SPT WA-9010E Manuale utente
Portable Air Conditioner
Model: WA-9010E
Instruction Manual
It is important that you read these instructions before using your
portable air conditioner and we strongly recommend that you keep
them in a safe place for future reference.
Sales Inquiries - 800-934-9194
TABLE OF CONTENTS
Thank you and energy saving tips
Introduction.................................................1
Partsandaccessories..................................2
Installation...................................................3
Controlpanelfunctions.................................7
Remotecontrolfunctions..............................8
Operatingtheunit........................................9
Drainage......................................................10
Maintenance................................................12
Storage.......................................................14
Cautions......................................................15
Troubleshooting...........................................16
Specification................................................17
Defectivenotice...........................................18
Your Guarantee
THANK YOU!
Energy Saving Tips
Thank you for choosing the portable air conditioner from SPTusa, a
leading brand in indoor air treatment. We would like you to enjoy the
many benefits this unit offers, so please take the time to read this
manual carefully and take full advantage of the many advanced
features that your SPTusa Air Conditioner offers you.
SPTusa has specialized in complete indoor environment control,
manufacturing world-class air conditioners, dehumidifiers and air
purifiers with innovative technology.
In designing these advanced products, we have listened carefully to
our customers and have passed their views on to our research and
development laboratories. We wish you many years of enjoyable use.
After reading this manual, please keep it in a safe place for future
reference.
·Please use the unit in the recommended room size.
·Do not locate the air conditioner where furniture or other objects
can obstruct the airflow.
·Keep blinds/curtains closed during the sunniest part of the day.
·Close the fireplace damper and floor or wall grills so that cool air
does not escape through the chimney or ductwork.
·Keep the filters clean.
Set the unit to maximum cooling and high speed fan initially, then
adjust the unit to a comfortable setting.
NOTE: It is recommended to turn on the air conditioner when the
room temperature is around 75ºF. Do not wait until the room is
excessively hot.
INTRODUCTION
This Portable Air Conditioner is a small size appliance, which can
adjust the temperature and humidity in a room. Its flexibility
characteristics make it easily used on different occasions in
different rooms. It also has multiple functions, including cooling,
dehumidifying and fan ventilation. This unit is designed to be used
in a family house, office, etc. It has a compact design compared to
others with the same cooling capacity. Power consumption is low
and the noise especially low.
SPTUSA Portable Air Conditioner
1
Before you use your PORTABLE AIR CONDITIONER,
please read this instruction manual carefully so that you get
the best from the unit.
This instruction manual is used for guidance and does not
form part of a contract. We reserve the right to make technical
changes without prior notice.
ATTENTION
2
FRONT
BACK
ACCESSORIES, PARTS AND FUNCTIONS
control panel
hot air outlet grill
lower air inlet grill
upper air inlet grill
air outlet
up/down air swinging louvers
caster
power cable
water tank
handle
left/right air swinging louvers
ACCESSORIES
ON/OFF
MODE
TIMER
HOUR
HOLD
MIN
FAN SPEED
SWING
COOL DRY FAN
AM PM ON
OFF
H
**
oF
window kit x 2
remote
window kit adapter
flexible exhaust hose
AC/hose adapter x 2
INSTALLATION
3
20 inch
20 inch
Installing the air exhaust duct
1) Fix adaptors onto hose by turning clock-wise
2) Fix the square end of the duct to the exhaust terminal of the unit
3) Lead the other end to the nearest window. Note: the length of the hose
is between 23.7 ~ 70 inches. Do not extend beyond the supplied
length. Keep hose length as short and as straight as possible.
12.8 inch
32.7 inch
17.3 inch
20 inch
Selection of installation location
Place the portable air conditioner on a flat surface where the air outlets are not blocked.
Place the unit with at least 20 inches of clearing from a wall or other obstacles.
heat exhaust air duct
hot air terminal
window
exhaust air opening
4
If the air exhaust requires bending, use the following as a guideline:
INSTALLATION
Correct mounting shown below. If mounting through wall, the height of the hole
should be between 16 ~ 51 inches from the floor.
fig. 23
51 inch
16 inch
20 inch
24 inch
20 inch
5
Example WRONG mounting diagram (Air exhaust bend is too large, will cause overheating.)
INSTALLATION
Window Kit Installation
Your window kit has been designed to fit most standard "vertical" and "horizontal" window
applications. However, it may be necessary for you to improvise/modify some aspects
of the installation procedures for certain types of windows. Please refer to Fig. 24 &
Fig. 24a for minimum and maximum window openings.
Fig.24a
Fig.24
inches
inches inches
inches
Water Tank Safety Feature
This unit is equipped with a fail-safe switch mechanism which prevents the unit from
condensing water in the event the water tank is accidentally displaced and/or FULL with
water. If this situation occurs, the WATER FULL indicator light will flash red continuously
until the water tank is correctly positioned and/or emptied
NOTE: The fan motor will continue to operate under this condition. This is normal, but no
cooling or dehumidifying will occur until the tank is emptied and/or correctly installed. (It
may take several minutes before the compressor resumes normal operation
6
INSTALLATION
Fig. 25
I
Installation Accessories (Fig. 25)
Flexible exhaust hose with adapters........3/set
stretches from 19 1/2" to 78 3/4"
Window exhaust adapter (flat mouth ).........1pc
Unit exhaust adapter (round) .....................1pc
Adjustable window slider kit.....................2/set
from 26 5/8" to 48 3/8"
Drain hose connector..................................1pc
continuous drain option (hose not included)
NOTE: Exterior drain hose extension is not
included with this unit but can be purchased
through any local Hardware Store.
Continuous Drainage
1.Remove the seal of drainage tube (as shown in
image).
2.Extend the tube outside the unit for drainage,
as shown.
3.Pay attention to place the tube in a proper
situation to avoid causing the electric controls
to not work properly.
Power cord storage
Fix the roll wire at the back of the air guide plate
with the clasp. Wrap the power cord around the
clasp when unit is not in operation.
7
CONTROL PANEL FUNCTIONS
Sets the
room
temperature
SWING Button
Selection of this button
will determine the air
delivery in swinging
or fixed direction mode.
FAN SPEED Button
Press this button will
choose high, medium
or low speed of air
delivery.
MODE Button
Press this button will select
among the modes of
cooling, dehumidify or
fan.
TIMER Button
Press this button to
switch-on, switch-off or
delete timer.
TIME Button
Sets remaining
time for timer
operation.
COMPRESSOR
Indication Light
WATER
FULL
indication
light
ON/OFF Button
To turn unit ON or OFF
TEMP Button
Display of preset temperature and failure
code. When SET is displayed, the displayed
digits indicate the preset temperature. When
FAULT is displayed, the displayed digits
indicate the code of failures.
MODE
COOL
DRY
FAN
FAN SPEED HIGH MED LOW
SWING
SET FAULT OFF
ON
Operation mode
Display of Time Setting
The displayed digits
indicate the remaining
time for timer ON/OFF
operation
Louver indicator
Fan speed indicator
F
0
TIMER TIME
COMP WATER FULL
SWING
FAN SPEED MODE
TEMP
MODE
COOL
DRY
FAN
FAN SPEED HIGH MED LOW
SWING
SET FAULT OFF
ON
+
-
MODE
F
0
Timer set to turn ON
Timer set to turn OFF
