6. Due to the rapid vibrating frequency of ultrasound, it is normal
for the water to become warm (up to 130°F after some time).
WARNING
1. Unit must be on leveled surface and not tilted.
2. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their satety.
3. Children should be supervised to ensure that they do not play
with the appliance.
4. Unplug the appliance during lling and cleaning.
5. Do not empty water from the side where air vent is located.
Once
Twice
Third me
On
On
Changing
Set Color
off
Control Buon - press: Light
Mist
Fourth me Off
On
Off
Product name: Ultrasonic Aroma Diffuser
Product Size: ø 5.12 in. x H 7.48 in.
Input Voltage: DC-24V / 0.5A
Power: 12W
(Uses universal adapter 100-240V/50-60Hz)
Water Tank Capacity: 80 ml (2.7 . oz.)
A. Cover
B. Water Guard
C. Base (water tank)
1. Ceramic disc
2. Max water level line
3. Air vent
4. Control button (underside of base)
D. Power Adapter
Max Water level (80ml)
4
D
1.1-1.2. Connect adapter to base of unit and plug into the wall
OPERATION
,
,
Important Notes Before Use:
A.Place the unit on an even surface, We recommend using
distilled water to prolong the unit’s life span.
Corrosive liquid is not suitable for this unit.
B.Fill water (80ml) into the water tank.
C.Use of water-soluble essential oil is recommended.
D.If product is tripped during operation, water may enter the
internal space. If this occurs, unplug the power and empty
all water. Keep the unit upright in a ventilated place for
3 days. If unit does not function properly, please contact
Sunpentown.
2.Remove the glass cover and guard.
CAUTION: Handle with care.
DO NOT EXCEED
THE MAX WATER
LEVEL LINE
3. Fill water (max 80ml)
into the water tank.
4.Add 2~3 drops of
essential oil into
the water
5.Replace cover.
CORRECT 6. Press down toward the Control Button
side (button is labeled with a sticker).
You will hear a click when control
button is pressed correctly.
WRONG
NOTE: Unit will automatically shut off when water is out.
control button X1-2.Turn off the unit and
unplug from power source.
3.Remove the cover.
1
2
3
air vent is located.
4.Empty water from the back side.
Avoid pouring water from where the
5. Use a clean swab or cloth to
clean the unit (At least once
every 3 days ).
The ceramic disc has a life span of approx. 3,000 hrs.
For replacement ceramic discs, please contact Sunpentown
at 1-800-330-0388 or visit www.spt-usa.com.
Check power connection.
Contact Sunpentown to
purchase replacement discs
Power supply is not connected
Insufcient water Add water
Pour away excess water
Cover is blocked by water drops
or mineral buildup
Clean with a swab and keep
the misting vent clean
Water overll (exceed 100ml)
The ceramic disc has reached
its life span (approx 3,000 hrs)
Water
becomes
warm
This is normal. Due to rapid vibrating frequency of
ultrasound, water can get heated up to 130°F.
